- Page 1 RF267 RF26X Refrigerator user manual English imagine the possibilities Thank you for purchasing your Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
- Page 2 Features of your new Refrigerator KEy FEatuREs oF youR nEw REFRigERatoR Your Samsung French Door Refrigerator comes equipped with various innovative storage and energy-efficient features. • twin Cooling system The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system, the Freezer and Refrigerator cool more efficiently.
- Page 3 Safety Information SAFETY INFORMATION Before using your new Samsung French Door Refrigerator, please read this manual thoroughly to ensure that you know how to safely and efficiently operate the features and functions that your new appliance offers. Because the following instruction covers various models, the characteristics of your Refrigerator may differ slightly from the Refrigerator described in this manual.
- Page 4 Safety Information Do not put undue stress on the power cord or place heavy articles on it. • Placing heavy articles on the power cord create the risk of explosion or fire. Do not insert the power plug with wet hands. • It may cause electric shock. Do not put a container filled with water on the Refrigerator. • If it spills, it may cause fire or electric shock. Do not install the Refrigerator in a damp place or water closed places.
- Page 5 • Products that require exact temperature controls should not be stored in the Refrigerator. Do not allow children to climb, stand or hang on shelves and handles of the Refrigerator. They could damage the Refrigerator and seriously injure themselves. CAUTION Do not sit on the freezer door. The door may break. Do not allow children to climb into the freezer basket. If you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator immediately and contact your Samsung Electronics Service Center. After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer compartment. Particularly when hands are damp or wet, skin may adhere to these extremely cold surfaces. • Skin may stick to the surface and you may get frostbite. Do not put your hands under the appliance. • Any sharp edges may cause personal injury.
- Page 6 Wipe excess moisture from the inside and leave the doors open to keep odor and mold from developing. Service Warranty and Modification • Any changes or modifications performed by a 3rd party on this finished appliance is not covered under Samsung warranty service, nor can Samsung be responsible for safety issues that result from 3rd party modifications. Children can get trapped inside Refrigerators.
-
Page 7: Table Of Contents
15 Adjusting the support for extension shelf 16 Making minor adjustments between doors 17 Adjusting the freezer drawer level 18 Checking the water dispenser line 19 Installing the water line OPERATING YOUR SAMSUNG 21 Using the control panel FRENCH DOOR REFRIGERATOR 22 Using the digital display 23 Controlling the temperature... -
Page 8: Setting Up Your French
Setting up your French Door Refrigerator GETTING READY TO INSTALL THE REFRIGERATOR Congratulations on your purchase of the Samsung French Door Refrigerator. We hope you enjoy the state-of-art features and efficiencies that this new appliance offers. Selecting the best location for the Refrigerator • A location with easy access to the water supply. -
Page 9: Removing The Refrigerator Doors
SETTING UP THE REFRIGERATOR Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and functions of the appliance. By completing the following steps, your Refrigerator should be fully operational. 1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and the Refrigerator. - Page 10 Setting up your French Door Refrigerator 2. Disconnect two connectors ( ) at Red Clip (1/4”) Cabinet each side of the top cap and the one Tube connector( ) on left side door . Remove Dispenser the tube ( ) with pressing the dark gray Door Tube color part ( ) of the water line coupler.
-
Page 11: Disassemble The Freezer Drawer
DISASSEMBLE THE FREEzER DRAWER 1. Take out the upper drawer by lifting it up. 2. Remove the tilting pocket( ) by pulling on both brackets( Slot Slot upward at the same time. 3. Take out the lower basket( ) by lifting the basket up from rail system. -
Page 12: Reattaching The Refrigerator Doors
Setting up your French Door Refrigerator REATTACHING THE REFRIGERATOR DOORS Assemble the Refrigerator doors 1. Reattach the lower left and right door hinges( With a Philips head screwdriver, insert and tighten a screw( ) into the lower left and right door hinges. With a Allen Wrench(3/16”), insert and tighten the two hex head bolts( ) into the lower left and right door hinges. - Page 13 REATTACHING THE REFRIGERATOR DOORS 4. Connect the water line ( ) and then insert a clip on the coupler with pulling tube. Red Clip Connect the one connector( ) on left side (1/4”) Cabinet Tube door and two connectors ( ) at each side of the top cap.
