- Page 1 USER MANUAL HIGHDROGEN AGE Hydrogen Water Generator Pimp your drink!
- Page 2 Hydrogen Basics „I run on Hydrogen“. To see Hydrogen cars, out of which no emissions are emitted and only clear water drips out, is still seldom in our smog-laden cities. Yet there is no doubt that Hydrogen gas presents the most interesting form of alternative energies of the future. For 1 kg of Hydrogen brings 33,33 kWh/kg onto the road.
- Page 3 What is a Hydrogen Water Generator? For many years it was irrefutable that activated water keeps its negative redox potential and therefor its electron abundance for just a few hours or days. Yet when it was discovered, in the 21c., that dissolved Hydrogen is the deciding factor for the antioxidant effect, an industry was developed that presses hydrogen under high pressure into multilayered water bags, where the positive qualities were able to be kept for some months.
- Page 4 Hydrogen water - the new benchmark for drinking Previously only the was measured to determine the antioxidant effect of activated water. Yet this is very inaccurate and a relative value, because the ORP is influenced not only by the dissolved hydrogen, but also from the different ORPs of the different materials dissolved in the water, e.g.
- Page 5 Always fresh hydrogen - free water choice! With a device for on the move it is clear: It may only be filled with perfect drinking water or mineral water. Therefor, the HIGHDROGEN AGE is designed so that the user is not dependent on one type of water, which is what happens with a stationary water ionizer.
-
Page 6: Chapter Overview
Chapter overview • 07 – General safety instructions • 08 – Scope of delivery • 09 – Removing the protective moisture cap • 10 – Charging mode • 11 – Display • 12 – Operating mode • 13 – Optional accessory: Hydrogen measuring drops •... -
Page 7: General Safety Instructions
General safety instructions ✓ Do not place the device in moist or ✓ Only use the device once you have read and polluted rooms. understood the instruction manual. ✓ Do not place the device outdoors. ✓ Before switching the device on, the water ✓... -
Page 8: Scope Of Delivery
Scope of delivery Screw cap Bottle adapter Cleaning powder (Citric acid) Charger + cable Pressure container Production unit Display + operating button... - Page 9 Removing the protective moisture cap Setting the electrode free, eliminating odor 1. Unscrew the pressure container from the production unit 2. Remove the protective cap above the cathode grid and keep it in case you do not use the device in 2 days. The cathode should always be kept moist with a bit of water. 3.
-
Page 10: Charging Mode
Charging mode 1. Place the device on a dry, flat surface. 2. Open the rubber flap over the charging socket. 3. Plug the USB cable into the charging plug and the other end into the production unit. Then plug the charger into a 220 V plug. 4. - Page 11 Display Hydrogen production in process Announcement volume Battery indicator USB cable connected Operating mode 1 or 2 Power indicator Action button When the device is idle the display is not illuminated By pressing the action button once the display will turn on.
-
Page 12: Operating Mode
Operating mode Attention: Only use still water! No carbonic acid in the water. Wether you fill the pressure container or use a bottle (a) with the bottle adapter with water you would like to electrolyse: Before switching the device on, you should have at least 0,1 Liter of drinking water in the container. - Page 13 Optional accessory: Hydrogen measuring drops Testing the amount of molecular hydrogen is carried out immediately after production with the optional H2 Blue Kit. ® A water sample of 6 ml is filled carefully into the measuring cup and one drop of the blue measuring liquid is added.
- Page 14 Increasing the hydrogen content Not only through multiple production cycles in a row, (maximum 30 minutes at a time), can the achievable hydrogen content be increased. Namely, what reduces the power of the hydrogen-water generator is the gas content of the water before production. These are mainly the atmospheric gases; oxygen, nitrogen and carbon dioxide, which according to Henry's Law always dissolve in proportion to the composition of the atmosphere in the water.
-
Page 15: Interior Cleaning
Interior cleaning The inside of the pressure container and the grid patterned negative electrode, which produces the hydrogen, must be cleaned if you have visible limescale traces with 1 teaspoon of citric acid dissolved in warm water. Allow the citric acid solution to work for 1 hour. - Page 16 Exterior cleaning / storage. Technical details Wipe the outside of the device with a moist, soft cloth. You can also remove heavy dirt stains from the inside of the pressure container if you half fill it with warm water and shake vigorously.
- Page 17 Hydrogen water - not just for drinking! • As opposed to alkaline activated water from a classic water ionizer, the pH value of the treated water remains the same. Hydrogen water can also be slightly acidic. • Drink up to 0,3 l of water per 10 kg of bodyweight daily. With high temperatures and / or strenuous physical activity respectively more.
-
Page 18: Troubleshooting
Troubleshooting Problem Cause analysis Solution Generator not working Battery charged? Connect to the charger • (no bubble production) Foreign object in the pressure Clean interior • container? LED not shining • Battery charged? Connect to the charger Does not charge Check plug and cable If the charger is defect inform your dealer. - Page 19 Legal reference - Disclaimer An instruction book by Aquavolta UG (limited liability). Georgenstr. 110, 80798 Munich. Author and copyright: Karl Heinz Asenbaum. Email: aquavolta@web.de IMPORTANT NOTES This instruction book contains important information. Read the whole book and if necessary repeatedly. Do not throw it away in case you wish to read it again! You can and should ask questions and queries.
-
Page 20: Service And Guarantee
This applies, in particular, to commitments which have surpassed the two-year legal warranty. All guarantee assurances will be listed on your dealers purchase receipt (invoice). Manufacturer (main importer and service center): München, Aquacentrum. Owner: Yasin Akgün 05.04.2017 Fraunhoferstrasse 13, 80469 Munich, Germany www.aquacentrum.de www.aquacentrum.com...
