Exos ST6000NM0245 Product Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

7E8 SAS Product Manual

Standard 512N models

ST6000NM0245

100804239, Rev. A

October 2017

Table of Contents

Need help?

Do you have a question about the ST6000NM0245 and is the answer not in the manual?

Questions and answers

Summary of Contents for Exos ST6000NM0245

Page 1 7E8 SAS Product Manual Standard 512N models ST6000NM0245 100804239, Rev. A October 2017...
Page 2 Document Revision History Revision Date Pages affected and Description of changes Rev. A 10/09/2017 Initial release. © 2017 Seagate Technology LLC. All rights reserved. Publication number: 100804239, Rev. A October 2017 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice, Raid Rebuild and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
Page 3: Table Of Contents
Prefetch operation ..............16 Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 4 Mechanical specifications ..............32 Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 5 Additional information ..............52 Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 7: Scope
This manual describes Seagate® Exos™ 7E8 SAS (Serial Attached SCSI) disk drives. Exos 7E8 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives.
Page 8: Applicable Standards And Reference Documentation
If these models have the RCM marking, they comply with the Australia/New Zealand Standard AS/NZ CISPR32 and meet the Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication and Media Authority (ACMA). Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 9: Canada Ices-003
Federal Communications Commission: How to Identify and Resolve Radio-Television Interference Problems. This booklet is available from the Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 10: Environmental Protection
GB/T26572. X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。 X：Indicates that the hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement of GB/T26572. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 11: Taiwan Requirements - Taiwan Rohs
INCITS 536 Zone Block Commands (ZBC) Specification for Acoustic Test Requirement and Procedures Seagate part number: 30553-001 In case of conflict between this document and any referenced document, this document takes precedence. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 12: General Description
Exos 7E8 drives are random access storage devices designed to support the Serial Attached SCSI Protocol as described in the ANSI specifications, this document, and the SAS Interface Manual (part number 100293071) which describes the general interface characteristics of this drive. Exos 7E8 drives are classified as intelligent peripherals and provide level 2 conformance (highest level) with the ANSI SCSI-1 standard.
Page 13: Standard Features
Standard features Exos 7E8 drives have the following standard features: • 128 - deep task set (queue) • 256MB data buffer (see Section 4.4). • 3.0 / 6.0/12.0 Gb Serial Attached SCSI (SAS) interface • Drive Self Test (DST) • Embedded servo design •...
Page 14: Formatted Capacities
Users planning single unit distribution should specify this option. • The Safety and Regulatory Agency Specifications, part number 75789512, is usually included with each standard OEM drive shipped, but extra cop- ies may be ordered. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 15: Performance Characteristics
Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Exos 7E8 drives. Internal drive characteristics Drive capacity 6TB models (formatted, rounded off value) Read/write data heads Bytes/track 2,179,072 Bytes (average, rounded off values) Bytes/surface 1,300,000 MB (unformatted, rounded off values)
Page 16: Start/Stop Time
Sending a size specification using the Mode Select command (bytes 14 and 15) does not set up a new segment size. If the STRICT bit in Mode page 00h (byte 2, bit 1) is set to one, the drive responds as it does for any attempt to change an unchangeable parameter. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 17: Caching Write Data
When prefetch (read look-ahead) is enabled (enabled by DRA = 0), the drive enables prefetch of contiguous blocks from the disk when it senses that a prefetch hit will likely occur. The drive disables prefetch when it decides that a prefetch hit is not likely to occur. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 18: Reliability Specifications
An interface error is defined as a failure of the receiver on a port to recover the data as transmitted by the device port connected to the receiver. The error may be detected as a running disparity error, illegal code, loss of word sync, or CRC error. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 19: Reliability And Service
