Gateway 30-inch LCD TV
Specifications
Specifications are subject to change without notice or obligation.
Display Panel
Screen size
Aspect ratio
Number of pixels
Pixel pitch
Luminance
Contrast ratio
Response time
Colors
Viewing angle
Power Source
Input voltage
Input current
Power consumption
Stand-by and Power Save
Diagonal 30-inch
16:9 wide
1280 (Horizontal, RGB Trio) × 768 (Vertical) pixels
0.5025 × 0.1675 mm
2
450 cd/m
, at APL13% typical
350:1 typical
25 ms typical (7 ms Tr, 18 ms Tf)
16.7 M colors / 8 bits
±85° Horizontal / ±85° Vertical
90 ~ 240 Vac, 47.5 Hz -63 Hz
2.5 A
165 Watts max.
5 Watts max.
www.gateway.com
Advertisement
Related Manuals for Gateway 30-inch
Summary of Contents for Gateway 30-inch
-
Page 1: Specifications
Gateway 30-inch LCD TV Specifications Specifications are subject to change without notice or obligation. Display Panel Screen size Diagonal 30-inch Aspect ratio 16:9 wide Number of pixels 1280 (Horizontal, RGB Trio) × 768 (Vertical) pixels Pixel pitch 0.5025 × 0.1675 mm... - Page 2 Gateway 30-inch LCD TV Specifications Connector Types Video Signal Type Polarity Amplitude Sync Input impedance Signal (Component) Type Polarity Amplitude Sync RGB Signal Type Polarity Amplitude Frequency RCA jacks for audio, composite video, and component video 4-pin Din S-terminal for S-Video...
- Page 3 800 × 600 800 × 600 832 × 624 1024 × 768 1024 × 768 1280 × 1024 1280 × 768 Gateway 30-inch LCD TV Specifications Signal Assignment RED GND GREEN GND BLUE GND +5 V for DDC Horizontal Vertical...
- Page 4 Gateway 30-inch LCD TV Specifications for Component Mode Resolution 480i, 480p, 720p, 1080i 480i, Faroudja-enhanced Maximum Resolution Up to 1280 × 1024 Dimensions With/Stand Width 28.89 in. (733.8 mm) Height 21.18 in. (538.0 mm) Depth 7.52 in. (191.0 mm) Package Dimensions...
- Page 5 The MTBF is 50,000 hours under operation at 25±5°C (Half luminosity, motion picture) Emissions Requirement Your LCD TV meets the EMI limits in all screen modes as qualified by FCC class B part 15. Many products for Gateway and its subsidiaries are custom engineered by our suppliers to Gateway specifications and may vary from similarly marketed products.
