Vollrath REDCO Lettuce King I Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
English
English
Operator's Manual
Lettuce King
I
®
400N, 401N, 402NC, 403N
Lettuce King
IV
®
4400N
Thank you for purchasing this Vollrath Food Processing Equipment. Before operating the equipment, read and familiarize yourself with
the following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and
packaging. Use this packaging to ship the equipment if repairs are needed.
Item No. 2350026-1 Rev 01/12

Advertisement

loading
Need help?

Need help?

Do you have a question about the REDCO Lettuce King I and is the answer not in the manual?

Questions and answers

Related Manuals for Vollrath REDCO Lettuce King I

Summary of Contents for Vollrath REDCO Lettuce King I

  • Page 1 ® 4400N Thank you for purchasing this Vollrath Food Processing Equipment. Before operating the equipment, read and familiarize yourself with the following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this packaging to ship the equipment if repairs are needed.

  • Page 2: Safety Precautions

    anual rocessing quiPMent afety recautionS eatureS and ontrolS To ensure safe operation, read the following statements and understand their meaning. This manual contains safety precautions which are explained below. Please read carefully. WARning Warning is used to indicate the presence of a hazard that can cause severe personal injury, death, or substantial property damage if the warning is ignored.
  • Page 3 anual rocessing quiPMent GUIDE RODS. Guides and align the pusher head onto the blade set. HANDLE. Used to lower and raise the pusher head. LEGS. Supports the equipment. PUSHER HEAD ASSEMBLY. Made up of the guides and the pusher head block (and the handle for tabletop models). BUMPERS.

  • Page 4: Preventative Maintenance

    anual rocessing quiPMent 4. Do not wipe across the blades or use scrub pads on this equipment. Peration Wiping across the sharp edge of the blade can cause injury and will dull the blades. WARNING 5. The blade assembly (G) is best cleaned by forcing water under pressure through the blades from the unsharpened side.
  • Page 5 Please contact the qualified professional repair service listed below. VOllRATh induction Repair service • 1-800-825-6036 (UsA) or www.vollrathco.com When contacting the Authorized Professional Service Center, please be ready with the model number, serial number, and proof of purchase showing the date the equipment was purchased.
  • Page 6 anual rocessing quiPMent SPare PartS liSt - l ettuce LETTER PART NUMBER DESCRIPTION RUBBER FOOT (OLD STYLE) RUBBER FOOT, DEEP (NEW STYLE) 0655 RUBBER SEAL SCREW FIL. HEAD., 1/4-20 X 3/4” SCREW, HEX HEAD., 1/4-20 X 7/8” BLADE BLOCK BLADE BLOCK PIN LEG CASTING, FRONT / REAR BLADE BLOCK SCREW, 1/4-20 X 2”...
  • Page 7 anual rocessing quiPMent SPare PartS liSt - l ettuce ’ peratOr anual...
  • Page 8 anual rocessing quiPMent SPare PartS liSt - l ettuce LETTER PART NUMBER DESCRIPTION 0658 Rubber Seal Rubber Foot “O” ring Handle Bracket 379017 379018 Leg (new style - do not intermix with old style) 379019 Screw, Stainless, Hex, 3/8-24 x 1” Spacer 379020 Main frame with guide rods...
  • Page 9 anual rocessing quiPMent SPare PartS liSt - l ettuce ’ peratOr anual...
  • Page 10 MERChAnTABiliTY OR FiTnEss FOR A PARTiCUlAR PURPOsE As The Vollrath Company LLC’s only responsibility and the purchaser’s only remedy, for any breach of warranty, The Vollrath Company LLC will repair or, at its option, replace the defective product or part without charge, except as otherwise provided below: •...

  • Page 11: Warranty Procedure

    ONLINE: Register your warranty on-line now at www.Vollrathco.com NO WEB ACCESS: If you do not have access to the web, kindly register by completing the warranty registration form and faxing it to The Vollrath Co. LLC office in the country of purchase.
  • Page 12 The Vollrath Company, L.L.C. Technical Services: 800.628.0832 1236 North 18th Street Service Fax: 920.459.5462 Sheboygan, WI 53081-3201 U.S.A. Canada Service: 800.695.8560 www.vollrathco.com Main Tel: 800.628.0830 Fax: 800.752.5620 © 2012 The Vollrath Company, L.L.C.
