- Page 1 OWNER’S MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. 32LS5700 32LM6200 42LM6210 42LS5700 42LM6200 47LM6210 47LS5700 47LM6200 55LM6210 60LS5700 55LM6200 65LM6210 65LM6200 www.lg.com P/NO : MFL67372307 (1210-REV05)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. WARNING/CAUTION Heed all warnings. Follow all instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN Do not use this apparatus near water. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Protect the power cord from being walked on Keep the packing anti-moisture material or or pinched particularly at plugs, convenience vinyl packing out of the reach of children. receptacles, and the point where they exit Anti-moisture material is harmful if from the apparatus.
- Page 4 Do not attempt to modify this product in any as gasoline or candles, or expose the TV to way without written authorization from LG direct air conditioning. Electronics. Unauthorized modification could void the user’s authority to operate this product.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS Cleaning Dot Defect When cleaning, unplug the power cord and The Plasma or LCD panel is a high wipe gently with a soft cloth to prevent technology product with resolution of two scratching. Do not spray water or other million to six million pixels.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS DISPOSAL (Hg lamp only used in LCD TVs) The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority.
-
Page 7: Viewing 3D Imaging (For 3D Models)
IMPORTANT SAFETY INSTRUCTIONS Viewing 3D Imaging (For 3D models) WARNING Viewing Environment Viewing Time - When watching 3D contents, take 5 - 15 minute breaks every hour. Viewing 3D contents for a long period of time may cause headache, dizziness, fatigue or eye strain. Those that have a photosensitive seizure or chronic illness Some users may experience a seizure or other abnormal symptoms when they are exposed to a flashing light or particular pattern from 3D contents. - Page 8 Cautions when using the 3D glasses Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly. Do not use 3D glasses instead of your normal glasses, sunglasses or protective goggles.
-
Page 9: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to ‘opensource@lge.com’. -
Page 10: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS REMOTE CONTROL Viewing 3D Imaging (For 3D models) WATCHING TV LICENSES Turning the TV on for the first time OPEN SOURCE SOFTWARE NOTICE USING THE USER GUIdE TABLE OF CONTENTS SPECIFICATIONS INSTALLATION PROCEdURE MAINTENANCE Cleaning Your TV... -
Page 11: Installation Procedure
INSTALATION PROCEDURE / ASSEMBLING AND PREPARING INSTALLATION PROCEdURE Open the package and make sure all the accessories are included. Attach the stand to the TV set. Connect an external device to the TV set. Make sure the network connection is available. You can use the TV network functions only when the network connection is made. - Page 12 ASSEMBLING AND PREPARING (For LM6200, LM6210 series) Remote control, Cinema 3D glasses Owner’s manual Batteries (AAA) The number of 3D glasses (See p.29) may differ depending on the model or country. Stand body Stand base Stand screws 8 EA, M4 x 20 (See p.16) (See p.16) (See p.16)
-
Page 13: Optional Extras
ASSEMBLING AND PREPARING Optional Extras Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. The model name or design may be changed manufacturer’s circumstances or policies. AN-MR300 AG-F*** AN-WF100... -
Page 14: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Screen Remote control and intelligent sensors Power indicator Speakers Touch buttons SETTINGS INPUT Touch Button Description v / ^ Scrolls through the saved channels. - / + Adjusts the volume level. OK ⊙ Selects the highlighted menu option or confirms an input. SETTINGS Accesses the main menus, or saves your input and exits the menus. -
Page 15: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When transporting a large TV, there should be at least 2 people. When transporting the TV by hand, hold the When moving or lifting the TV, read the following TV as shown in the following illustration. to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. -
Page 16: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Put your TV on a pedestal stand and mount the TV on a table or wall. Attaching the stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. M4 x 20 Stand Body Front... -
Page 17: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a table (Depending on model) Lift and tilt the TV into its upright position on a Fix the TV to a table to prevent from tilting table. forward, damage, and potential injury. To secure the TV to a table, insert and tighten the - Leave a 10 cm (minimum) space from the supplied screw on the rear of the stand. -
Page 18: Tidying Cables
TV. materials, please contact qualified personnel. Connect the eye-bolts and wall brackets tightly We recommend that you use an LG brand wall with a sturdy rope. mount when mounting the TV to a wall. - Page 19 TV, insert the wall mount inner spacers into the TV wall mount holes to move your TV in vertical angle. Please make sure not to use the spacers for LG wall mounting bracket. Standard screw Number of screws...
