Gefen HD-PVR User Manual

High-def personal video recorder
Hide thumbs Also See for HD-PVR:
Table of Contents

Advertisement

Quick Links

Download this manual
High-Def Personal Video Recorder
GTV-HD-PVR
User Manual
www.gefentv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-PVR and is the answer not in the manual?

Questions and answers

Related Manuals for Gefen HD-PVR

Summary of Contents for Gefen HD-PVR

  • Page 1 High-Def Personal Video Recorder GTV-HD-PVR User Manual www.gefentv.com...
  • Page 2 Chatsworth, CA 91311 www.gefentv.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Gefen TV High-Def Personal Video Recorder is a trademark of Gefen Inc.

  • Page 3: Table Of Contents

    27 Viewing Photos 30 Copying/Deleting Movies And Photos 31 Viewing Photos On The SD-Card 35 Learning and Resetting The Remote 36 Installing The Decoder Software 41 Updating The HD-PVR Firmware 42 Specifi cations 43 Terminology 44 Warranty TABLE OF CONTENTS...

  • Page 4: Introduction / Operation Notes

    The HD-PVR is easy to use. You simply connect your video source(s) to one or all of the HD-PVR’s 4 inputs, then connect your HDMI display on the HDMI output. Once the source(s), the HD-PVR and the display are powered and connected, you select the video source and feature that you want using the Infrared (IR) remote.
  • Page 5 Friendly Graphical Interface for controlling Settings • 2x-10x Picture Zoom for viewing Photos • International language support INCLUDES: (1) Gefen HD Personal Video Recorder (1) 6FT HDMI cable (M-M) (1) IR Extender (1) IR Blaster (1) IR Remote (1) 5V DC Power Supply (1) User’s Manual...

  • Page 6: Panel Layout

    COMPONENT ANALOG INPUT INPUT S/PDIF S/PDIF IN 1 HDMI SD (Secure Digital) RECEIVER PANEL LAYOUT ANALOG COMPOSITE INPUT S-Video INPUT S/PDIF IN 2 HDMI HDMI IN 1 IN 2 INPUT LED INDICATOR Card Slot INPUT BLASTER EXTENDER RS232 INPUT DC 5V INPUT RECORD LED INDICATOR...

  • Page 7: Ir Remote Layout

    IR REMOTE LAYOUT TV Power User programmable key HDMI 1 Selects HDMI input 1 HDMI 2 Selects HDMI input 2 Component Selects the Component input Repeat Cycles the repeat function Info Displays info on selected movie or photo S-Video Selects the S-Video input Zoom Cycles the zoom function Snapshot...

  • Page 8: Quick Setup Guide

    When the HOME menu is displayed, you can press the HOME button on the remote control, again, to view the input source. If the HD-PVR is unable to fi nd a source signal, you will receive the message: “No Signal”. If this is the case, check the following: •...

  • Page 9: Home Menu And Navigation

    HD-PVR HOME MENU AND NAVIGATION HOME MENU This is the HOME menu. From here, you can view recorded content, view photos, set up preferences or view the input source by selecting EXIT or pressing HOME on the remote control. Navigation...
  • Page 10 HD-PVR HOME MENU AND NAVIGATION HOME MENU - Panel Description Current Media Mute Drive (HDD or SD) Status Current Menu Currently Selected Output Date Time Input Exit Exits the HOME menu, allowing you to view the input source. Setup Utilities All confi...

  • Page 11: Setting Up The Hd-Pvr

    fl ash card, if inserted. It will also display the current fi rmware and our technical support e-mail address. Learn Remote This option allows the HD-PVR remote to learn keys from another remote. Use the supplied IR Blaster to send the commands to the device. See the Learn Remote section on page 32 for more details Reset Remote Clears (resets) all user-defi...
  • Page 12 SETTING UP THE HD-PVR to move between each digit in the date and Pressing will set the date and proceed to the SET TIME screen SETUP UTILITIES - Set Time to move between each digit in the time and Pressing will set the time.
  • Page 13 SETTING UP THE HD-PVR SETUP UTILITIES - Set Language To set the language, use to select the language and press to accept the selection. You will be asked if you are sure you want to change the language. Press Yes to accept or press No to keep the current language setting. You can choose between English or Chinese.
  • Page 14 SETTING UP THE HD-PVR SETUP UTILITIES - OSD Time-out This controls the time that the information panel is displayed when viewing movies or photos. You can choose between 1, 3 or 5 seconds. Use to choose your desired setting and press to accept it.
  • Page 15 SETTING UP THE HD-PVR SETUP UTILITIES - Default Record Quality Quality HD Bit Rate Extra Fine (EX) Normal (NOR) 7.5Mb Economic (ECO) SuperEco (S.E.) 3.5Mb Select your desired recording rate with SETUP UTILITIES - Background The background menu lets you choose between two images that will serve as the backdrop for all menu screens.
  • Page 16 SETTING UP THE HD-PVR SETUP UTILITIES - Free Space / Total Space The information menu will give you statistics on the remaining and total space available on both the internal hard disk drive (HDD) and SD card. The current fi rmware is also displayed...

