Programmable Terminal
NA-series
Hardware
User's Manual
NA5-15 101
NA5-12 101
NA5-9 001
NA5-7 001
V117-E1-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMRON NA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sysmac OMRON NA Series

  • Page 1 Programmable Terminal NA-series Hardware User’s Manual NA5-15 101 NA5-12 101 NA5-9 001 NA5-7 001 V117-E1-11...
  • Page 2 Trademarks • Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in Japan and other countries for OMRON factory automation products. • Microsoft, Windows, Windows Vista, Excel, and Visual Basic are either registered trademarks or trademarks of Microsoft Corporation in the United States and other countries.

  • Page 3: Introduction

    Introduction Introduction Thank you for purchasing an NA-series Programmable Terminal. This manual contains information that is necessary to use the NA-series Programmable Terminal. Please read this manual and make sure you understand the functionality and performance of the NA-series Programmable Terminal before you attempt to use it in a control system. Keep this manual in a safe place where it will be available for reference during operation.

  • Page 4: Relevant Manuals

    • NA-series Programmable Terminal Soft-NA User's Manual (Cat. No. V126) Operations are performed from the Sysmac Studio Automation Software. Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for information on the Sys- mac Studio. Other manuals are necessary for specific system configurations and applications.

  • Page 5: Manual Structure

    Manual Structure Manual Structure Page Structure and Markings The following page structure is used in this manual. Level 1 heading 3 Installation and Wiring Level 2 heading Installing NA-series PTs Level 3 heading Level 2 heading Give the current headings. Level 3 heading 3-3-1 Installation in a Control Panel...
  • Page 6 Manual Structure Special Information Special information in this manual is classified as follows: Precautions for Safe Use Precautions on what to do and what not to do to ensure safe usage of the product. Precautions for Correct Use Indicates precautions on what to do and what not to do to ensure proper operation and perfor- mance.

  • Page 7: Sections In This Manual

    Sections in this Manual Sections in this Manual Introduction to the NA-series Programmable Terminals Configuration Units Installation and Wiring System Program Troubleshooting Maintenance Appendices Index NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 8 Sections in this Manual NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 9: Table Of Contents

    CONTENTS CONTENTS Introduction ......................1 Relevant Manuals..................... 2 Manual Structure...................... 3 Sections in this Manual ................... 5 Terms and Conditions Agreement ................11 Safety Precautions....................13 Precautions for Safe Use ..................15 Precautions for Correct Use ................. 18 Regulations and Standards .................. 19 Conformance to Shipbuilding Standards ............
  • Page 10 CONTENTS USB Memory Devices......................2-11 2-3-1 Models and Specifications ......................2-11 2-3-2 Applications..........................2-11 2-3-3 Installing and Removing......................2-11 Support Software......................... 2-13 2-4-1 Connection Methods ......................... 2-13 Section 3 Installation and Wiring Processing at Power ON and Power OFF ................3-2 3-1-1 Power ON Operation........................
  • Page 11 5-2-2 Correcting Fatal Errors in the NA Unit ..................5-6 5-2-3 Troubleshooting Non-fatal Errors....................5-6 5-2-4 Causes and Correction When You Cannot Go Online from the Sysmac Studio......5-7 5-2-5 Troubleshooting NA Unit Errors ....................5-12 Section 6 Maintenance Periodic Maintenance and Inspection ................. 6-2 6-1-1 Preparations for Problems ......................
  • Page 12 CONTENTS NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 13: Terms And Conditions Agreement

    Terms and Conditions Agreement Terms and Conditions Agreement Warranty, Limitations of Liability Warranties  Exclusive Warranty Omron’s exclusive warranty is that the Products will be free from defects in materials and workman- ship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron).
  • Page 14 Terms and Conditions Agreement Application Considerations Suitability of Use Omron Companies shall not be responsible for conformity with any standards, codes or regulations which apply to the combination of the Product in the Buyer’s application or use of the Product. At Buyer’s request, Omron will provide applicable third party certification documents identifying ratings and limitations of use which apply to the Product.

  • Page 15: Safety Precautions

    Safety Precautions Safety Precautions Definition of Precautionary Information The following notation is used in this manual to provide precautions required to ensure safe usage of the NA-series Programmable Terminal. The safety precautions that are provided are extremely impor- tant to safety. Always read and heed the information provided in all safety precautions. The following notation is used.
  • Page 16 Safety Precautions Warnings WARNING Do not attempt to take the NA Unit apart and do not touch the product inside while the power is being supplied. Otherwise it may result in electric shock. Always ensure that the personnel in charge confirm that installation, inspection, and maintenance were properly performed for the NA Unit.
  • Page 17 • Once the DIP switch settings are changed, reset by pressing the reset switch, or restart the power supply. • Initialize the project, after confirming that existing project is backed up at the Sysmac Studio. • When changing the password, do not reset or turn OFF the power supply until the writing is com- pleted.
  • Page 18 Precautions for Safe Use • Disconnecting the cable between a support tool and the NA Unit. • Do not connect an AC power supply to the DC power terminals. • Do not perform a dielectric strength test. • Use a DC power with a slight voltage fluctuation and that will provide a stable output even if the input is momentarily interrupted for 10 ms.
  • Page 19 Precautions for Safe Use • To execute a subroutine with multiple threads, fully check the operation of the program that takes multithreads into consideration, before starting actual system application. • To use numeric input functions safely, always make maximum and minimum limit settings. •...

  • Page 20: Precautions For Correct Use

    Precautions for Correct Use Precautions for Correct Use  Do not install or store the NA Unit in any of the following locations: • Locations subject to severe changes in temperature • Locations subject to temperatures or humidity outside the range specified in the specifications •...

  • Page 21: Regulations And Standards

    Regulations and Standards Regulations and Standards Conformance to EU Directives Applicable Directives • EMC Directive Concepts  EMC Directive OMRON devices that comply with EC Directives also conform to the related EMC standards so that they can be more easily built into other devices or the overall machine. The actual products have been checked for conformity to EMC standards.* Whether the products conform to the standards in the system used by the customer, however, must be checked by the customer.
  • Page 22 Regulations and Standards Conformance to KC Standards When you use this product in South Korea, observe the following precautions. This product meets the electromagnetic compatibility requirements for business use. There is a risk of radio interference when this product is used in home. NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 23: Conformance To Shipbuilding Standards

    Conformance to Shipbuilding Standards Conformance to Shipbuilding Standards The NA-series Programmable Terminals comply with shipping standards. Application conditions are set for compliance for individual shipping standards, and it may not be possible to use the product in some installation locations. Contact an OMRON sales representative before using the product. ...
  • Page 24 Conformance to Shipbuilding Standards  Certification Zones for Shipping Standards b. Bridge Air conditioning a. Deck No air conditioning Devices on deck or bridge Devices not on deck or bridge Ocean e. Boiler room c. Depends on ship type d. Engine room Air conditioning Emergency power supply devices on No air conditioning...

