Summary of Contents for VolantexRC Hurricane 791-2
-
Page 2: Safety Precautions And Warnings
Do not use with incompatible components or alter this product in any way outside of the instructions provided by VolantexRC Co.,Ltd.. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Box Contents
Box Contents 1. Assembled Jib Sail & Boom 5. Backstay Crane 9. Ballast 2. Assembled Main Sail & Boom 6. Assembled Hull 10. Keel 3. Long Mast 7. Radio Transmitter 11. Rudder 4. Short Mast 8. Display Stand Parts 12. Shrouds Cross 13. - Page 4 Installation and Rigging Guide 1. Setup the display base as shown in picture. 2. Setup the keel, water-proof rubber piece and Insert the tubes into the sockets, no gluing is ballast by HM5*50mm screw, using a H4.0mm required. allen key. 3.
- Page 5 6. Hang the main sail on the backstay crane by 7. Insert the installed mast into the hull. the pre-rigged cord. Now the Hurricane is installed as shown on above left image. How-to hang 10.1. Take cord the cord "L1" from storage board, hang it on the backstay crane.
- Page 6 11.1. Take cord "L2" from storage board, hang it on 12.1. Take the port side of cord "L3" from forestay crane. storage board, hang it on the port side of 11.2. Lead the shrouds cross. cord through the shrouds cross. 12.2.
- Page 7 285mm 190mm 60mm 250mm 150mm 50mm 13mm 17. Adjust positions of the silicone rings on main boom and jib boom as shown in above picture. 18. Move Silicone Rings("SR" for short) to appropriate position as shown in picture. If further rigging needed, adjust refering to below instruction: 18.1.
- Page 8 8mm - 12mm 30mm - 35mm 18.6 Move SR6 to adjust the cord tied in step 15 if it is too tight(move to SR6 direction) or if too loose(move to SR4 direction), to keep the jib boom with 30mm - 35mm expand distance to mast when the sail stick is at lowest position.
- Page 9 23. Move the bowsie as shown to tighten or loosen the main sail. 2 4 . M o v e t h e b o w s i e as shown to adjust the bended angle of the mast. It should be bended little like a bow as dotted line s h o w n i n p i c t u r e , b u t e n s u r e i t i s a s t r a i g h t...
- Page 10 Transmitter Functions Instruction The yacht comes with a 2.4G 4-channels radio system. For sailing you will only need 2 channels. Learn all instructions as below: 1. Sail stick controls maximum expand angle of main sail and jib sail. When you move sail stick in upper position, both sails will be allowed with larger expand angles when wind comes.
- Page 11 How-to-sail Instruction Unlike propeller driven boats that you basically point and accelerate, sailboats present some more interesting challenge. Sailing requires constant reaction to water movements and wind directions. These reactions require adjustments of rudder and sails, in order to find the best possible course. There is no substitute for actual "on-the-water"...
-
Page 12: Troubleshooting Guide
Sail Checklist NOTE: This checklist is NOT intended to replace the content included in this instruction manual. Although it can be used as a quick start guide, we strongly suggest reading through this manual completely before proceeding. 1. Always turn on the transmitter first. 2.
Need help?
Do you have a question about the Hurricane 791-2 and is the answer not in the manual?
Questions and answers
My receiver is not binding with my transmitter.I’ve tried a second transmitter and receiver but to no joy. Is there someone somewhere that can repair or have a look at it.
To troubleshoot binding issues between the VolantexRC Hurricane 791-2 receiver and transmitter:
1. Move the transmitter 1 to 3 meters away from the receiver to avoid signal interference from close proximity.
2. Avoid operating near metal objects, as they can block or reflect signals.
3. Check that the transmitter is bound to the correct model; if not, rebind the transmitter and receiver.
4. Replace old or low batteries with new ones to ensure proper power levels.
5. Inspect wires between the battery and receiver for damage or loose connections. Repair or replace as needed.
This answer is automatically generated
