- Page 2 Table of Contents 1.Foreword ............3 2.Getting to know your touch phone ....6 3.Starting up the device ........7 4.Introduce the basic phone function ....9 5.Technical Specifications ........ 16 6.SAR..............17...
- Page 3 Foreword Safety In order to ensure the phone is used safely and correctly, please read the precautions below carefully before use. 1.1 General precaution · Your phone is only suitable for the battery and charger approved by our company or else it may cause the battery to leak, overheat, explode or even catch fire.
- Page 4 · Do not use or place the battery under direct sunlight, or in hot places, it may cause leakage and overheating, thus reducing performance and shortening the lifespan. · Do not charge the battery for over 24 hours continuously. · Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can cause hearing loss.
- Page 5 bathrooms, or it may cause electric shock, fire and damage of charger. · Do not touch the charger, power cord or power plug with wet hands or it can cause electric shock. · Do not put heavy objects on the power cord or change the power cord or it may cause electric shock and fire.
- Page 6 periodically. 1.4 Common Precaution Mobile Phone: · Please use the phone in an environment with temperature between -20℃- 45℃and humidity of <75%. · Please use the phone far away from regular telephones, TV sets, radio sets and office automation equipment, to avoid affecting the normal use of these equipments and mobile phone.
- Page 7 ACCORDING TO THE INSTRUCYIONS. Charger: · Do not charge under following conditions: -- Places with direct sunlight -- Places with ambient temperature less than 0℃ or over 40℃, wet or dusty places with strong vibrations (it may cause malfunction) -- Places near electrical appliances (it may affect the image and sound) like TV set, radio, etc -- Adapter shall be installed near the equipment and shall be easily accessible.
- Page 8 Getting to know your LIKUID L-1 FLYER 1) Handset 2) Receiver 3) LCD display 4) Button menu/home/back 5) Touch Panel 6) Power button 7) Camera 8) Flash 9) Battery cover 10) Speaker 11) Volume button 12) Headphone Jack (Jack3.5)Spearker 13) Micro USB...
- Page 9 Starting up the device To remove the back cover · Make sure your device is turned off. · Firmly hold the device with the front panel facing down. · Slide your finger into the groove at the top of the phone and gently pull open the back cover.
- Page 10 right panel. Insert the memory card into the slot with its gold contacts facing down until it clicks into place (See picture2). To install the battery Align the battery’s exposed copper contacts with the battery connectors at the bottom part , insert the contacts side of the battery first and then gently push the battery into place.
- Page 11 the back cover. Charging the Battery New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery.. Note: Only the AC adapter and USB sync cable provided with your device must be used to charge the device. Connect the USB connector of the AC adapter to the sync connector on your device, and then plug in the AC adapter to an electrical outlet to start charging the battery.
- Page 12 charging icon appears in the title bar of the Home screen. After the battery has been fully charged, a full battery icon appears in the title bar of the Home screen. Warning: Do not remove the battery from the device while you are charging it using the AC or car adapter.
- Page 13 Introduce the basic phone function 1. Switch Main Menu style (1) In default Home screen, slide your fingertip left and right along the screen to reveal the more home screen. (2) On Home screen, click icon on the bottom of the screen (Main menu icon) to enter the main menu screen, slide your fingertip left and right along the screen to reveal the more applications.
- Page 14 2. Home screen (1) Read your notifications When you see a notification in the status bar, touch the bar and slide your finger down the screen to open the list of notifications displayed in the sliding window. Ongoing notifications report activities such as call forwarding ON, current call status, song playing.
- Page 15 (2) Create Home screen shortcuts and widgets: From the Home screen, touch and hold the blank screen, or click MENU Key and select ‘Add’. Enter the main menu screen, slide your fingertip left to reveal the widget, select a shortcut to some of your saved information (such as a play list), a widget (a clock) for your Home screen.
- Page 16 (3) Move objects on the Home screen ·To move an icon or other item on the Home screen, you must first touch & hold it to enter move mode. The object will magnify when it’s ready to be moved. ·Without lifting your finger (or you’ll drop out of move mode), drag the object to the new position.
- Page 17 3. Camera All the pictures you can capture or view on your phone are stored on a memory card, which must be installed in your phone. Before you can use the Camera or view pictures in Pictures, make sure you have a card installed.
- Page 18 4. GPRS/WLAN network Your device’s networking capabilities allow you to access the Internet or your corporate network through WLAN, GPRS, EDGE (if available) You can also add and set up a VPN or proxy connection. To use WLAN on your device, you need access to a wireless access point.
- Page 19 If you are in the 3G service area, 3G mobile network will be displayed in the status bars.It can make the browser rapidly and support the video call. Settings: Idle-Settings-Wireless&networks-Mobile networks -3G service-Network Mode-WCDMA only. Notes: If have a video call,you must ensure that both of you are in 3G service area and have launched a video phone.
- Page 20 5. U-disk storage This phone supports movable storage, i.e., the U-disk function. When the phone is switched on, you see the icon in the status bar on the top of the screen when its connected to a PC by a data line.
- Page 22 6. Music Your music is organized into four categories: Artists, Albums, Songs, and Play lists. Select a category to view the lists within each. Once in a category, keep selecting until you reach the music you want to play. 7. BT The phone supports Bluetooth functions, you can establish a wireless connection between the phone with other compatible...
- Page 23 devices, and data transmission, and you can establish a wireless connection between devices in the phone with a distance of up to 10 meters. Bluetooth connection may be interference by obstacles, such as walls or other electronic device. (1)Enter the setting menu, Touch the Bluetooth to open the function, idle screen will display BT icon in the status bar, Open the BT discoverable and other devices can search the phone.
- Page 24 Technical Specifications Technical Specifications Weight: 130g (Including battery) Dimensions: 120.65*63.5*11.4mm Band: GSM900MHz DCS1800MHz GSM850MHz PCS1900MHz WCDMA850MHz / WCDMA1900MHz Battery Type: Li-ion Battery Capacity: 1650mAH Talk Time: about 3-5h Standby Time: about 200-300h Battery Time (No prior or separate notice is required for capacity changes) Note: Actual operating conditions depend on the local network environment, SIM, and user behavior.
- Page 25 Announcement: The manufacturer reserves the right to change or upgrade specifications or software versions without prior or separate notice. Trade marks mentioned or used in this material belong to their respective owners.
- Page 26 FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 27 television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Page 28 Specific Absorption Rate (SAR) information: This wireless phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
- Page 29 metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. More info visit our website www.likuidmobile.com...