  • Page 25: Related Manuals

    Startup Guide mation required to page creation and transfer proce- install and start the dures with the Sysmac Studio. Also operation of an operation, maintenance, and inspec- NA-series PT. tion procedures after the project is transferred are described.
  • Page 26 Related Manuals Manual name Cat. No. Models Applications Description NX-series CPU Unit W535 NX701- Learning the basic An introduction to the entire NX-series Hardware User's specifications of system is provided along with the fol- Manual the NX-series CPU lowing information on the CPU Unit. Units, including •...
  • Page 27 Related Manuals Manual name Cat. No. Models Applications Description CJ Series Program- W393 CJ1H-CPUH-R Learning the basic The following information is provided mable Controllers specifications of on a CJ-series PLC. CJ1G/H-CPUH Operation Manual the CJ-series • Introduction and features CJ1G-CPUP PLCs, including •...
  • Page 28 Related Manuals Manual name Cat. No. Models Applications Description CS/CJ/NSJ Series W342 CS1G/H-CPUH Learning detailed 1) C-mode commands and 2) FINS Communications specifications on commands are described in detail. CS1G/H-CPU-V1 Commands Refer- the communica- Refer to this manual for information CS1D-CPUH ence Manual tions instructions...
  • Page 29 Units. CS1W-EIP21 CJ2 CPU Units. Basic settings, tag data links, FINS CJ1W-EIP21 communications, and other functions are described. Sysmac Studio Ver- W504 SYSMAC-SE2 Learning about the The operating procedures of the Sys- sion 1 Operation operating proce- mac Studio are described.
  • Page 30 Related Manuals Manual name Cat. No. Models Applications Description NY-Series IPC W557 NY532-1 Learning the basic An introduction to the entire NY-series system is provided along Machine Controller specifications of Industrial Panel PC the NY-series with the following information on the Hardware User's Industrial Panel Industrial Panel PC.
  • Page 31 Related Manuals Manual name Cat. No. Models Applications Description NX-series NX1P2 W579 NX1P2- Learning about the Of the functions for an NX1P2 CPU Unit, the following information is pro- CPU Unit Built-in I/O details of functions and Option Board only for an vided.

  • Page 32: Terminology

    Term Description A general term for interface devices that indicates both hardware and software elements. In this manual, “HMI” refers to an OMRON Sysmac-brand product unless otherwise specified. The hardware elements of the HMI. NA Series The NA Series of Programmable Terminals and peripheral devices.

  • Page 33: Revision History

    Revision History Revision History A manual revision code appears as a suffix to the catalog number on the front and back covers of the manual. V117-E1-11 Cat. No. Revision code Revision code Date Revised content June 2014 Original production October 2014 Made revisions accompanying version upgrade.
  • Page 34 Revision History NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 35: Introduction To The Na-Series Programmable Terminals

    Introduction to the NA-series Pro- grammable Terminals This section describes the features, basic system configuration, specifications, and overall operating procedure of the NA-series Programmable Terminals. 1-1 NA-series Programmable Terminals ......1-2 1-1-1 Features .

  • Page 36: Na-Series Programmable Terminals

    They provide all of the functions of traditional programmable terminals with a clearer, easy-to-use interface. OMRON offers the new Sysmac Series of control devices designed with unified communications speci- fications and user interface specifications. The NA-series Programmable Terminals are Sysmac devices that you can use together with the NJ/NX/NY-series Machine Automation Controllers and the Sysmac Studio Automation Software to achieve optimum functionality and ease of operation.
  • Page 37 You can use an SD Memory Card inserted in the NA Unit to automatically transfer the project you created on the Sysmac Studio to the NA Unit, to update the system program in the NA Unit, or to save the log data from the NA Unit.

  • Page 38: System Configurations

    Connecting to the Support Software You can connect the Sysmac Studio to a USB port on the NA Unit with a commercially available USB cable. You can also connect it through an Ethernet cable that is connected to Ethernet port 2 on the NA Unit.

  • Page 39: Available Products

    1.3 kg max. NA5-7W001B Black NA5-7U001B 1-3-2 Support Software You use the Sysmac Studio to create applications for NA-series PTs and to debug them. Name Model Specifications Sysmac Studio SYSMAC-SE This software is used to create and debug applications for NA-series Standard Edition PTs.

  • Page 40: Other Optional Products

    It is used to back up the clock informa- tion in the NA Unit. Cable for USB port (to Commercially avail- USB 2.0 (or 1.1) cable (A connector - B connect the Sysmac Stu- able USB cable connector), 5.0 m max. dio) Anti-reflection Sheets...

  • Page 41: Specifications

    1 Introduction to the NA-series Programmable Terminals Specifications This section gives the hardware specifications of the NA-series PTs. 1-4-1 General Specifications Specification Item NA5-15W NA5-12W NA5-9W NA5-7W NA5-15U NA5-12U NA5-9U NA5-7U Rated supply 24 VDC voltage 19.2 to 28.8 VDC (24 VDC ±20%) Allowable power supply voltage range...
  • Page 42 1 Introduction to the NA-series Programmable Terminals Specification Item NA5-15W NA5-12W NA5-9W NA5-7W NA5-15U NA5-12U NA5-9U NA5-7U UL 508/CSA standard C22.2 No.142 EMC Directive (2014/30/EU) EN 61131-2:2007 Shipbuilding standards LR, DNV, and NK International IP65 oil-proof, UL Type 4X (front panel only) standards ANSI 12.12.01 Class 1 Division 2/CSA standard C22.2 No.
  • Page 43 1 Introduction to the NA-series Programmable Terminals *3. Store the PT within the following temperature and humidity ranges. Storage temperature-humidity range Temperature [°C] *4. Check with your OMRON representative or refer to the following OMRON website for the latest information on the applicable standards for each model: www.ia.omron.com.