-
Page 14: Assemble The Freezer Drawer
Setting up your French Door Refrigerator ASSEMBLE THE FREEzER DRAWER 1. Pull out the rails to the full length on each side of the cabinet evenly. Slot Slot 2. Hang the freezer door front onto open slots on the sides. Slot Slot Slot Slot 3. -
Page 15: Adjusting The Doors
ADJUSTING THE DOORS Now that the doors are back on the Refrigerator, you want to make sure the Refrigerator is level so that you can make final adjustments. If the Refrigerator is not level, it will not be possible to get the doors perfectly even. When the Left door is lower than the Right door. -
Page 16: Making Minor Adjustments Between Doors
Setting up your French Door Refrigerator MAKING MINOR ADJUSTMENTS BETWEEN DOORS Remember a level Refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the Refrigerator. When the left When the left door is lower door is higher than the right than the right... -
Page 17: Adjusting The Freezer Drawer Level
ADJUSTING THE FREEzER DRAWER LEvEL Adjustment part Freezer Drawer 1. Locate the height-adjuster ( ) in the freezer drawer. Unscrew the four Phillips screws ( ) slightly to loosen the door. 2. Loosen the controller screw( ) with a Phillips screwdriver. 3. Find the best level to align the door slope. Example) The slope is about 2mm (0.08inch) as shown below. -
Page 18: Checking The Water Dispenser Line
Setting up your French Door Refrigerator CHECKING THE WATER DISPENSER LINE A water dispenser is one of the helpful features on your new Samsung Refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. -
Page 19: Installing The Water Line
INSTALLING THE WATER LINE Connecting the water line to the Refrigerator. There are several items that you need to purchase to complete this connection. You may find these items sold as a kit at your local hardware store. 1/4” compression nut copper tubing plastic tubing ferrule Refrigerator Compression nut Plastic tubing Ⓐ... - Page 20 Setting up your French Door Refrigerator Cover filter. 4. Remove the filter cap and insert the filter into the filter housing. 5. Slowly turn the water filter 90º clockwise to align with the printing mark on the cover, locking the filter in position. Make sure to align the water filter label mark with center of cover filter printing as illustrated.
-
Page 21: Operating Your Samsung
Operating your SAMSUNG French Door Refrigerator USING THE CONTROL PANEL For better energy efficiency, press the Energy Saver button. If condensation occurs on the doors, ) Energy Saver turn the Energy Saver function off. Button Press the Freezer / Power Freeze button to set the Freezer to your desired temperature. -
Page 22: Using The Digital Display
USING THE DIGITAL DISPLAY “Freezer Temp” indicates the current Freezer temperature. “Fridge Temp” indicates the current Refrigerator temperature. When not in use the Display will turn off, this is normal. Power Freeze This icon will light up when you activate the “Power Freeze” feature. “Power Freeze” is great when you need a lot of ice. -
Page 23: Controlling The Temperature
Operating your SAMSUNG French Door Refrigerator Energy Saver This icon will light up when you activate the “Energy Saver” function is automatically set to “ON” when poer is supplied to the Refrigerator. If condensation occurs on the doors, turn the Energy Saver function off. -
Page 24: Using The Ice And Cold Water Dispenser
USING THE ICE AND COLD WATER DISPENSER Press the Ice / Water button to select the type of you want No ICE Select this if you want to turn ice maker off. Using the Ice Dispenser Place a glass underneath the ice dispenser and push gently against the dispenser lever with your glass. Make sure the glass is in line with the dispenser to prevent the ice from bouncing out. - Page 25 Operating your SAMSUNG French Door Refrigerator ICE PRODUCTION Normal Use To fill ice bucket to maximum capacity after installation, make sure to do the following steps. 1. Allow your refrigerator to operate and cool down for 24 hours (or 1 full day).
