- Page 1 Tablet 10.1” Talius Zircon 1007-3G User’s manual...
- Page 2 Dear customer: Thank you for choosing this Talius product. We hope it will satisfy you totally and will work perfectly for a long time. This tablet with Android ™ operating system allows you to download many applications (Apps) and take full advantage of all the Internet potential (surf the net, send and receive emails, download widgets, etc.), as you would on a laptop or desktop computer.
- Page 3 - Avoid fall or Violent collision of the device, don’t make the TFT display screen were violent tremor, This could cause TFT display screen abnormal or damage. - Please choose the appropriate volume. The use headphones should not be at too high volume.
- Page 4 and design have any change, The information is subject to changes without prior notice. Note that this device uses an operating system license AndroidTM free of charge so there can be substantial differences in the instructions in this manual regarding to those found in your device, as well as differences in the language of the displayed options due to operating system upgrades.
- Page 5 Configuration We recommend that the first time you use the Talius Zircon 1007-3G tablet configure core values such as language, location, date, time, security options and backup found in the Settings section.
-
Page 6: Appearance And Button
1. Appearance and button:... - Page 7 1.1 Touch panel 10,1” Capacitive II touch panel: In the Operation, to click, dragging on the touch panel. 1.2 POWER Start up: Long Press and hold the power button, then it will load the operating system and display the main interface.
- Page 8 1.6 Micro SD - TF card Memory expand through TF-CARD slot: external T-FLASH card. 1.7 Mini USB / OTG Mini USB jack: you can use it to connect the computer for data transmission, charging and external connection USB flash drive. 1.8 RESET Remark: unless unable to shutdown, otherwise don’t use the reset, suggest you to shutdown by normal, or it will easy to damage the machine system.
- Page 9 choose standard adaptor (Input: AC110~240V 50/60Hz Max.180MA.. Output: DC9.0V/2.0A), this device without supply DC charging, USB interface can charge, Choose USB interface to charger. During the charging, the battery icon will scroll. When finished charging, battery icon will become green and stop rolling. In order to prolong the service life of the machine, suggest use out battery power before charge it.
-
Page 10: Connection With Pc
2. Connection with PC Use USB cable to connect device to PC, device will pop up the USB connection window, clic Turn on USB storage to connect to PC Once connected click on the USB icon that appears at the bottom right of the screen: The device enables users to access the screen to activate the USB storage as shown in the following screen:... -
Page 11: Equipment Operation Interface
3. Equipment operation interface 3.1 Main interface describe After startup will enter the main interface: The main interface, can be divided into 5 parts, each of the corners and the main body of the screen. In the main of the screen are housed icons and widgets that the user wants, capable of being moved to the left (2 screens) or right (2 screens) thus has a total of 5 screens that can be added shortcuts, bookmarks and Widgets. - Page 12 Applications are programs that run when the user wishes and stop working when the user exits the application. They can be installed by downloading the application Google Play or through websites that offer Android applications. Widgets are small easy access programs that run continuously, they are located in any of the main screens.
- Page 13 Press and hold an icon 3 seconds after the icon is enlarged, you can drag it anywhere on the interface Delete icons: long press the icons 3 second, drag the icons to the Recycle Bin icon, once it become red, Loosen your hand, after that you can delete icon. You touch the screen keep a time, appear the dialog box”...
-
Page 14: Basic Settings
4. Basic settings Setting: Click setting icons , enter setting interface Wi-Fi: Turns on the Wi-Fi and connects to any Wi-Fi that is within the coverage area. 4.2. 3G: SIM Management Click settings in main menu, choose SIM Management:... - Page 15 Click voice call, choose defaulted SIM card: Click settings in main menu, choose SIM Management, and click video call, choose defaulted SIM card when makes video call. Message: Click settings in main menu, choose SIM Management, click message, choose the defaulted SIM card when sends message:...
- Page 16 Data Connection: Click setting application in main menu, choose SIM management, click data connection, choose the defaulted SIM card. Data Usage: Allows you to disable or limit access to mobile data as well as shows the volume of data downloaded.
- Page 17 4.4: More ..: Enables Airplane mode (used when you are aboard a plane), and advanced settings for both Ethernet networks, creation of VPNs and mobile networks. 4.5 Sound: You can change the default volume of music, games and other media files, notifications and alarms, different melodies for service, enable sound to play and also the sound of the lock screen.
- Page 18 4.8 Battery: Displays current use of the battery. 4.9 Applications: Displays applications downloaded to main memory or the memory card (SD) as well as the currently running applications.
- Page 19 WARNING The manufacturer does not guarantee the compatibility of the version installed on your Android device with all the applications available for this platform. The manufacturer is not liable for damage to the device for any malware, worm, trojan or virus as a result of the installation, implementation, or downloading programs.
- Page 20 Some applications allow to be moved to external memory (SD card) to not fill the entire main memory of the Tablet. 4.10 Accounts and synchronization: Allows you to manage the accounts of different mail applications, Skype etc., Which can be synchronized in real time or not.
- Page 21 which does not mean they are not reliable sources). 4.13. Language and Keyboard: Change the language to use the Tablet, set the automatic spell correction, keyboard type, etc. Select Language: 54 languages are available. Remark: Android system can support 54 kind of language, now main interface just support 14 kind of language.
- Page 22 4.15 Date & time setting: Set date, set time, Select time zone and select date format. 4.16 Accessibility: Different options to facilitate the accessibility of the Tablet. 4.17 Development options: Options for developers. 4.18 About the unit: Displays information about the tablet and the OS.
-
Page 23: Problem Solution
It is possible that some recently installed application isn’t ready to be used in the tablet or it may be consuming too much work memory. Enter the download area in Talius website and look for the original firmware and your model’s guide to restore your Android system from your computer. -
Page 24: Specifications
6. Specifications Display screen: 10.1” IPS, 10 point capacitive touch Resolution: 1280x600 Operation System: Android 5 RAM: DDRIII 1024MB CPU: MTK 8127, Quad core 1.3G (Cortex-A7) GPU: GPU@600MHZ,ARM Mali-450 MP Memory: 16GB/1GB Tarjeta Micro SD (TF): 128MB-32GB USB: USB Host / OTG Bluetooth G-sensor 3D Front camera 0.3MP and rear 2.0 MP... - Page 25 Guarantee and responsibility All Talius products have a 24 month warranty from the invoice date to the end customer, except in the included accessories. The manufacturer guarantees the consumer that its products are free from defects in materials and workmanship at the time of purchase.