  • Page 44: Performance Specifications

    1 Introduction to the NA-series Programmable Terminals 1-4-2 Performance Specifications Display Specification Item NA5-15W NA5-12W NA5-9W NA5-7W Display Display TFT LCD device panel Screen size 15.4 inches 12.1 inches 9.0 inches 7.0 inches 1,280 × 800 dots (horizontal × vertical) 800 ×...
  • Page 45 Ethernet ports Applications Port 1: Connecting to anything other than the Sysmac Studio, e.g., device connections and VNC clients Port 2: Connecting to the Sysmac Studio in addition to the applications of port 1. Number of ports 2 ports Compliant standards IEEE 802.3i (10BASE-T), IEEE 802.3u (100BASE-TX), and...
  • Page 46 1 Introduction to the NA-series Programmable Terminals 1 - 12 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 47: Configuration Units

    Configuration Units This section describes the basic system configuration and devices used for NA-series Programmable Terminals. 2-1 NA Units ........... . . 2-2 2-1-1 Components and Functions .

  • Page 48: Na Units

    2 Configuration Units NA Units This section describes the names and functions of NA Unit parts and installation methods and provides other information. 2-1-1 Components and Functions Front Panel RUN indicator Display F1 Key F2 Key F3 Key Function keys Name Description ...
  • Page 49 2 Configuration Units Precautions for Safe Use • Do not press the touch panel with a force greater than 30 N. • The deterioration over time may cause the touch points to move on the touch panel. Cali- brate the touch panel periodically. •...
  • Page 50 2 Configuration Units Back Panel • Back Panel (b) ID information label (a) Battery cover (c) Expansion Unit connector (for future expantion (Connector not included with product lot No. 01818 or later.)) • Bottom Panel (e) Ethernet ports (f) Serial port (for future expansion) (d) SD Memory (g) USB host port Card connector...
  • Page 51 Expansion Unit connector or later.) SD Memory Card connector Insert an SD Memory Card here. Ethernet port 1 Connect a device other than the Sysmac Studio. Ethernet port 2 Connect mainly the Sysmac Studio. For future expansion. Serial port USB host port Connect a USB memory, keyboard, mouse, or other device.
  • Page 52 2 Configuration Units  Reset Switch Use a precision screwdriver or similar device with a diameter of less than 2.4 mm. The reset switch performs the same function as cycling the power supply.  Ethernet Ports • Port Pin Arrangement and Indicator Locations Ethernet Port 1 Ethernet Port 2 Indicators...
  • Page 53 2 Configuration Units • Connecting Devices That Support IEEE 802.3ab (1000Base-T) Pin No. Signal name Name TRD0+ Send/receive data 0+ TRD0- Send/receive data 0- TRD1+ Send/receive data 1+ TRD2+ Send/receive data 2+ TRD2- Send/receive data 2- TRD1- Send/receive data 1- TRD3+ Send/receive data 3+ TRD3-...
  • Page 54 2 Configuration Units  ID Information Label You can check the ID information of the NA Unit with the ID information label on the back of the NA Unit. An example is shown below. The label varies with the model and applicable standards. Name Description Model...

  • Page 55: Sd Memory Cards

    2-2-2 Applications You can use the SD Memory Card for the following applications. • Automatically transferring the project data (which includes the screen data) created on the Sysmac Studio to an HMI • Updating the HMI system program • Recording log data (data log and user alarms)
  • Page 56 2 Configuration Units • Never insert the SD Memory Card facing the wrong way. If the SD Memory Card is inserted forcibly, it may become unusable. • To format the SD Memory Card (e.g., to delete all of the data), use the SD Formatter for SD/SDHC/SDXC provided by the SD Association.

  • Page 57: Usb Memory Devices

    2-3-2 Applications You can use the USB Memory Device for the following applications. • Automatically transferring the project data (which includes the screen data) created on the Sysmac Studio to the HMI • Updating the HMI system program • Recording log data (data log and user alarms)
  • Page 58 2 Configuration Units Installing the USB Memory Device Insert the USB Memory Devices into the USB host port on the back of the NA Unit. Push the USB Memory Device all of the way in. Removing the USB Memory Device Execute EjectUSBDevice in a subroutine and then remove the USB Memory Device.

  • Page 59: Support Software

    This Sysmac Studio is used to create, debug, and maintain applications for NA-series Programmable Terminals. 2-4-1 Connection Methods With an NA-series Programmable Terminal, you can connect the Sysmac Studio online in the following ways. Connecting with USB Use a commercially available USB cable for a USB connection.
  • Page 60 • Connect the Sysmac Studio to Ethernet port 2. • The IP address and connection device do not need to be specified at the Sysmac Studio. Select the Direct Connection with Sysmac Studio Check Box under HMI Settings − TCP/IP Settings and then connect to Ethernet port 2.
  • Page 61 Installation and Wiring This section describes how to install and wire an NA Unit. 3-1 Processing at Power ON and Power OFF ......3-2 3-1-1 Power ON Operation .

  • Page 62: Processing At Power On And Power Off

    3 Installation and Wiring Processing at Power ON and Power WARNING Do not attempt to disassemble, repair, or modify the NA Unit. It may cause NA Unit to lose its safety function. Do not attempt to take the NA Unit apart and do not touch the product inside while the power is being supplied.

  • Page 63: Fail-Safe Measures

    3 Installation and Wiring Fail-safe Measures WARNING Provide safety measures in external circuits to ensure safety in the system if an abnormality occurs due to malfunction of the NA Unit or due to other external factors affecting operation. Not doing so may result in serious accidents due to incorrect operation. The circuits associated with safety measures, such as emergency stop circuits, interlock cir- cuits, and limit circuits, must be provided in external control circuits.

  • Page 64: Installing Na Units

    3 Installation and Wiring Installing NA Units This section describes how to install an NA Unit. Precautions for Correct Use • Follow the instructions in this manual to correctly perform installation. • Do not install or store the NA Unit in any of the following locations: •...

  • Page 65: Installation In A Control Panel

    3 Installation and Wiring 3-3-1 Installation in a Control Panel Installation in a Control Panel The NA Unit is installed by embedding it in a control panel. Panel Mounting Brackets and a Phillips screwdriver are required to mount the NA Unit. The required number of Panel Mounting Brackets are included with the NA Unit.
  • Page 66 3 Installation and Wiring Slide the PWA over the NA Unit from the back until the flat side of the PWA is flat against the inside of the panel, as shown in the following figure. Attach the panel mounting brackets from the back of the panel as shown in the following figure. The number of mounting brackets depends on the size of the NA Unit, as shown in the following table.
  • Page 67 3 Installation and Wiring Precautions for Safe Use • Do not let metal particles enter the NA Unit when preparing the panel. • To conform to UL Type 4X standards, the thickness must be 1.6 to 4.5 mm. To conform to UL Type 4X standards, always use the NA5-W with a High-pres- sure Waterproof Attachment (PWA).
  • Page 68 3 Installation and Wiring Additional Information Bracket Mounting Locations for Different Units When you mount an NA Unit, secure it with the mounting brackets as shown in the following fig- ures. • NA5-15W Secure the NA Unit with mounting brackets in the eight locations shown below. •...

