ATTACHABLE SPEAKERS
Instruction Manual
Thank you for purchasing the attachable speakers.
Before using this product, please read this instruction
manual thoroughly so that you can use this product
at its full functionality.
After reading, retain this manual in an easily accessible
location so that you can refer to this manual whenever
you have a problem or trouble during use.
This product is exclusively for use with 46-inch plasma
monitors.
Note
This speaker is of an antimagnetic design. However,
depending on its placement, for example, bringing
the speaker into the vicinity of a monitor other than a
plasma monitor, the speaker may cause irregular
color or other effects. Should this occur, please move
the speaker away from the monitor.
Checking the Package Contents
Make sure the following items are included in the delivery package.
If any of the following items are missing or defective, immediately contact your dealer.
Base (2)
Steel Bracket (4)
Speaker unit (2)
(2.2M×2) (0.3M×2)
Connection Cord
Care and Maintenance
• When the cabinet gets dirty . . .
Wipe with a lint-free, soft, dry cloth.
If the cabinet is seriously stained, soak a cloth in a neutral detergent solution, wring well and, after wiping remove
moisture by wiping with a dry cloth.
If you want to use a chemical cloth for cleaning, read well the caution provided with the chemical cloth product.
• Do not use solvent such as thinner or benzine for cleaning. Otherwise the surface finish will be deteriorated or
the coating will be stripped off.
• To remove dust from the speaker nets, use a brush adapter of a cleaner. Avoid applying the cleaner inlet directly
without using a brush adapter or using a nozzle adapter.
• To prevent damage to the cabinet and speaker nets, do not scratch or hit them with a fingernail or other hard object.
Also do not stab the speaker nets with a sharp object to prevent making a hole.
Do not apply volitle agents such as insecticide on the cabinet or leave a rubber or vinyl product in prolonged
contact with it.
Otherwise the surface finish will be deteriorated or the coating may be stripped off.

Specifications

Maximum input rating:
Dimensions (W×H×D):
M4×10 Screw (8)
Weight:
M4×30 Screw (4)
• The design and specifications are subject to change without notice.
Instruction Manual
Type:
Passive radiator design/2-Way system
Impedance:
8Ω
Rated input:
10 W
15 W
100 × 781 × 76.8 mm (including stand)
100 × 721 × 76.8 mm (without stand)
3.1 kg (one speaker - including stand)
2.1 kg (one speaker - without stand)
