This symbol is used to alert the user to important
operating or maintenance instructions.
The Lightning bolt triangle is used to alert the user
to the risk of electric shock.
SAFETY
1. It is important to read these instructions, and to follow them.
2. Keep this instruction manual in an accessible place.
3. Clean only with a dry cloth. Cleaning fluids may effect the equipment.
4.
Do not cover or obstruct ventilation of this unit. Install in accordance with
the manufacturer's instructions.
5. Do not install near any heat sources such as radiators, heating vents, or other
apparatus that produces heat.
6.
Refer all servicing to qualified personnel. Servicing is required when the
apparatus has been damaged in any way, such as a power supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to any rain or moisture, does not
operate normally or has been dropped.
7.
WARNING - To reduce risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to
dripping or splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CLD1-AC INSTALLATION HANDBOOK
Box Contents
1 x CLD1-AC
1 x AC power cable
1 x A6 Induction loop logo
1 x 'CLD1-AC Installation Handbook''
1 x Loop coil and fixings (if requested)
1 x Microphone option (if requested)
TO PREVENT ELECTRIC SHOCK DO NOT
REMOVE THE COVER. THERE ARE NO
USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
PERSONNEL.
Advertisement
Related Manuals for Ampetronic CLD1-AC
Summary of Contents for Ampetronic CLD1-AC
- Page 1 1 x CLD1-AC Introduction 1 x AC power cable Quick Start 1 x A6 Induction loop logo Installation 1 x 'CLD1-AC Installation Handbook'’ Troubleshooting 1 x Loop coil and fixings (if requested) Technical Specification 1 x Microphone option (if requested) Warranty...
- Page 2 INTRODUCTION The CLD1-AC Compact Loop Driver has been designed as a high quality stand- alone induction loop driver for ticket counters, banks or other point of sales systems. The unit is designed to drive the standard multi-turn loop (if supplied), or a small area perimeter loop up to an area of 40m².
- Page 3 QUICK START 1. Fit CLD1-AC to a panel or wall under the counter, away from contact by the system user. Ensure the cables are positioned such that they are not vulnerable to damage and are unlikely to be snagged or disconnected from the unit.
- Page 4 MOUNTING DETAILS Fixing Hole centres 170.0mm apart BLOCK DIAGRAM I/P 1 I/P 1 select line switch I/P 2 drive line I/P 2 40dB CONNECTION (LINE LEVEL INPUT) Balanced Input Connect screen and -ve signal lead together Screen Stereo Source Left Ideally fit the two 10k, ¼W, summing resistors within the body of the jack plug Right...
- Page 5 INSTALLATION Tools You will require the following: Small flat bladed screwdriver Screws, fixings and appropriate tools for mounting CLD1-AC on wall etc. Location The amplifier should be mounted where: It is in close proximity to the loop. it is protected from drips or sprays of water.
- Page 6 If 'LOOP CURRENT LED is illuminated, but there is only a very low or dull field strength. there is significant metal in the desk / counter near the loop consult Ampetronic. If 'LOOP CURRENT' LED is not illuminated - See above.
- Page 7 Meets relevant CE, EMC and safety for speech. standards. Loop Design: IEC 60118-4 AFILS Standard loop coil (supplied) or perimeter loop. See 'Designing Induction Loops Please contact Ampetronic if you need further Handbook' for details. assistance. Consult Ampetronic for advice.
- Page 8 WARRANTY This product carries a five year parts and labour warranty from date of shipment from Ampetronic. To qualify for the five year warranty, the product must be registered at www.ampetronic.co (products/warranty), without which the warranty will be valid for two years only.