  • Page 69: Wiring Methods

    3 Installation and Wiring Wiring Methods This section describes how to wire an NA Unit. WARNING Make sure that the voltage and current that are input to the NA Unit are within the specified ranges. Inputting voltages or currents that are outside of the specified ranges may cause acci- dents or fire.
  • Page 70 3 Installation and Wiring Wiring Materials Use the enclosed power supply connector to connect the power supply to the NA Unit. • We recommend that you use a power supply cable with the following stranded wires. Wire the power supply giving sufficient consideration to the voltage drop and heat generation for the cable length in the installation environment.
  • Page 71 3 Installation and Wiring Wiring Procedure Use the following procedure to connect the power supply. Remove the sheath from the power supply wires. 7 mm Remove the power supply connector from the NA Unit and loosen the terminal block screws. Insert the wires all the way to the back of the connector and then turn the screws clockwise to secure the wires.
  • Page 72 3 Installation and Wiring Precautions for Correct Use Observe the following precautions to prevent broken wires. • When you remove the sheath, be careful not to damage the conductor. • Connect the conductor without twisting the wires. • Do not weld the conductors. If you do so, vibration may cause the wires to break. •...

  • Page 73: Wiring The Ethernet Port

    3 Installation and Wiring 3-4-2 Wiring the Ethernet Port Refer to the NA-series Programmable Terminal Device Connection Manual (Cat. No. V120) for informa- tion on wiring the Ethernet ports. 3-4-3 Wiring the Serial Port The serial port is for future expansion. Do not wire this port. 3 - 13 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 74: Control Panel Installation

    3 Installation and Wiring Control Panel Installation To ensure system reliability and safety, the system must be designed and configured according to the installation environment (temperature, humidity, vibration, shock, corrosive gases, overcurrent, noise, etc.). 3-5-1 Temperature Panels have been reduced in size due to space-saving and miniaturization in devices and systems, and the temperature inside the panel may be at least 10 to 15°C higher than outside the panel.

  • Page 75: Humidity

    3 Installation and Wiring  Forced Air Circulation (with Fan in Closed Panel) NA Unit Forced Circulation  Room Cooling (Cooling the Entire Room Where the Control Panel Is Located) Cooler NA Unit Control panel Room Cooling Low Temperatures The NA Unit may not start normally if the temperature is below 0°C when the power is turned ON. Maintain an air temperature of at least approximately 5°C inside the panel, by implementing measures such as installing a low-capacity space heater in the panel.

  • Page 76: Vibration And Shock

    3 Installation and Wiring 3-5-3 Vibration and Shock The NA Unit is tested for conformity with the sine wave vibration test method (IEC 60068-2-6) and the shock test method (IEC 60068-2-27) of the Environmental Testing for Electrotechnical Products. It is designed so that malfunctioning will not occur within the specifications for vibration and shock.

  • Page 77: Electrical Environment

    3 Installation and Wiring 3-5-5 Electrical Environment When installing or wiring devices, make sure that there will be no danger to people and that noise will not interfere with electrical signals. Installation Locations for NA Unit Install the NA Unit as far away as possible from high-voltage (600 V or higher) and power devices to ensure safe operation and maintenance.
  • Page 78 3 Installation and Wiring External Wiring Wiring, and noise countermeasures in particular, must be based mostly on experience, and it is neces- sary to closely manage wiring based on information in the manuals.  Wiring Routes Each of the following combinations includes different signal types, properties, or levels. They will cause the signal-to-noise ratio to drop due to factors such as electrical induction.
  • Page 79 3 Installation and Wiring • To avoid overheating the conduits when using conduits for wiring, do not place wires for a single circuit in separate conduits. Power supply Load Incorrect Power supply Load Correct Power supply Load Correct Parallel Wiring (Single Phase) •...

  • Page 80: Grounding

    3 Installation and Wiring 3-5-6 Grounding Grounding has the following two purposes. • Protective Grounding Protective grounding is done to ensure safety. It is intended to prevent electrical shock by holding the electrical potential at the grounding potential that is generated by factors such as leakage, induction, or failure.
  • Page 81 3 Installation and Wiring  Precautions when Grounding • If the same ground is used for both the signal lines and the enclosure, isolate the channel base (a grounded metal plate inside a control panel) with an insulating material. The NA Units are designed to be mounted so that they are isolated (separated) from the mounting surface to protect them from the effects of noise...
  • Page 82 3 Installation and Wiring 3 - 22 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 83: System Program

    System Program This section describes the system program that is used by NA-series Programmable Terminals. 4-1 System Program and NA Unit Startup Status ..... . . 4-2 4-2 System Recovery .

  • Page 84: System Program And Na Unit Startup Status

    • You may need to update the system program from time to time, e.g., when support for a new con- nected device is added to the NA Units. In this case, the system program is automatically down- loaded from the Sysmac Studio. 4 - 2...

  • Page 85: System Recovery

    System Recovery Procedure Use the following procedure for system recovery. Prepare a formatted SD Memory Card or USB Memory Device. Execute the following file in the Sysmac Studio installation media. Sysmac_Studio_installation_media\Utility\ NA_RecoverUpdate\NA_RecoverUpdate___.exe Specify the root folder on the media you prepared in step 1 as the extraction location.
  • Page 86 4 System Program Tap the language to use for system recovery. Select the package that you want to install, and then tap the Install Button. Tap the Yes Button. 4 - 4 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 87 4 System Program When the following message is displayed, remove the media from the NA Unit and turn OFF the power supply to the NA Unit. Open the battery cover on the back of the NA Unit and set the DIP switch to the settings shown below.

  • Page 88: System Menu Overview

    4 System Program System Menu Overview You can use the System Menu to perform operations according to on-screen displays to perform vari- ous settings for the NA Unit. Refer to 4-3-1 System Menu Configuration on page 4-6 for the configuration of the System Menu. Refer to 4-3-2 Using the System Menu on page 4-9 for the procedures to use the System Menu.
  • Page 89 4 System Program • Project System Menu (2/2) Item Description Reference Print Settings Sets up printing/capturing of the NA screens. P. 4-29 Buzzer Settings Sets buzzer sounds. P. 4-30 Operation Log Viewer Display the Operation Log Viewer. P. 4-31 Safety Monitor Display the Safety Monitor.
  • Page 90 4 System Program • Device System Menu Item Description Reference Date & Time Settings Sets the date and time, as well as settings for synchronization P. 4-48 with the time server. Language Settings Makes settings for the system language. P. 4-48 Interface Settings Makes settings for the NA Unit interface.

