Introduction
Thank you for choosing Geemarc's Clearview Caller Display. You can expect
many years of quality service.
Please read the instructions carefully before use and keep this User Guide for
future reference.
The Clearview stores up to 50 names and numbers in its call log. The display
is extra large, allowing you to read it from across the room, without the need to
walk to the display.
Also it serves as a jumbo LCD clock, which never has to be set, since the
correct time is maintained automatically by the caller ID information.
The Clearview can also hold a directory of 50 names and numbers. If an
incoming number matches a record in the directory, the assigned name (such
as FATHER, OFFICE, etc) will be mapped and shown on the display. You can
build up your own directory.
Installation
Siting your Clearview Caller Display
Position your Clearview Caller Display within 2 metres of a telephone socket.
Do not stand it on carpets or other similar surfaces which might generate fibres.
Do not expose the unit to high temperatures by siting near radiators etc. Keep
the unit dry and do not operate in outdoor conditions.
Do not cover or enclose the machine. Allow a free flow of air to its surfaces.
NOTE: We advise that the unit be placed on a table cloth or similar, as rubber
feet can mark some surfaces.
NOTE: Do not connect the line cord into the telephone socket until after Insert
Batteries section has been completed.
Insert Batteries
Open the battery compartment on the underside of your Clearview Caller
Display by pushing it towards the back edge. You will need 4 x AA alkaline
batteries (NOT INCLUDED).
WARNING - Calls list back up time is 1
minute. Do not remove all batteries or the
stored memories may be lost. To ensure
the memories are not lost users should take
out one battery at a time and replace with a
new one before taking out the next battery.
Change all 4 batteries when the battery low
symbol shows in the display. Unplug
telephone line before changing batteries.
NOTE - The directory memory is non volatile and will not be lost when changing
batteries.
Check your telephone wall socket
Should you not have a modular telephone socket as shown, please contact
your local British Telecom or other Network Operator office.
For moving through the
Directory list, calls list
Dials the
or between
displayed digits/characters when
entering a number
number
DIR
DIAL CLEAR
Allows you to view the
Directory. You can
then Dial the number,
store a new number or
re-enter a number
Helpline - 01707 384438
1. Plug the Clearview Caller Display line cord in to the telephone socket.
2. To connect a telephone to your Clearview Caller Display, plug the telephone
line cord in to the spare socket of the doubler at the end of the Clearview
line cord.
Your Clearview Caller Display receives and displays caller information, which
is transmitted over the BT network and other network providers. The information
will include the date and time the call is received. And in most cases the caller's
phone number.
IMPORTANT: To enable your Clearview Caller Display to display information
transmitted via BT or another network providers you will first have to subscribe
to that networks Caller Display Service.
Your Clearview Caller Display is now ready for use
Used to delete
all of a number
or just part of it
You may select the LCD contrast level (factory setting is level 4) to make the
screen lighter or darker.
1. Press REVIEW FORWARD for 5 seconds, until you see "LCD
CONTRAST".
2. Press REVIEW FORWARD repeatedly to scroll through the 8 contrast
settings.
3. Press STORE to end.
STORE
A 'NEW' icon will appear on the display to tell you that new calls have been
received since you last checked the calls list.
Used to store
Pressing the REVIEW FORWARD/BACKWARD button will display how many
new numbers
new calls you have received and the total number of calls stored.
in the Directory
1. Press the REVIEW FORWARD button to display the most recent call.
2. Press the REVIEW FORWARD button again to display the next most
recent call. Continue pressing until the display shows 'END OF LIST'.
3. Press the FORWARD button at any time to move up the list.
1. Press REVIEW/FORWARD/BACKWARD to view and scroll to the record
in the call log.
2. Press DIAL, the display shows "LIFT HANDSET".
3. Lift handset to continue the call before time out of 10 seconds.
Connect the leads
Caller Display Service
Operation
Setting LCD contrast
Call list
New calls indicator
Reading records in the call list
Dialling a record from call list
