- Page 1 ® R&S TSME-Z3 Backpack System for TSME Drive Test Scanner Getting Started (?C9ì2) 1519.0994.02 ─ 02...
- Page 2 ® This manual describes the R&S TSME-Z3 Backpack System for TSME Drive Test Scanner (1514.6936.02) © 2014 Rohde & Schwarz GmbH & Co. KG Mühldorfstr. 15, 81671 München, Germany Phone: +49 89 41 29 - 0 Fax: +49 89 41 29 12 164 E-mail: info@rohde-schwarz.com...
- Page 3 Basic Safety Instructions Always read through and comply with the following safety instructions! All plants and locations of the Rohde & Schwarz group of companies make every effort to keep the safety standards of our products up to date and to offer our customers the highest possible degree of safety. Our products and the auxiliary equipment they require are designed, built and tested in accordance with the safety standards that apply in each case.
- Page 4 Basic Safety Instructions Symbol Meaning Symbol Meaning Warning! Hot surface Alternating current (AC) Protective conductor terminal Direct/alternating current (DC/AC) Ground Device fully protected by double (reinforced) insulation Ground terminal EU labeling for batteries and accumulators For additional information, see section "Waste disposal/Environmental protection", item 1.
- Page 5 Basic Safety Instructions Operating states and operating positions The product may be operated only under the operating conditions and in the positions specified by the manufacturer, without the product's ventilation being obstructed. If the manufacturer's specifications are not observed, this can result in electric shock, fire and/or serious personal injury or death. Applicable local or national safety regulations and rules for the prevention of accidents must be observed in all work performed.
- Page 6 Basic Safety Instructions 6. The product may be operated only from TN/TT supply networks fuse-protected with max. 16 A (higher fuse only after consulting with the Rohde & Schwarz group of companies). 7. Do not insert the plug into sockets that are dusty or dirty. Insert the plug firmly and all the way into the socket provided for this purpose.
- Page 7 Basic Safety Instructions 2. Before you move or transport the product, read and observe the section titled "Transport". 3. As with all industrially manufactured goods, the use of substances that induce an allergic reaction (allergens) such as nickel cannot be generally excluded. If you develop an allergic reaction (such as a skin rash, frequent sneezing, red eyes or respiratory difficulties) when using a Rohde &...
- Page 8 Basic Safety Instructions 2. Adjustments, replacement of parts, maintenance and repair may be performed only by electrical experts authorized by Rohde & Schwarz. Only original parts may be used for replacing parts relevant to safety (e.g. power switches, power transformers, fuses). A safety test must always be performed after parts relevant to safety have been replaced (visual inspection, protective conductor test, insulation resistance measurement, leakage current measurement, functional test).
- Page 9 Instrucciones de seguridad elementales Waste disposal/Environmental protection 1. Specially marked equipment has a battery or accumulator that must not be disposed of with unsorted municipal waste, but must be collected separately. It may only be disposed of at a suitable collection point or via a Rohde &...
- Page 10 Instrucciones de seguridad elementales Se parte del uso correcto del producto para los fines definidos si el producto es utilizado conforme a las indicaciones de la correspondiente documentación del producto y dentro del margen de rendimiento definido (ver hoja de datos, documentación, informaciones de seguridad que siguen). El uso del producto hace necesarios conocimientos técnicos y ciertos conocimientos del idioma inglés.
- Page 11 Instrucciones de seguridad elementales Símbolo Significado Símbolo Significado Aviso: Cuidado en el manejo de dispositivos Distintivo de la UE para la eliminación por sensibles a la electrostática (ESD) separado de dispositivos eléctricos y electrónicos Más información en la sección "Eliminación/protección del medio ambiente", punto 2.
- Page 12 Instrucciones de seguridad elementales 1. Si no se convino de otra manera, es para los productos Rohde & Schwarz válido lo que sigue: como posición de funcionamiento se define por principio la posición con el suelo de la caja para abajo, modo de protección IP 2X, uso solamente en estancias interiores, utilización hasta 2000 m sobre el nivel del mar, transporte hasta 4500 m sobre el nivel del mar.
- Page 13 Instrucciones de seguridad elementales 6. Solamente está permitido el funcionamiento en redes de alimentación TN/TT aseguradas con fusibles de 16 A como máximo (utilización de fusibles de mayor amperaje solo previa consulta con el grupo de empresas Rohde & Schwarz). 7.
- Page 14 Instrucciones de seguridad elementales Funcionamiento 1. El uso del producto requiere instrucciones especiales y una alta concentración durante el manejo. Debe asegurarse que las personas que manejen el producto estén a la altura de los requerimientos necesarios en cuanto a aptitudes físicas, psíquicas y emocionales, ya que de otra manera no se pueden excluir lesiones o daños de objetos.
- Page 15 Instrucciones de seguridad elementales Reparación y mantenimiento 1. El producto solamente debe ser abierto por personal especializado con autorización para ello. Antes de manipular el producto o abrirlo, es obligatorio desconectarlo de la tensión de alimentación, para evitar toda posibilidad de choque eléctrico. 2.
- Page 16 Instrucciones de seguridad elementales 2. Las asas instaladas en los productos sirven solamente de ayuda para el transporte del producto por personas. Por eso no está permitido utilizar las asas para la sujeción en o sobre medios de transporte como p. ej. grúas, carretillas elevadoras de horquilla, carros etc. Es responsabilidad suya fijar los productos de manera segura a los medios de transporte o elevación.