-
Page 26: Parts And Features(Rf267)
Operating your SAMSUNG French Door Refrigerator wherever it appears PARTS AND FEATURES(RF267) Use this page to become more familiar with the parts and features of the Refrigerator. Light Auto Door Closer Dairy Ice-Maker Compartment Water Filter Foldable-Shelf Slide-Shelf Slide-Shelf Vertical Hinged Door Bins... -
Page 27: Parts And Features(Rf26X)
PARTS AND FEATURES(RF26x) Use this page to become more familiar with the parts and features of the Refrigerator. Light Ice-Maker Dairy Compartment Water Filter Extension-Shelf Door Bins Vertical Hinged Section Deli Drawer Vegetable & Fruit Drawers Light Auto Pull Out Drawer Tilting Pocket Freezer Drawer Bin Operating _27... -
Page 28: Storing Food
STORING FOOD The Samsung French Door Refrigerator has been designed to provide you with maximum space saving features and functions. Here are some of the customized compartments we have created to keep your food fresher longer. In order to further prevent odor from seeping into the ice compartment, stored food should be wrapped securely and as airtight as possible. -
Page 29: Using The Cool Select Pantry
USING THE COOL SELECT PANTRY™ (RF267) The Cool Select Pantry™ is a full-width drawer with adjustable temperature control. This pantry can be used for large party trays, deli items, pizza, beverages or miscellaneous items. There is a temperature control which can adjust the amount of cold air allowed into the pantry. -
Page 30: Removing The Refrigerator Accessories
Operating your SAMSUNG French Door Refrigerator REMOvING THE REFRIGERATOR ACCESSORIES 1. Door Bins & Dairy Compartment To remove - Simply lift the bin up and pull straight out. To relocate - Slide it in above the desired location and push down until it stops. Injury may occur if the door bins are not firmly assembled. -
Page 31: Using The Doors
5. Cool Select Pantry™ (RF267) To remove the pantry - Pull the pantry out to full extension. Tilt up the front side of pantry and pull straight out. To relocate the pantry - Push the rails to the back of the Refrigerator. Place the drawer onto the rails and slide the pantry back until it is in place. -
Page 32: Removing The Freezer Accessories
Operati n g your SAMSUNG French Door Refri g erator REMOvING THE FREEzER ACCESSORIES 1. Tilting Pocket To remove - Pull the brackets( ) upward until you hear a clicking sound and remove the pocket To replace - Hook the ends of the pocket into both brackets ) and push down until it locks into place. -
Page 33: Cleaning The Refrigerator
CLEANING THE REFRIGERATOR Caring for your Samsung French Door Refrigerator prolongs the life of your appliance and helps keep the refrigerator free of odor and germs. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth. You can remove the drawers and shelves for a more thorough cleaning. -
Page 34: Changing The Interior Lights
CHANGING THE INTERIOR LIGHTS Do not disassemble or replace the LED type Lighting. To change the LED Type Lighting contact Samsung service center or your authorised Samsung dealer. CAUTION If Users randomly exchange the LED lamp by yourself, this may result in electric shock or personal injury. -
Page 35: Changing The Water Filter
CHANGING THE WATER FILTER To reduce risk of water damage to your property DO NOT use generic brands of water filters in your SAMSUNG Refrigerator. USE ONLY SAMSUNG BRAND WATER FILTERS. waRning SAMSUNG will not be legally responsible for any damage, including, but not limited to property damage caused by water leakage from use of a generic water filter. - Page 36 Operating your SAMSUNG French Door Refrigerator WATER FILTER CHART Performance Data Sheet For Samsung Model DA97-06317A Using Replacement Cartridge DA29-00003G This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specifi ed in NSF/ANSI 42 and 53.
- Page 37 WATER FILTER CERTIFICATION Operating _37...
- Page 38 Operating your SAMSUNG French Door Refrigerator FOOD STORAGE TIPS Foods Refrigerator Freezer Storage Tips DAIRY PRODUCTS Butter 2-3 Weeks 6-9 Months Wrap or cover tightly. Check date code. Most milk and similar products are sold in date-coded Milk 1-2 Weeks Not recommended cartons that indicate a products’s peak freshness. Re-seal with cap or wrap tightly.
- Page 39 Foods Refrigerator Freezer Storage Tips FISH AND SHELLFISH Fish Fatty Fish (mackerel, 1-2 Days 2-3 Months trout, salmon) Keep in original wrapper and store in coldest part of refrigerator. Pack- Lean Fish (cod, flounder, age in vapor-proof and moisture proof wrap for freezer. Freeze at 0ºF. 1-2 Days 6 Months etc)
-
Page 40: Troubleshooting
Troubleshooting PROBLEM SOLUTION The Refrigerator does not • Check that the power plug is properly connected. work at all or it does not chill • Is the temperature control on the display panel set to the correct temperature? sufficiently. Try setting it to a lower temperature. • Is the Refrigerator in direct sunlight or located near a heat source? •... -
Page 41: Warranty
Samsung authorized service center. Samsung will repair or replace any part found to be defective, at our option and at no charge as stipulated herein, with new or reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of Samsung and must be returned to Samsung. - Page 42 OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL...
- Page 43 MEMO...
- Page 44 In an effort to promote recycling this user manual is printed on recycled paper.