  • Page 91: Using The System Menu

    This section describes how to use the System Menu, including the display methods and how to select menu items. Additional Information The system settings that are made in the Sysmac Studio project data take priority over the set- tings that are made from the System Menu. System Menu Display Methods You can display the System Menu with any of the following methods.
  • Page 92 4 System Program Selecting Menu Items Tap a menu item or icon on the System Menu to display the corresponding functionality. Example: Tap the Hardware Diagnostics Icon on the Device System Menu to display the Hardware Diagnostics Screen. Leaving the System Menu to Enter Operating Status Tap the Exit Button on the Project System Menu to return to Run Status.

  • Page 93: System Menu Details

    4 System Program System Menu Details This section describes the functions that are provided by the System Menu. 4-4-1 Display Settings (Project System Menu) You can use the display settings to set the following items. Item Description Screen Saver Enabled Select this check box to use the screen saver.

  • Page 94: Language Settings (Project System Menu)

    4 System Program 4-4-2 Language Settings (Project System Menu) You can use the language settings to set the following items. Item Description User Language Sets the user language. System Language Displays the system language that is associated with the user lan- guage.

  • Page 95: User Accounts (Project System Menu)

    4 System Program 4-4-4 User Accounts (Project System Menu) You can use the user account settings to set the following items. Precautions for Safe Use • When you change a password, do not reset the NA Unit or turn OFF the power supply before writing the new password is completed.

  • Page 96: Nj/Nx/Ny Troubleshooter (Project System Menu)

    Errors and Events That Can Be Monitored  User-defined Errors and User-defined Events Errors and events can be defined by the user with the Sysmac Studio. Detailed information on trouble- shooting also can be set. Refer to Section 1 Overview in the NJ/NX-series Troubleshooting Manual (Cat.
  • Page 97 Displaying Clearing error errors errors error logs logs CPU Rack CPU Unit Applicable CJ-series Units Applicable Partially applicable EtherCAT Slaves (Sysmac devices) *2 *3 Applicable Applicable Applicable EtherCAT Slave Ter- EtherCAT Cou- *2 *3 Applicable Applicable Applicable minals pler Units...
  • Page 98 4 System Program When Connected to an NX-series Communication Control Unit Troubleshooter functions System configuration element Displaying Clearing Displaying Clearing error errors errors error logs logs Communication Control Unit Applicable NX Units Partially appli- *2*3 Applicable Applicable Applicable cable *1. Events are not displayed for some NX Units. *2.
  • Page 99 4 System Program Starting and Quitting the NJ/NX/NY Troubleshooter There are four ways to start the NJ/NX/NY Troubleshooter. • Select NJ/NX/NY Troubleshooter from the System Menu. • Execute the ShowTroubleshooter action. • Execute the ShowTroubleshooter function. • Set the Troubleshooter operation settings to specify monitoring user-defined or Controller errors. (The NJ/NX/NY Troubleshooter will be displayed automatically when a user-defined error or Control- ler error occurs.) ...
  • Page 100 4 System Program  Starting from a User Screen The required settings must be made from the Sysmac Studio. The following example shows how to execute the Troubleshooter by using an object event. In this example, settings are performed to execute the Troubleshooter when a Button object is clicked.
  • Page 101 Troubleshooter is activated.  Starting the Troubleshooter for User-defined Errors or Controller Errors The required settings are made from the Sysmac Studio. Double-click Troubleshooter under Configurations and Setup in the Multiview Explorer. The Troubleshooter Settings Tab Page will be displayed in the Edit Pane.
  • Page 102 4 System Program  Quitting the NJ/NX/NY Troubleshooter Click the Exit Button on the screen that was displayed when the NJ/NX/NY Troubleshooter started. The display will return to the user screen that was displayed before the NJ/NX/NY Trouble- shooter started. NJ/NX/NY-series Controller Status Screen The status of the host to which the NA is currently connected is displayed.
  • Page 103 4 System Program Controller Event List Screen This screen displays a list of the Controller errors for the selected host. Item Description Exit Button Quits the Troubleshooter. Title Bar Displays the current date of the NA. Tabs Switch between displaying active events and the event log. Controller Events Displays current Controller events.
  • Page 104 4 System Program Controller Event Log Screen This screen displays a list of the Controller events for the selected host. Item Description Exit Button Quits the Troubleshooter. Tittle Bar Displays the current date of the NA. Tabs Switch between displaying active events and the event log. Controller Events Displays current Controller events.
  • Page 105 4 System Program Event Source Selection Screen On this screen, the Functional Modules that are the sources of the errors are selected. Item Description Functional Module List Displays a list of the Functional Modules in the Controller. Sub Functional Module List Displays a list of the Sub Functional Modules in the Controller.
  • Page 106 4 System Program Details Screen This screen displays detailed information on errors or events. Item Description Tittle Bar Displays the current date of the NA. Back Button Closes the Details Screen. Details Button Displays errors and events in detail. Screen Shot Button Captures an image of the displayed screen and stores it in USB memory or an SD Memory Card in PNG format.
  • Page 107 4 System Program Operation Settings of the NJ/NX/NY Troubleshooter The operation settings of the NJ/NX Troubleshooter are set from the Sysmac Studio. Double-click Trou- bleshooter under Configurations and Setup in the Multiview Explorer. The Troubleshooter Settings Tab Page will be displayed in the Edit Pane.

  • Page 108: Alarm Viewer (Project System Menu)

    4 System Program 4-4-6 Alarm Viewer (Project System Menu) The following two functions are provided to display alarms. Item Description Active HMI User Alarms Displays current user alarms. Historical HMI User Alarms Displays the user alarm log. From the Alarm Viewer Screen, you can tap any of the icons for functions to display the individual func- tion screens.
  • Page 109 4 System Program • Alarm Details Screen This screen displays detailed information on a selected user alarm. Item Description Alarm Code Displays the alarm code of the user alarm that occurred. Additional Information Displays the additional information of the user alarm that occurred. Details Displays the details on the user alarm that occurred.
  • Page 110 4 System Program • Historical HMI User Alarms Screen This screen displays a log of the user alarms. Item Description Historical HMI User Alarm Displays a log of the user alarms. 4 - 28 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 111: Project System Menu Settings (Project System Menu)

    4 System Program 4-4-7 Project System Menu Settings (Project System Menu) You can use the System Menu settings to set the following items. Item Description Double-tap Interval Sets the double-tap interval for the operation to start the System Menu. Detectable Corner Sets the double-tap detection positions for the operation to start the System Menu.

