415U-IAS Intelligent Antenna Switch User Manual
Contents
Introduction...................................................... 1
System Design ................................................ 2
Redundancy ................................................ 2
Connection to the SCADA computer ........... 2
Connection to the Legacy Base Radio ........ 2
Configuration ................................................... 3
Configuration ............................................... 3
connection ................................................ 4
Legacy Base Radio Connection .............. 4
connection ................................................ 4
Configuration ............................................... 5
Field Station Serial Connection ............... 5
Introduction
The ELPRO 415U-IAS provides a way to operate two radio telemetry systems side by side using
existing infrastructure. The primary use-case is when an existing system is being incrementally
upgraded to ELPRO 415U radio hardware. The 415U-IAS automatically switches the base station
antenna between a legacy base station radio and the upgraded base station radio as needed to
communicate with a mix of legacy and upgraded radios in the field.
The 415U-IAS switch module is used in conjunction with an ELPRO 415U-BSR (Base Station and
Repeater) which monitors the polling requests sent to the remote field stations and instructs the
switch module to connect the required base station radio (Legacy or 415U-BSR) to the antenna.
Responses from field stations are monitored, and the switch will alternate between the two systems
when it doesn't see a valid response from a field site. This allows incremental upgrades of field sites
without a need to make configuration changes when field sites are switched from the legacy system to
the new 415U system.
ELPRO_415U-IAS_IntelligentAntennaSwitch_UserManual_1.0.docx
ELPRO Technologies
29 Lathe Street
Virginia QLD 4014
Australia
tel: +61 7 3352 8600
www.elpro.com.au
Diagnostics ..................................................... 6
LED indication on 415U-IAS ....................... 6
415U-BSR Internal Diagnostics .................. 6
Serial Connection Statistics ..................... 6
Capture IP Comms .................................. 6
Connection ...................................................... 7
Rear Panel Connections ............................. 7
RS232 DTE - DB9 Male (DTE) ............... 7
5.08mm .................................................... 7
RF Switch 1 and RF Switch 2 .................. 7
Earth ........................................................ 7
Front Panel Connections ............................. 8
Legacy Radio - DB25 Male - DTE .......... 8
Specifications - ELPRO 415U-IAS ................. 9
References: ..................................................... 9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elpro Technologies EL-415U-IAS-C Series
Summary of Contents for Elpro Technologies EL-415U-IAS-C Series
-
Page 1: Table Of Contents
ELPRO Technologies 29 Lathe Street Virginia QLD 4014 Australia tel: +61 7 3352 8600 www.elpro.com.au 415U-IAS Intelligent Antenna Switch User Manual Contents Diagnostics ............. 6 LED indication on 415U-IAS ....... 6 Introduction............1 415U-BSR Internal Diagnostics ....6 System Design ..........2 Serial Connection Statistics ..... -
Page 2: System Design
Page 2 of 9 November 2021 System Design The 415U-IAS is designed to be installed with an existing legacy system. The 415U-BSR monitors MODBUS messages sent from a central SCADA computer and monitors MODBUS responses from field sites. The system can use either RS-232 serial communications or it can communicate over TCP-IP link. -
Page 3: Configuration
Page 3 of 9 November 2021 Configuration This section covers the configuration required on the 415U-BSR and the Remote sites for a system update with the 415U-IAS. 415U-BSR (Base Station and Repeater) Configuration The 415U-BSR controls the 415U-IAS switching between Primary and Alternate ports, and transfers data messages from the SCADA computer to the Legacy base radio and to the ELPRO 415U radio network. -
Page 4: Scada Computer Rs-232 Serial Connection
Page 4 of 9 November 2021 SCADA Computer RS-232 Serial connection When the connection to the SCADA computer is via RS-232 serial, the SCADA computer connection is through the 415U-IAS and via the RS-485 connection on the 415U-BSR. Configure the 415U-BSR RS-485 serial port to match the SCADA computer serial connection. -
Page 5: 415U-E And 415U-C Field Station Configuration
Page 5 of 9 November 2021 415U-E and 415U-C Field Station Configuration The field station units must be configured to allow MODBUS communication from the connected device back to the Multicast Pipe Manager active in the 415U-BSR. Configure the RS-232 or RS-485 port as described below to communicate with the connected device on the corresponding port. -
Page 6: Diagnostics
Page 6 of 9 November 2021 Diagnostics LED indication on 415U-IAS The 415U-IAS unit provides LEDs to indicate the status of the unit. Colour Function Power Green Indicates power connected to the 415U-IAS unit Alternate Green Indicates the RF switch (Switch1 or Switch2) is connected between ANT and Alternate ports on the rear panel. -
Page 7: Connection
Page 7 of 9 November 2021 Connection Rear Panel Connections This section provides a detailed reference on the 415U-IAS rear panel connections. RS232 DTE – DB9 Male (DTE) Pin# Abbrev Signal Name Direction Required Notes No Connection Received Data To DTE Receive to DTE Transmitted Data From DTE... -
Page 8: Front Panel Connections
Page 8 of 9 November 2021 Front Panel Connections This section provides a detailed reference on the 415U-IAS front panel connections. Scada Computer – DB25 Female - DCE Pin# Abbrev Signal Name Direction Required Notes Frame Ground <-> Connected to Chassis Gnd Transmitted Data To DCE Transmit from DTE... -
Page 9: Specifications - Elpro 415U-Ias
Page 9 of 9 November 2021 Specifications – ELPRO 415U-IAS ELPRO 415U-IAS-C1, -C4, -C9 Power Supply 9-30VDC 100mA. Internal fuse protection. Serial Connections 4 Serial Connections RS232 DTE DB9 DTE to 415U-BSR Legacy Radio DB-25 DTE to Legacy Base Radio SCADA Computer DB-25 DCE to SCADA computer RS-485...
