- Page 1 OWNER’S MANUAL (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27GL63T 27GK65S www.lg.com Copyright © 2019 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Table of ConTenTs lICense ........3 HDMI Connection - Connecting Peripherals...........17 asseMblInG anD PRePaRInG 4 Connecting Headphones - Supported Drivers and Software ......4 UseR seTTInGs ....... 18 - Product and Button Description......5 - Activating the Main Menu ........18 How to Use the Joystick Button Main Menu Features - Moving and Lifting the Monitor......6 - User Settings ...............20... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Assembling And Preparing
• It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Illustrations in this document represent typical procedures, so they may look different from the actual product. -
Page 5: Product And Button Description
Product and button Description How to Use the Joystick button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. basic functions Press the joystick button once with Power on your finger to turn on the monitor. -
Page 6: Moving And Lifting The Monitor
Moving and lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. - Page 7 • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the monitor or human injury. In addition, this may cause the joystick button to malfunction.
-
Page 8: Installing On A Table
Installing on a Table adjusting the stand Height Lift the monitor and place it on the table in an upright position. Place the monitor at Place the monitor mounted on the stand base in an upright position. least 100 mm away from the wall to ensure sufficient ventilation. Handle the monitor with both hands for safety. -
Page 9: Adjusting The Angle
adjusting the angle WaRnInG Place the monitor mounted on the stand base in an upright position. • To avoid injury to the fingers when adjusting the screen, do not hold the lower part Adjust the angle of the screen. of the monitor’s frame as illustrated below. The angle of the screen can be adjusted forward or backward from -5°... -
Page 10: Pivot Feature
Pivot feature Adjust the angle of the monitor in the direction of the arrow as shown in the figure. The pivot feature allows the monitor to rotate 90° clockwise. Head stand Rotate the monitor clockwise as shown in the figure. WaRnInG •... -
Page 11: Tidying Up Cables
Tidying up Cables Complete the installation by rotating the monitor 90° as shown below. Arrange the cables using the cable holder as shown in the illustration. Mouse Holder noTe • Auto Pivot feature of the display is not supported. • The screen can be rotated easily using the screen pivot shortcut key provided with your Windows operating system. -
Page 12: Using The Kensington Lock
Using the Kensington lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the This monitor meets the specifications for the wall mount plate or other compatible monitor. devices. For more information on installation and usage, refer to the Kensington lock owner’s Place the screen face down. -
Page 13: Installing On The Wall
If you use screws longer than the standard length, it may damage the inside of bracket. the product. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. 100 mm Wall Mount (mm) - Page 14 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor Monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Screw •...
-
Page 15: Using The Monitor
USING THE MONITOR Connecting to a PC • This monitor supports the *Plug and Play feature. Press the joystick button, go to Settings → Input, and then select the input • * Plug and Play: A feature that allows you to add a device to your computer without option. -
Page 16: Displayport Connection
Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. -
Page 17: Connecting Peripherals
Connecting Peripherals Connecting Headphones Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones. Angled Straight •... -
Page 18: User Settings
UseR seTTInGs button Menu status Description Main menu disabled Enables the main menu. Exits the main menu. activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor. -
Page 19: Main Menu Features
Main Menu features Main Menu Description Input Sets input mode. Power off Power off Turns off the monitor. settings Configures the screen settings. exit Input settings Game Mode Sets the game mode for gaming. Game Mode exit Exits the main menu. -
Page 20: User Settings
User settings Menu settings To view the settings menu, press the joystick button at the bottom of the monitor and then enter the settings. Configure the options by moving the joystick up/down/left/right. To return to the upper settings or set other settings items, move the joystick to or press ( ). - Page 21 settings Description Game Mode Changes the game mode to the one optimized for a given feature. Game adjust Adjusts the 1ms Motion blur Reduction,adaptive-sync,black stabilizer,Response Time,Cross Hair and Game Reset. Picture adjust Adjusts the brightness,Contrast,sharpness,Gamma,Color Temp,R/G/b,black level,DfC and Picture Reset. Input Input list Selects the input mode.
- Page 22 Game Mode on SDR(Non-HDR)signal. settings > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 2 Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup options.
- Page 23 Game Mode on HDR signal. settings > HDR Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 2 Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup options.
- Page 24 settings > Game adjust Description This mode minimizes motion blur in fast-moving videos. To take full advantage of this function, select 1920 x 1080 @ 120Hz/144Hz before enabling 1ms Motion blur Reduction. This function is available for the following vertical frequency. (120Hz/144Hz) Turns 1ms Motion blur Reduction Mode off.
- Page 25 Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • Supported Interface: DisplayPort,HDMI. • Supported Graphic Card : A graphic card that supports AMD’s Adaptive-Sync is necessary. • Supported Version : Make sure to update the graphic card to the latest driver.
- Page 26 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Setting to Faster may cause image sticking. Response Time Faster Sets the response time to faster.
- Page 27 Settings > Picture Adjust Description Adjusts the brightness of the screen. Brightness Adjusts the contrast of the screen. Contrast Sharpness Adjusts the sharpness of the screen. Gamma Mode 1, Mode The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes.
- Page 28 Settings > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Input Just Scan The aspect ratio is not adjusted from the original.
- Page 29 Settings > General Description Language Sets the menu screen to the desired language. High Saves energy using the high-efficiency SMART ENERGY SAvING feature. SMART eNeRGY Saves energy using the low-efficiency SMART ENERGY SAvING feature. SAVING Disables the SMART ENERGY SAvING feature. Turns the power LED on the bottom of the monitor on or off.
- Page 30 This feature disables the configuration and adjustment of menus. Enables OSD Lock. Disables OSD Lock. OSD Lock NOTe General • All features are disabled except Brightness,Contrast in Picture Adjust, Input, OSD Lock and Information in General. Information The display information will be shown Serial Number, Total Power On Time, Resolution. Reset Cancel the select.
-
Page 31: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com . • Make sure to check if the graphics card supports Plug and Play function. some features are disabled. - Page 32 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. screen display is unstable and shaky.
- Page 33 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > settings > Color Quality. (The (16 colors)? settings may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 34: Product Specification
PRODUCT SPECIFICATION LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Color Depth HDMI 8-bit color is supported. DP (DisplayPort) 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 144 Hz Recommended Resolution 1920 x 1080 @ 60 Hz Operating Frequency HDMI Horizontal Frequency... - Page 35 Environmental Conditions Operating Conditions Temperature 0 °C to 40 °C Humidity Less than 80 % Storing Conditions Temperature -20 °C to 60 °C Humidity Less than 85 % Dimensions Monitor Size (Width x Height x Depth) With Stand 615.1 x 575.2 x 274.4 (mm) Without Stand 615.1 x 366.6 x 45.2 (mm) Weight (Without Packaging)
-
Page 36: Factory Support Mode
factory support Mode (Preset Mode, HDMI/ DisplayPort PC) Preset Mode Horizontal frequency (kHz) Vertical frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 640 x 480 37.5 800 x 600 76.302 800 x 600 46.875 75.0 800 x 600 37.879 60.317 1024 x 768... -
Page 37: Hdmi Timing (Video)
HDMI Timing (Video) factory support mode Horizontal frequency Vertical frequency Remarks (Preset Mode) (kHz) (Hz) 480P 31.5 576P 31.25 720P 37.5 720P 1080P 56.25 1080P 67.5 1080P 112.5 1080P Power leD Mode leD Color On Mode Red (For a few seconds) Sleep Mode Off Mode... - Page 38 Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and Model handling) upon email request to opensource@lge.com.