  • Page 112: Buzzer Settings (Project System Menu)

    4 System Program 4-4-9 Buzzer Settings (Project System Menu) You can use the buzzer settings to set the following items. Item Description Touch Input Notification Select this check box to sound the buzzer when an object is touched. Alarm Notification Select this check box to sound the buzzer when an alarm occurs.
  • Page 113 4 System Program 4-4-10 Operation Log Viewer In the Operation Log Viewer, you can check the logs recorded when operations specified on Sysmac Studio are executed on the NA unit. Starting and Exiting Operation Log Viewer There are three ways to start the Operation Log Viewer as shown below.
  • Page 114 4 System Program  Starting from a User Screen The required settings are made from the Sysmac Studio. The following example shows how to execute the Operation Log Viewer by using an object event. In this example, settings are performed to execute Operation Log Viewer when a Button object is tapped.
  • Page 115 4 System Program  Exiting Operation Log Viewer Tap Back on the screen that was displayed when the Operation Log Viewer started. The display will return to the screen that was displayed before the Operation Log Viewer started. 4 - 33 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 116: Operation Log Viewer

    4 System Program Operation Log Viewer Displays the operation logs. Item Description Search Searches the specified date and time and then displays the results in the log list. Log List Displays a list of the logs that have been recorded. Date and Time: Displays the local time at which the log was recorded.
  • Page 117 4 System Program Detail Information Displays detailed information on the log. Item Description Log detail information Displays detailed information on the log. Date and Time: Displays the local time at which the log was recorded. User: Displays the user who executed the operation. Category: Displays the category of the operation executed.

  • Page 118: 4-4-11 Safety Monitor

    4 System Program 4-4-11 Safety Monitor Safety Monitor provides a function to identify inputs that cause abnormal states when the external out- put from the safety program of the safety control unit is in an abnormal state. Display Item Safety Monitor can display the items below. •...
  • Page 119 4 System Program System configuration All NA5 Series Programmable Terminals support the Safety Monitor. To use the Safety Monitor, an SD memory card needs to be inserted into the NA unit. The equipment that can be monitored is as follows. ...
  • Page 120 4 System Program Starting and exiting Safety Monitor There are three ways to start the Safety Monitor as shown below. • Select Safety Monitor from the System Menu. • Execute the StartSafetyMonitor action. • Execute the StartSafetyMonitor function.  Starting from the System Menu Display the System Menu and select Safety Monitor.
  • Page 121 4 System Program  Starting from a User Screen The required settings are made from the Sysmac Studio. The following example shows how to use an object event to execute the Safety Monitor. In this example, settings are made to execute the Safety Monitor when a Button object is pressed.
  • Page 122 4 System Program  Exiting Safety Monitor on the screen that was displayed when the Safety Monitor started. The display will return to the screen that was displayed before the Safety Monitor started. 4 - 40 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 123 4 System Program I/O Matrix Monitor Displays a list of values of variables. In the initial state, only outputs are displayed. Selecting an output displays its related inputs. Item Description Applicable equipment Displays the safety CPU unit currently being monitored. Output from Safety CPU Displays a list of outputs and shows values.
  • Page 124 4 System Program Safety output unit monitor Displays the status of the safety output unit. Item Description Applicable equipment Displays the CPU unit currently being monitored. Unit information Displays information on the currently displayed safety output unit. Terminal section monitor Displays the output state of the terminal.
  • Page 125 4 System Program Safety input unit monitor Displays the status of the safety input unit. Item Description Applicable equipment Displays the CPU unit currently being monitored. External equipment setting Displays information on the equipment connected to the terminal. information Displays the name of the equipment, terminal numbers connected, as well as corresponding icons.
  • Page 126 4 System Program Variable Information Displays detailed information on the variable. Item Description Variable Information Displays detailed information on the variable. Close Closes Variable Information. Search Variable Searches for a variable. Item Description Variable Name Sets the name of the variable to search. Type Selects the type of variables to search.
  • Page 127 4 System Program PDF Display Displays the files set in PDF Display Settings on the Document Viewer in Windowed mode. The Docu- ment Viewer closes when the Safety Monitor is exited. Menu The following three functions can be executed from the menu. •...
  • Page 128 4 System Program  PDF Display Settings Specify the files to be displayed in PDF Display. Item Description Media Settings Specifies the location where files are saved. For FTP Server settings, inquire to the server administrator. Folder Name Displays the name of the folders displayed in File List. File List Displays a list of folders and files included in the folder.
  • Page 129 4 System Program Elements of each column are shown below. Rows including the initial row are handled as data and up to 16 rows are loaded. Column Item Description Number PDF File Name Specifies the name of the PDF file to be displayed. Extensions cannot be omitted.

  • Page 130: Date & Time Settings (Device System Menu)

    4 System Program 4-4-12 Date & Time Settings (Device System Menu) You can use the date & time settings to set the following items. Item Description Time Zone Sets the time zone. Automatically adjust clock for Select this check box to automatically compensate for daylight sav- ing time.

  • Page 131: Interface Settings (Device System Menu)

    4 System Program 4-4-14 Interface Settings (Device System Menu) You can use the interface settings to set communications for the NA Unit. From the Interface Settings Screen, you can tap any of the icons for settings to display the individual setting screens.
  • Page 132 4 System Program Ethernet This screen is used to set the Ethernet port IP address and other settings for Ethernet. Item Description Ethernet Port 1 Settings Sets the IP address and other settings for Ethernet port 1. Ethernet Port 2 Settings Sets the IP address and other settings for Ethernet port 2.
  • Page 133 4 System Program This screen is used to make settings for VNC. • VNC Settings (1/2) Item Description Enable VNC Server Select this check box to use the VNC. Port No. Sets the port number. Mode Sets the mode. Change Password Select this check box to change the password.
  • Page 134 4 System Program • VNC Settings (2/2) Item Description Enable registered client login Select this check box to set login restrictions. List of clients Lists the clients registered at present. Edits the selected client. Deletes the selected client. Adds a new client. IP Address Sets the IP address of a client.
  • Page 135 4 System Program FINS This screen is used to make settings for FINS. Item Description Ethernet Port 1 Settings Sets the FINS network address for Ethernet port 1. The node address is automatically created based on the IP address. Ethernet Port 2 Settings Sets the FINS network address for Ethernet port 2.