Reliability and service Users can enhance the reliability of Exos 7E8 disk drives by ensuring that the drive receives adequate cooling. Section 6.0 provides temperature measurements and other information that may be used to enhance the service life of the drive. Section 8.2 provides recommended air-flow information.
Page 20 (not to exceed zero) whenever the error rate is acceptable. If the counter continually increments such that it reaches the predictive threshold, a predictive failure is signaled. This counter is referred to as the Failure History Counter. There is a separate Failure History Counter for each attribute. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 21: Thermal Monitor
5.2.4 Thermal monitor Exos 7E8 drives implement a temperature warning system which: Signals the host if the temperature exceeds a value which would threaten the drive. Saves a S.M.A.R.T. data frame on the drive which exceeds the threatening temperature value.
Page 22 The integrity of the media is checked through a read/verify scan of the media. Motor functionality is tested by default as a part of these tests. The anticipated length of the Extended test is reported through the Control Mode page. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 23: Product Warranty
Seagate customer service centers are the only facilities authorized to service Seagate drives. Seagate does not sanction any third-party repair facilities. Any unauthorized repair or tampering with the factory seal voids the warranty. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 24: Physical/Electrical Specifications
Start/Stop Cycle Counter Log Page reports (log page 0x0E) • Specified and accumulated Start/Stops and Load/Unload cycles Power Condition Transitions Log Page reports (log page 0x1A, subpage 0x00) • Accumulated transitions to Active, Idle_A, Idle_B, Idle_C, Standby_Y, Standby_Z Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 25: Ac Power Requirements
See paragraph 6.3.1, "Conducted noise immunity." Specified voltage tolerance includes ripple, noise, and transient response. During idle, the drive heads are relocated every 60 seconds to a random location within the band from three-quarters to maximum track. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 26: Conducted Noise Immunity
450 mV pp from 8 KHz to 20 KHz. 250 mV pp from 20 KHz to 5 MHz. 6.3.2 Power sequencing The drive does not require power sequencing. The drive protects against inadvertent writing during power-up and down. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 27: Current Profiles
6.3.3 Current profiles The +12V (top) and +5V (bottom) current profiles for the Exos 7E8 drives are shown below. Figure 1. 6TB model current profiles. Note All times and currents are typical. See Table 3 for maximum current requirements. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 28: Power Dissipation
+5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 2. 6TB models (12Gb) DC current and power vs. input/output operations per second Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 29: Environmental Limits
Non-operating 5% to 95% non-condensing relative humidity. 6.5.3 Effective altitude (sea level) a. Operating –1000 to +10,000 feet (–304.8 to +3048 meters) b. Non-operating –1000 to +40,000 feet (–304.8 to +12,192 meters) Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 30: Shock And Vibration
Disk drives shipped as loose load (not palletized) general freight will be packaged to withstand drops from heights as defined in the table below. For additional details refer to Seagate specifications 30190-001 (under 100 lbs/45 kg) or 30191-001 (over 100 lbs/ 45 Kg). Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 31 48 in (1070 mm) against a concrete floor or equivalent. Figure 4. Recommended mounting Note Image is for reference only, may not represent actual drive. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 32: Acoustics
ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. 6.5.8 Electromagnetic susceptibility See Section 2.4. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 33: Mechanical Specifications
26.11 MM .142±.015 2 2.000 C L OF DRIVE Figure 5. Mounting configuration dimensions (6TB models) Note The image is for mechanical dimension reference only and may not represent the actual drive. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 34: Defect And Error Management
When the RC bit is one, reallocations are disabled even if the ARRE or AWRE bits are one. The drive will still perform data recovery actions within the limits defined by the Read Retry Count, Write Retry Count, and Recovery Time Limit parameters. However, the drive does not report any unrecovered errors. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 35: Sas System Errors
Pre-Scan period. In the event that the drive is in a high transaction traffic environment and is unable to complete a BMS scan within 24 power on hours BMS will disable Pre-Scan to restore full performance to the system. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 36: Deferred Auto-Reallocation