- Page 17 Quality management Certified Quality System ISO 9001 and environmental Certified Environmental System management ISO 14001 Sehr geehrter Kunde, Dear customer, Cher client, Sie haben sich für den Kauf You have decided to buy a Vous avez choisi d’acheter un eines Rohde & Schwarz Produk- Rohde &...
- Page 18 Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support Centers. A team of highly qualified engineers provides telephone support and will work with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
- Page 19 The Rohde & Schwarz drive test solution also supports indoor measurements. Particularly scanner measurements with R&S ROMES and R&S TSME scanners require a convenient hardware setup. The R&S TSME-Z3 backpack provides such a solution which allows for indoor measurements of coverage and interfer- ence in GSM, WCDMA, LTE, CDMA2000, EVDO, TD-SCDMA, WiMAX and TETRA networks.
- Page 20 The R&S TSME-Z3 backpack consists of: ● A frame based on the HPRC 3500 backpack, with a carrying handle, ergo- nomic shoulder straps, and a waistband ●...
- Page 21 The R&S TSME antennas (1 x RF, 1 x GPS) can be stored inside the backpack, or alternatively lead through the side wall for external operation. Fig. 2-1: Fully equipped R&S TSME-Z3 backpack System Unit The system unit contains the following connectors and interface elements: Fig.
- Page 22 ● Battery-powered operation The R&S TSME-Z3 backpack can be equipped with up to two 91 Wh batteries (accessory item TSME-Z3B1). The batteries can be hot-swapped, i.e. the measurement can continue while one empty battery is exchanged by a charged one.
- Page 23 ("BAT1/2" connectors), and are protected by a fuse. When power is supplied to the system unit from the batteries, the "PWR" LED lights blue. Fig. 2-4: R&S TSME-Z3 system unit and two battery packs Battery operation can be used in addition to a default external DC power source to provide an interruption-free power supply.
- Page 24 Scanner and Mobile Device Configuration Scanner and Mobile Device Configuration The R&S TSME-Z3 can be configured to support both scanner and mobile meas- urements. The backpack has three mounting positions. Each position can hold one of the following (as shown in...
- Page 25 ● TSME-Z3M1: R&S TSME-Z3 mounting kit for 1 mobile device (device-spe- cific) The R&S TSME-Z3 is shipped along with the ordered mounting material. It is the responsibility of the customer to configure and mount the equipment into the backpack after delivery according to the instructions in this docu- ment.
- Page 26 R&S TSME-Z3 data sheet and the general safety instructions to avoid damage to the devices. Two fans are built in in the R&S TSME-Z3 backpack. Ensure that all fan openings on both sides of the backpack are unobstructed and the airflow perforations are unimpeded.
- Page 27 ® Preparing for Use R&S TSME-Z3 Setting up the System a) Using 4 screws, screw the connecting metal plate of the R&S TSME mounting set to the bottom of the upper R&S TSME. b) Lay the upper R&S TSME on the lower R&S TSME so that the connectors of both devices are on the same side.
- Page 28 ® Preparing for Use R&S TSME-Z3 Setting up the System 2. Using 4 screws, screw the base metal plate of the mounting set to the bottom of the (lower) R&S TSME so that the hole in the metal plate fits over the fan output of the R&S TSME.
- Page 29 6. Connect each R&S TSME to the system unit using a LAN cable and a power supply cable, which is provided with the mounting set. Fig. 3-1: R&S TSME-Z3: cable connections 7. Connect the control PC for the R&S TSME(s) to the "Host" connector on the system unit.
- Page 30 ® Preparing for Use R&S TSME-Z3 Setting up the System To mount the antenna holder to the R&S TSME ► The blue antenna holder is connected to the side panel of the R&S TSME using two screws. Fasten one screw in the fourth hole from the left, and the other screw in the fourth hole from the right on the R&S TSME.
- Page 31 ® Preparing for Use R&S TSME-Z3 Setting up the System Fig. 3-2: Position of the velcro strip to fasten the GPS antenna to the system unit 1. Fasten one side of the velcro strip to the front of the system unit as shown in figure 3-2.
- Page 32 Completing the Pre-Configured Measurement System The R&S TSME-Z3 is pre-configured in the factory according to the user's specifi- cations. Thus, you only have to connect the additional equipment to complete the measurement setup for scanning or testing mobile devices.
- Page 33 Supply", on page 6, either an external DC power supply can be used for the measurement system, or optional rechargeable batteries that can be inserted in the R&S TSME-Z3. Risk of instrument damage due to excess power supply Do not exceed the supported input power supply of 10-18 V DC to avoid instrument damage.
- Page 34 LED signals, an acoustic signal, or both. The fol- lowing sections provide information on the possible causes for these warnings and some recommendations how to solve common problems when using the R&S TSME-Z3. General troubleshooting procedure The general troubleshooting procedure is: 1.
- Page 35 ® Troubleshooting R&S TSME-Z3 Status LEDs 3. Switch the system unit back on. To check the USB connectors 1. Connect a control PC to the "Host" or "CPU" connectors on the system unit. 2. Connect an external device to one of the USB connectors on the system unit.
- Page 36 ® Troubleshooting R&S TSME-Z3 Acoustic Signals Color Meaning Possible causes/ recommendations Red, blinking Critical temperature Check the outlets of the cooling fans in the back- (+acoustic pack and make sure they are unobstructed. signal) Check the connectors of the built-in cooling fans to the system unit and make sure they are work- ing.