  • Page 136: Brightness Settings (Device System Menu)

    4 System Program 4-4-15 Brightness Settings (Device System Menu) You can use the brightness settings to set the following items. Item Description Brightness Sets the screen brightness. 4 - 54 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 137: Transfer Operations (Device System Menu)

    4 System Program 4-4-16 Transfer Operations (Device System Menu) This screen is used to transfer the project and other data. You can tap any of the icons for settings to display the individual setting screens. Item Description Transfer User Program to HMI Downloads the project.
  • Page 138 4 System Program Transfer User Program to HMI This screen is used to download the project from an SD Memory Card or USB Memory Device. Item Description Source Media Sets the media that contains the project to download. Path Displays the path of the folder displayed at (c). Folder Contents Displays the files and folders in the currently open folder.
  • Page 139 Uploads the selected project from the HMI to the destination media. Precautions for Correct Use Projects that are downloaded with Sysmac Studio version 1.10 and projects that are down- loaded when the Transfer source code to the NA device Check Box is not selected cannot be read by the Sysmac Studio.
  • Page 140 4 System Program Transfer Data to HMI This screen is used to download text, videos, or other data from an SD Memory Card or USB Memory Device. Item Description Data Type Sets the file type. Only files with the specified file type are displayed at (c).
  • Page 141 4 System Program Transfer Data from HMI This screen is used to upload recipes, videos, or other data to an SD Memory Card or USB Memory Device. Item Description Media Sets the media to which to upload the data. Path Displays the path of the folder displayed at (c).

  • Page 142: Hardware Diagnostics (Device System Menu)

    4 System Program 4-4-17 Hardware Diagnostics (Device System Menu) This screen is used to check the operation of the touch panel and to calibrate it. You can tap any of the icons to access a function. Item Description Function Keys Checks the operation of the function keys.

  • Page 143: Production Information (Device System Menu)

    4 System Program Function Keys This screen is used to check the operation of the function keys. Production Information This screen displays product information. 4 - 61 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 144 4 System Program LCD Display A color bar is displayed. Use this to check the LCD. Tap the screen to move to the next display. Touch Panel Calibration This screen is used to calibrate the touch panel. Tap the plus signs that are displayed. To cancel, double-tap any position.
  • Page 145 4 System Program Touch Panel Input The locations that are touched are displayed as dots. Use this to check the operation of the touch panel. To end, double-tap any position. 4 - 63 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 146: Production Information (Device System Menu)

    4 System Program 4-4-18 Production Information (Device System Menu) This screen displays product information. 4 - 64 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 147: Troubleshooting

    Troubleshooting Non-fatal Errors ........5-6 5-2-4 Causes and Correction When You Cannot Go Online from the Sysmac Studio . . . 5-7 5-2-5 Troubleshooting NA Unit Errors .

  • Page 148: Operation After An Error

    5 Troubleshooting Operation after an Error This section describes the error status of the NA-series Programmable Terminal and the operation that occurs after an error is detected. Refer to 5-2 Troubleshooting on page 5-5 for details on corrections for specific errors. 5-1-1 Checking NA Unit Status You can check the operating status of an NA Unit with the RUN indicator on the right side of the front...

  • Page 149: Fatal Errors In The Na Unit

    • System Program Error The system program is corrupted and normal operation is not possible.  If any of the following errors occur, the Sysmac Studio can go online with the NA Unit, but communications connections with connected devices are not possible.

  • Page 150: Nonfatal Errors In The Na Unit

    If there are no problems in the hardware or system program, the NA Unit will operate even if one of these errors occurs. This section describes nonfatal errors.  If any of the following errors occur, the Sysmac Studio can go online with the NA Unit, but communications connections with connected devices are not possible.

  • Page 151: Troubleshooting

    5 Troubleshooting Troubleshooting This section provides basic error identification, troubleshooting flowcharts, and error corrections. Use them when an error occurs in the NA Unit. 5-2-1 Confirming NA Unit Operation When an error occurs in the NA Unit, use the following flowchart to determine whether the error is a fatal error or a non-fatal error.

  • Page 152: Correcting Fatal Errors In The Na Unit

    5 Troubleshooting 5-2-2 Correcting Fatal Errors in the NA Unit  Power Supply Error Check the following items: • Is the NA Unit correctly connected to the external DC power supply? • Is the voltage supplied from the external DC power supply within the allowable range? ...

  • Page 153: Causes And Correction When You Cannot Go Online From The Sysmac Studio

    There is a mistake in the settings that the Refer to Troubleshooting Incorrect Settings or faulty communi- Sysmac Studio uses to go online with the and Faulty Communications Path on page cations path NA Unit. Or, the communications path is 5-8.
  • Page 154 Can the Sysmac Studio go online with the NA Unit? Install the USB driver. Refer to the appendices of the Sysmac Studio Version 1 Operation Manual Is the USB driver installed (Cat. No. W504) for the procedure to install the correctly? USB driver.
  • Page 155 IP address for the NA Unit or connect for more than one node (e.g., the Sysmac Studio to the NA Unit with a USB computer or NA Unit) in the same cable and set the required IP address.
  • Page 156 Set the connection method to an Ethernet Is the connection method hub connection in the Communications set to an Ethernet hub connection in Setup of the Sysmac Studio. Set the Remote the Communications Setup of the IP Address in the Communications Setup. Sysmac Studio?
  • Page 157 Is the same IP address set for the default IP address for the NA Unit or connect more than one node (e.g., the Sysmac Studio to the NA Unit with a USB computer or NA Unit) in the cable and set the required IP address.