The Standard Inquiry provides a bit to indicate if PI is support by the drive. Vital Product Descriptor (VPD) page 0x86 provides bits to indicate the PI Types supported and which PI fields the drive supports checking. Note For further details with respect to PI, please refer to SCSI Block Commands - 3 (SBC-3) Draft Standard documentation. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 37: Installation
Installation Exos 7E8 disk drive installation is a plug-and-play process. There are no jumpers, switches, or terminators on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which users need to mount the drive.
Page 38: Cooling
Above unit Under unit Note. Air flows in the direction shown or in reverse direction (side to side) Figure 7. Air flow Note Image is for reference only, may not represent actual drive. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 39: Drive Mounting
Increased radiated emissions may result if users do not provide the maximum surface area ground connection between system ground and drive ground. This is the system designer’s and integrator’s responsibility. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 40: Interface Requirements
Invalid logical unit Dual port support Exos 7E8 SAS drives have two independent ports. These ports may be connected in the same or different SCSI domains. Each drive port has a unique SAS address. The two ports have the capability of independent port clocking (e.g. both ports can run at 12Gb/s or the first port can run at 6Gb/s while the second port runs at 3Gb/s.) The supported link rates are 3.0, 6.0, or 12.0 Gb/s.
Page 41: Scsi Commands Supported
SCSI commands supported Table 7 lists the SCSI commands supported by Exos 7E8 drives. Table 7 Supported commands Command name Command code Supported Change Definition Compare Copy Copy and Verify Format Unit [1] [5] DCRT bit supported DPRY bit supported...
Page 42 Read (10) DPO bit supported FUA bit supported Read (12) Read (16) Read (32) 7Fh/0009h Read Buffer (modes 0, 2, 3, Ah and Bh supported) Y (non-SED drives only) Read Capacity (10) Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 43 Send Diagnostics Supported Diagnostics pages (00h) Translate page (40h) Set Limits Start Unit/Stop Unit (spindle ceases rotating) Synchronize Cache Synchronize Cache (16) Test Unit Ready Verify (10) BYTCHK bit Verify (12) Verify (16) Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 44 XDWrite XPWrite Exos 7E8 drives can format to 512, 520 or 528 bytes per logical block. Warning. Power loss during flash programming can result in firmware corruption. This usually makes the drive inoperable. Reference Mode Sense command 1Ah for mode pages supported.
Page 45: Inquiry Data
Eight ASCII digits representing the eight digits of the product serial number. Bytes 16 through 26 reflect model of drive. The table above shows the hex values for Model ST6000NM0245. Refer to the values below for the values of bytes 16 through 26 of a particular model: ST6000NM0245 Seagate Exos 7E8 SAS Product Manual, Rev.
Page 46: Mode Sense Data
The following tables list the values of the data bytes returned by the drive in response to the Mode Sense command pages for SCSI implementation (see the SAS Interface Manual ). DEF = Default value. Standard OEM drives are shipped configured this way. CHG = Changeable bits; indicates if default value is changeable. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 47 1A 26 01 0F FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 48: Miscellaneous Operating Features And Conditions
Figure 8 shows the location of the SAS device connector J1. Figures 9 and 10 provide the dimensions of the SAS connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual. Figure 8. Physical interface Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 49 0.30 0.05 (4X) SEE Detail1 33.43 0.05 15.875 15.875 1.27 (14X) 1.27 (6X) 0.84 0.05 (22X) 5.08 0.15 B 4.90 0.08 0.35MIN C OF DATUM B Figure 9. SAS device plug dimensions Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 50 CONTACT SURFACE FLUSH 0.08 0.05 TO DATUM A 0.03 1.90 0.08 1.23 0.05 Detail 2 0.08 0.05 2.40 0.08 0.10 A SECTION B - B Figure 10. SAS device plug dimensions (detail) Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 51: Physical Characteristics
** - Power Disable (T10 Industry Standard) for remote management of the end device. Allows power cycling / power saving to be controlled by the host via interface pin 3. NC - No connection in the drive. Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 52: Sas Transmitters And Receivers
Output voltage LED off, high 0 V ≤ VOH ≤ 3.6 V -100 μA < IOH < 100 μA LED on, low IOL = 15 mA 0 ≤ VOL ≤ 0.225 V Seagate Exos 7E8 SAS Product Manual, Rev. A...
Page 53: Differential Signals
For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068. Seagate Exos 7E8 SAS Product Manual, Rev. A...