  • Page 17: One-Touch Recording

    The current source will now be displayed on the screen: 2. Press the RECORD button on the remote control. Once the RECORD button is pressed you should see a fl ashing red light on the front panel of the HD-PVR. This indicates that the HD-PVR is now recording.
  • Page 18 ONE-TOUCH RECORDING During the recording process, you can get information about the current recording by pressing the INFO button while you are recording. Record Indicator (fl ashing) Output Selected Input After pressing the INFO button you should see the following information: Source Resolution Duration of...
  • Page 19 To stop the recording process, press the STOP button on the remote control. The HD-PVR will ask you if you are sure you want to stop recording:...
  • Page 20 HOME menu: 1. From the HOME menu, press the RECORD button on the remote. 2. The HD-PVR will switch from the HOME menu to the source. However, you will be asked “Record, Are you sure?”. This prevents an accidental recording directly from the HOME menu, since the source is not currently being viewed.You will need...

  • Page 21: Playing A Movie

    PAUSE, then press the STEP FWD button on the remote to advance one frame at a time. PLAYING A MOVIE The HD-PVR remote has several buttons which allow you to control the playback of your recorded movies.
  • Page 22 FAST FWD (Fast Forward) Pressing the FAST FWD button during playback will advance the movie forward. Pressing the button each time will provide you with a different speed: ½ To resume normal playback speed at any time, press PLAY or OK. Press STOP to stop the movie and return to the thumbnail view.
  • Page 23 PLAYING A MOVIE From the Home Menu, choose Play Movie with and press PLAY MOVIE - Thumbnail View HD or SD Recording Icon Resolution Runtime File Name Recording Page Quality To navigate the PLAY MOVIE menu, use to make your choice and press the PLAY button to start playback.
  • Page 24 PLAYING A MOVIE MOVIE MENU The Movie Menu allows you to begin playback, copy, or delete the selected movie. to select your choice and press to select it. MOVIE INFORMATION - Panel Description Source (HDD or SD) Repeat Mode Time Indicator Play Indicator Mute Status Volume Level...

  • Page 25: Scheduling A Recording

    SCHEDULING A RECORDING From the home menu use RECORD SETUP - Schedule List The Schedule List menu displays all scheduled recordings. Once a recording is complete, the entry is removed from the list. Scheduled recordings labeled with a are active recordings. to select Record Setup and press...
  • Page 26 SCHEDULING A RECORDING RECORD SETUP - Panel Description Active Schedule Recording Recording Number Date Time Record Length Source To Media RECORD SETUP - Set Date Set the date for the recording using to change each digit. Use to move to another digit.
  • Page 27 SCHEDULING A RECORDING RECORD SETUP - Set Start Time Set the time for when you want the recording to begin. Use and use to move between the digits. Press RECORD SETUP - Set Length Set the time for when you want the recording to begin. Use and use to move between the digits.
  • Page 28 SCHEDULING A RECORDING RECORD SETUP - Set Source Set the input source for the recording using to select between HDMI1, HDMI2, COMPONENT or VIDEO. Press when you are done. RECORD SETUP - Set Media Set the media for the recording using and press when you are done.
  • Page 29 SCHEDULING A RECORDING RECORD SETUP - Set Channel If the IR blaster is connected and set up, you can select a specifi c channel (up to 4 digits). Otherwsie, you should set to OFF mode when not using an IR blaster. to change each digit and to move between them.

  • Page 30: Viewing Photos

    VIEWING PHOTOS From the home menu use to select View Photo and press Folder Menu - Description Selected Media Folder Path Page Folder Name...
  • Page 31 VIEWING PHOTOS Folder Menu - Main The Folder Menu displays the current folders located on the selected media. To change media type, press the HDD/SD button on the remote at any time. Use to navigate the menu and press to open the selected folder. Photo Selection Menu Navigate the photos with .
  • Page 32 VIEWING PHOTOS Photo Selection Menu - Photo Menu The Photo Menu will allow you to view a single photo, delete the selected photo, or delete all the photos on the selected media. Use to choose your option and press to select it. While viewing a single photo, you may move to the next photo in the folder by pressing on the remote.

