STEAM PRESS

INSTRUCTION MANUAL

CONTENTS

Features of the Steam Press.........1

Safety Reminders.......................2

Parts Identification..................3-4

Steam Press Operation.............5-9

Cleaning the Steam Press...........10

Suggestions for Success.............11

Use of the Pressing Cushion.......12

Techniques for Pressing........13-14

Troubleshooting...................15-16

Please read this manual carefully before using and keep it for future reference.

Table of Contents

Need help?

Do you have a question about the PSP990 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steam Press PSP990

Page 1: Table Of Contents
STEAM PRESS INSTRUCTION MANUAL CONTENTS Features of the Steam Press..1 Safety Reminders.......2 Parts Identification....3-4 Steam Press Operation.....5-9 Cleaning the Steam Press...10 Suggestions for Success.....11 Use of the Pressing Cushion..12 Techniques for Pressing..13-14 Troubleshooting....15-16 Please read this manual carefully before using and keep it for future reference.
Page 2: Features Of The Steam Press
Features of the Steam Press Your Steam Press provides clean, Professional results every time! The pressing surface is seven times larger than most hand-held irons Can reduce ironing time up to 50% Multiple dry and steam settings; burst setting removes stubborn wrinkles...
Page 3: Safety Reminders
PARTS, HOT WATER or STEAM. .USE DISTILLED WATER in the appliance . DO NOT use perfumed or products containing alcohol in the appliance. THIS UNIT IS FOR HOUSEHOLD USE ONLY SAVE THESE INSTRUCTIONS Page 2 Steam Press Instruction Manual...
Page 4: Parts Identification
Slide the tank forward for a better view. Plate and Ironing Board. Use the Locking Knob to carry or Store the Steam Press. 3.The Steam Burst Buttons on either end of the handle grip produce a burst of steam when pressed.
Page 5 14.A Water Container is used for filling and emptying the Water Tank. 15.The Ironing Board Cover is removable and washable for extended use. Automatic features of the Steam Press include Auto Shut-Off and Auto Wake-Up. These multiple function safety features turn off electric power to the...
Page 6: Steam Press Operation
Using the Water Container, slowly pour the water into the Water Tank Fill Holes ( C ). c. Be careful to avoid spilling water onto the Steam press when filling. d. Slide the Water Tank back into its recessed position.
Page 7 IMPORTANT NOTE: You may find it more efficient to arrange your fabrics from those requiring the lowest setting to those requiring the highest setting and proceed accordingly. This will avoid any unnecessary delay or wait for the Pressing Plate to cool. Page 6 Steam Press Instruction Manual...
Page 8 IMPORTANT NOTE: The Steam Burst function can only be used when the Steam Ready Light is on AND the steam press is in an opened position. Do not use the Steam Burst function when the steam press is closed, or you may damage the unit.
Page 9 Grasp the handle of the Pressing Plate (A) and lower it onto the Ironing Board( C ),capturing the garment between the two halves of the Steam Press. For light duty pressing, simply lowering the handle and allowing the Pressing Plate to rest on the Ironing Board will be sufficient.
Page 10 Turn the ON/OFF switch to the OFF position. The red Power Indicator Light will go out. Disconnect the plug from the outlet. b .Wait for the Steam Press to cool completely, for at least 30 minutes before draining. c. Water left in the reservoir will not drip out if the machine is stored in an...
Page 11: Cleaning The Steam Press
DO NOT use any abrasives on the Pressing Plate. c. The Ironing Board Cover is removable for normal washing, You can rinse the Ironing Board Cover with mild detergent and warm water. Page 10 Steam Press Instruction Manual...
Page 12: Suggestions For Success
For the most stubborn or heavy gauge fabrics, place a damp cloth over the area to be pressed, Press the garment normally for a few seconds, then raise the Pressing Plate and allow the steam to escape, Repeat the procedure until the fabric is dry. Page 11 Steam Press Instruction Manual...
Page 13: Use Of The Pressing Cushion
Some garments have been constructed with details, such as darts. Curved seams and shoulder pads, which are not intended to be pressed flat A Pressing Cushion is supplied with your Steam Press for use with these areas. a. Use the cushion whenever pressing areas where no creases are desired or to shape tailored garments.
Page 14: Techniques For Pressing
Place the shoulder yoke ( E ) flat on the Ironing Board, Press to remove the crease. g. Place the collar ( F ) right side up on the Ironing Board and press. Page 13 Steam Press Instruction Manual...
Page 15 Page 14 Steam Press Instruction Manual...
Page 16: Troubleshooting
TROUBLE SHOOTING THE STEAM PRESS Below is a chart detailing the most common problems, their causes and solutions. Before shipping any appliance to a service center please check to make sure that the solution is not listed here: CAUSE SOLUTION...
Page 17 Controls have not been properly set. wise to a higher temperature. Wait for the Steam Ready light to come on. The Steam Press is in the open position. Close the Steam Press to use the control. Temperature Control Dial has not been Water drips from the Pressing Plate.
Page 18 Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as house- hold waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