-
Page 20: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. -
Page 21: Connecting To A Hd Receiver, Dvd, Or Vcr Player
MAKING CONNECTIONS Connecting to a HD receiver, DVD, or VCR player Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration. -
Page 22: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI Connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. -
Page 23: Component Connection
MAKING CONNECTIONS Component Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration. NOTE If cables are installed incorrectly, it could case the image to display in black and white or with distorted color. -
Page 24: Composite Connection
MAKING CONNECTIONS Composite Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE Check to ensure the cables are matched with the corresponding color connection. YELLOW (Use the composite video cable provided.) (*Not Provided) -
Page 25: Connecting To A Pc
MAKING CONNECTIONS Connecting to a PC NOTE It is recommended to use the HDMI connection for the best image quality. Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use. In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. - Page 26 MAKING CONNECTIONS Method B: dVI to HdMI Connection (*Not Provided) (RGB/HDMI-PC) (RGB/HDMI-PC) AUDIO AUDIO (RGB/HDMI-PC) (RGB/HDMI-PC) AUDIO AUDIO AUDIO OUT DVI OUT (*Not Provided) AUDIO OUT DVI OUT Method C: RGB Connection (RGB/HDMI-PC) (PC) (PC) (RGB/HDMI-PC) AUDIO AUDIO (RGB/HDMI-PC) (PC) (PC) (RGB/HDMI-PC) AUDIO...
-
Page 27: Connecting To An Audio System
MAKING CONNECTIONS Connecting to an Audio System You may use an optional external audio system instead of the built-in speaker. NOTE If you use an optional external audio device instead of the built-in speaker, set the TV speaker feature to off. Digital Optical Audio Connection Transmits a digital audio signal from the TV to an external device. -
Page 28: Connecting To A Usb
MAKING CONNECTIONS Connecting to a USB Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card reader to the TV and access the Smart Share menu to use various multimedia files. NOTE To use time machine function, make sure that it is connected to the USB IN 1 Time Machine Ready port. -
Page 29: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. - Page 30 REMOTE CONTROL SETTINGS Accesses the main menu. RATIO INPUT HOME Accesses the Home menu. MY APPS Shows the list of Apps. Q.MENU Accesses the quick menu. Navigation buttons (up/down/left/right) Scrolls through menus or options. OK ꔉ Selects menus or options and confirms your input. Q.VIEW ꕣ...
- Page 31 REMOTE CONTROL For LM6200, LM6210 series (POWER) Turns the TV on or off. (User Guide) RATIO INPUT Sees user-guide. RATIO Resizes an image. INPUT Rotates through inputs. Also switches the TV on from standby. Returns to the last TV channel. Number button Q.VIEW Enters numbers.
- Page 32 REMOTE CONTROL SETTINGS Accesses the main menu. RATIO INPUT HOME Accesses the Home menu. MY APPS Shows the list of Apps. Q.MENU Accesses the quick menu. Navigation buttons (up/down/left/right) Scrolls through menus or options. OK ꔉ Selects menus or options and confirms your input. Q.VIEW ꕣ...
-
Page 33: Watching Tv
WATCHING TV WATCHING TV NOTE Select Home when prompted. Store* mode puts the TV in demo mode. If you select Store, the any customized Turning the TV on for the first settings will switch back to the default time settings of Store in 5 minutes. The Standby light feature is disabled in Store Demo mode. -
Page 34: Using The User Guide
Voice Search ✎ Only the voice search adopted model can support this Language OPTION setting. Press HOME button to access the HOME LG SMART Function menu. Advabced Function Select User Guide and press the OK button. Information Try Now Zoom In Close HOME ... -
Page 35: Specifications
Current Value / Power consumption 1.2 A / 120 W 2.7 A / 270 W 42LM6200 (42LM6200-SA) 32LM6200 MODELS (32LM6200-SA) 42LM6210 (42LM6210-SA) With stand 746.0 x 528.0 x 204.0 mm 979.0 x 660.0 x 269.0 mm Dimensions (W x H x D) Without stand 746.0 x 462.0 x 35.5 mm... - Page 36 SPECIFICATIONS 47LM6200 55LM6200 (47LM6200-SA) (55LM6200-SA) MODELS 47LM6210 55LM6210 (47LM6210-SA) (55LM6210-SA) With stand 1089.0 x 722.0 x 269.0 mm 1263.0 x 822.0 x 315.0 mm Dimensions (W x H x D) Without stand 1089.0 x 655.0 x 35.5 mm 1263.0 x 754.0 x 35.5 mm With stand 18.1 kg 25.5 kg...
- Page 37 SPECIFICATIONS 3D supported mode (For 3D TV) Video, which is input as below media contents is switched into the 3D screen automatically. The method for 3D digital broadcast may differ depending on the signal environment. If video is not switched automatically into 3D, manually convert the settings to view 3D images. 3D supported mode automatically Horizontal Vertical...
- Page 38 SPECIFICATIONS For models supporting WiDi, you can set the 3D mode in the same way as in RGB (PC) mode. 3D supported mode manually Horizontal Vertical Input Signal Playable 3D video format Frequency (kHz) Frequency (Hz) 37.50 2D to 3D, Side by Side(Half), Top & Bottom, 720p Single Frame Sequential 45.00...
- Page 39 SPECIFICATIONS HDMI (DTV) supported mode Wireless LAN module (WN8122E) specification (For LM6210 series) Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) Standard IEEE802.11a/b/g/n 31.47 59.94 720 x 480p 2400 to 2483.5 MHz 31.50 60.00 Frequency Range 5150 to 5250 MHz 31.25 50.00 720 x 576p 5725 to 5850 MHz...
-
Page 40: Maintenance
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning Your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended or unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. - Page 42 The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service. MODEL SERIAL...