  • Page 33: Copying/Deleting Movies And Photos

    COPYING/DELETING MOVIES AND PHOTOS Copying Navigate to the desired movie or photo using the instructions in the Play Movie or View Photo section. Pressing will bring up the additional menu where the COPY command is located. Choose COPY and press .

  • Page 34: Viewing Photos On The Sd-Card

    VIEWING PHOTOS ON THE SD-CARD 1. Remove the SD-Card from your digital camera and insert it in the HD-PVR SD- Card slot. 2. Press the HDD/SD button on the remote to make the SD-Card the active storage media. The icon in the upper right-hand corner of the screen should change to a black square disk icon (this let’s you know you are working with the SD-Card and...
  • Page 35 VIEWING PHOTOS ON THE SD-CARD If this happens, you will need to tell the HD-PVR where the photos are stored. Most digital cameras use the \DCIM folder for storing digital photos. By default, the HD- PVR will always look in the \PICT folder for images.
  • Page 36 In our example, our photos are stored in a folder called “101_PANA”. As you can see, the HD-PVR always tells us where we are: The text in the upper-left corner tells us what folder we are viewing (in this case, the \DCIM folder) and the text in the lower-right corner tells us what folder we have highlighted.
  • Page 37 VIEWING PHOTOS ON THE SD-CARD Once you are in thumbnail view, you can press the HOME button on the remote control to return to the HOME menu. You can also press the STOP button to move up one level in the folder hierarchy. In our example, pressing STOP will return you to the \DCIM folder.
  • Page 38 LEARN REMOTE & RESET REMOTE The Gefen HD-PVR remote has a number of user confi gurable keys that can be programmed with IR codes from other devices. The IR codes are transmitted through the IR blaster on the back of the unit. This feature allows you to control your other devices using the HD-PVR remote.

  • Page 39: Installing The Decoder Software

    NOTE: The installer only installs decoder software. You will still need a program such as Windows® Media Player to play video fi les from the HD-PVR. To install the software, please follow these steps: Start your computer and insert the included CD in your CD or DVD drive.
  • Page 40 INSTALLING THE DECODER SOFTWARE You must agree to the terms of the software license agreement before installation can continue. If you do, click “I accept the terms of the license agreement” and click Next. On the Customer Information screen, enter your name, company name and serial number.
  • Page 41 INSTALLING THE DECODER SOFTWARE If you make a mistake entering the serial number, the installation program will notify you. If this happens, click OK and you will be returned to the Customer Information screen. Make sure there are no spaces in the serial number and that you type the serial number exactly as it appears on the CD jacket.
  • Page 42 INSTALLING THE DECODER SOFTWARE This screen will show you the progress of the installer as it installs the necessary fi les. After all fi les have been installed, you have the option of using Microsoft® Windows Media Player to view all .mov fi les. If you want to do this, click the Yes button. Otherwise, click No to play .mov fi...
  • Page 43 After the installation completes, you will need to restart your computer before you can playback any movies that were recorded with your HD-PVR. Click Yes then click Finish to restart your computer now. Click No then click Finish to restart your computer at a later time.

  • Page 44: Updating The Hd-Pvr Firmware

    UPDATING THE HD-PVR FIRMWARE Updating the fi rmware on your Gefen HD-PVR is a simple process. If a new version of fi rmware is released, simply download the fi le and follow the procedure outlined below. You will need an SD-Card to update your HD-PVR.

  • Page 45: Specifications

    SPECIFICATIONS Digital Video Amplifi er Bandwidth ...165 MHz Component Video Bandwidth ...350 Mhz Input DDC Signal ...5 Volts p-p (TTL) Input Video Signal ...1.2 Volts p-p Single Link Range ...1080i /1920x1200 Input/Output HDMI Connector ...Type A 19 pin female Analog Video Connector 1...(1) Component Analog Video Connector 1...(1) RCA Composite or (1) S-Video Digital Audio Connectors ...(3) SPDIF Analog Audio Connector ...(1) RCA...

  • Page 46: Specifi Cations

    Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for confi...

  • Page 47: Warranty

    The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen , be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