  • Page 158: Troubleshooting Na Unit Errors

    5 Troubleshooting 5-2-5 Troubleshooting NA Unit Errors This section describes how to troubleshoot errors in the NA Unit. NA Unit Startup NA Unit symptom Cause Correction The indicator does not Power is not supplied. Confirm the connection location and correctly supply light.
  • Page 159 The IsVisible Check Box Select the IsVisible Check Box in the object properties the screen are not dis- is not selected in the on the Sysmac Studio. played. object settings. If you change the IsVisible property, e.g., from a sub- routine, set it to True.
  • Page 160 Numeric values cannot The upper/lower limit Check the Minimum Value and Maximum Value proper- be input. check for numeric inputs ties of the object on the Sysmac Studio and correct is operating. them as required. When an object is A communications error...
  • Page 161 5 Troubleshooting Output message Cause Correction E_SYS_015: The bat- The battery voltage fell Replace the battery following the procedure given in tery voltage is low. below a certain level dur- 6-2 Replacing the Battery on page 6-5 ing operation. E_SYS_019: XXX must The filtering conditions for Check the set values of the EndTime and StartTime be behind XXX.
  • Page 162 5 Troubleshooting Output message Cause Correction E_RCP_001: Failed to A recipe is set incorrectly. Select the correct template when you save the recipe. import Recipe csv file XXX. Ingredients do not match template XXX. E_SYS_999: Runtime Illegal processing was Restart the NA Unit. Exception Caught XXX performed.
  • Page 163 5 Troubleshooting  Error Codes Correspondence Table The displayed error codes depend on the runtime version. A correspondence table is given below: Error codes prior to runtime Error codes for runtime version version 1.03 1.03 or higher ManE202 E_COM_100, E_COM_101, E_COM_102, or E_COM_103 ManE203...
  • Page 164 5 Troubleshooting 5 - 18 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 165 Maintenance This section describes the required inspections and maintenance. It also describes the service life and replacement procedure for the Battery. 6-1 Periodic Maintenance and Inspection ......6-2 6-1-1 Preparations for Problems .

  • Page 166: Periodic Maintenance And Inspection

     Backing Up the Sysmac Studio Project Always make a backup of the Sysmac Studio project and store it in a safe place. You will need it if you have to send in the NA Unit for repairs or if replace the NA Unit with another NA Unit.
  • Page 167 6 Maintenance Item Inspection Criteria Correction Ambient Check for accumulation of dirt, No accumulation Clean and protect the NA Unit if environ- dust, salt, metal powder, etc. necessary. ment Check for water, oil, or chemi- No spray Clean and protect the NA Unit if cal sprays that may land on the necessary.

  • Page 168: Precautions When Replacing The Na Unit

    6 Maintenance 6-1-3 Precautions When Replacing the NA Unit If you discover a fault in the NA Unit during inspections and must replace the NA Unit, observe the fol- lowing precautions when you replace the NA Unit. • Back up the NA Unit data. If OMRON performs repairs, the data may be deleted. •...

  • Page 169: Replacing The Battery

    If the indicator flashes, connect the Sysmac Studio and see if the _HMI_IsBatteryLow system-defined variable in the Sysmac Studio is True. If it is True, first check the Battery connection in the NA Unit. If the Battery in the NA Unit is properly connected, replace the Battery with a new one as soon as possible.

  • Page 170: Operation Without A Battery

    6 Maintenance Turn OFF the power supply to the NA Unit. If the NA Unit has not been ON, turn it ON for at least five minutes and then turn it OFF. Open the cover on the NA Unit, disconnect the Battery connector, remove the Battery, and replace it with a new Battery.

  • Page 171: Appendices

    Appendices The appendices provide specifications and other information not provided in the body of this manual. A-1 Dimensions ........... A-2 A-1-1 NA Units .

  • Page 172: A-1 Dimensions

    Appendices A-1 Dimensions A-1-1 NA Units NA5-15W  NA Units 194.2 139.1 33.5 69.1 (Unit: mm)  Cable Connection Dimensions 33.9 32.6 34.4 41.6 39.6 42.1 41.2 24.8 47.3 55.7 69.3 (Unit: mm) A - 2 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 173 Appendices NA5-12W  NA Units 194.2 139.1 33.5 69.1 (Unit: mm)  Cable Connection Dimensions 32.6 10.9 10.4 41.6 39.6 42.1 41.2 25.8 24.8 47.3 55.7 69.3 (Unit: mm) A - 3 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 174 Appendices NA5-9W  NA Units 194.2 139.1 33.5 69.1 (Unit: mm)  Cable Connection Dimensions 32.6 41.6 39.6 42.1 41.2 16.6 17.1 24.8 53.3 47.3 55.7 69.3 (Unit: mm) A - 4 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 175 Appendices NA5-7W  NA Units 69.1 (Unit: mm)  Cable Connection Dimensions 32.6 39.6 41.6 42.1 41.2 29.5 24.8 47.3 55.7 69.3 (Unit: mm) A - 5 NA-series Programmable Terminal Hardware User’s Manual (V117)

  • Page 176: A-2 Available Products

    Appendices A-2 Available Products A-2-1 Optional Products Table of Optional Products Name Model Remarks NA-15WKBA04 Anti-reflection Sheets for NA5-15W NA-12WKBA04 Anti-reflection Sheets for NA5-12W Anti-reflection Sheets NA-9WKBA04 Anti-reflection Sheets for NA5-9W NA-7WKBA04 Anti-reflection Sheets for NA5-7W NA-15WATW01 High-pressure waterproofing frame for NA5-15W High-pressure NA-12WATW01 High-pressure waterproofing frame for NA5-12W...
  • Page 177 Appendices NA-WKBA04 Anti-reflection Sheets Attach a Sheet to the screen to protect against diffused reflections and dirt. The entire Sheet is color- less and transparent. Five Sheets are provided in one set. Dimensions Material Attachment method Polyester film Double-sided tape Dimensions (Unit: mm) Model Specification...
  • Page 178 Appendices NA-WATW01 High-pressure Waterproof Attachment The High-pressure Waterproof Attachment (PWA) is required to conform to UL Type 4X standards. The mounting panel thickness must be between 1.6 and 4.5 mm. To conform to UL Type 4X standards, always use the NA5-W with a High-pressure Waterproof Attachment (PWA). If you do not use a PWA, there is a risk of water entry, which may cause severe equipment damage.
  • Page 179 Index I - 1 NA-series Programmable Terminal Hardware User’s Manual (V117)
  • Page 180 Index ABS ................1-21 NA-series Programmable Terminals ......1-2 Anti-reflection Sheets ............. 1-6 NK ................1-21 available products ...........1-5, A-6 Operation Log Viewer ........... 4-31 Battery ................1-6 battery replacement ............6-5 BV ................. 1-21 performance specifications .......... 1-10 periodic inspection ............6-2 power supply connector ..........
  • Page 182 OMRON Corporation Industrial Automation Company Authorized Distributor: Kyoto, JAPAN Contact: www.ia.omron.com OMRON EUROPE B.V. OMRON ELECTRONICS LLC Wegalaan 67-69, 2132 JD Hoofddorp 2895 Greenspoint Parkway, Suite 200 The Netherlands Hoffman Estates, IL 60169 U.S.A. Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 ©...

This manual is also suitable for:

Omron na5-15 101 seriesOmron na5-12 101 seriesOmron na5-9 001 seriesOmron na5-7 001

Table of Contents
