Summary of Contents for Abatement Technologies HEPA-AIRE PAS600
- Page 1 ® HEPA-AIRE Portable Air Scrubber PAS600 Instruction Manual Abatement Technologies, Inc. Abatement Technologies, Inc. Abatement Technologies Limited Georgia, USA Ontario, Canada 800-634-9091 905-871-4720 www.abatement.com PAS600_MN-IB 2018.04.20...
-
Page 2: Table Of Contents
AIRE® Portable Air Scrubber. These instructions must be carefully followed in order to operate the units safely and correctly. If you have any questions regarding the use or care of this equipment call Abatement Technologies at +1 800-634-9091 (U.S.) or +1 905-871-4720 (Canada) for assistance. -
Page 3: Safety Instructions
Warning: To reduce the risk of fire, electric shock, or injury to person observe the following: Use this unit only in the manner intended by Abatement Technologies. If you have questions, contact Abatement Technologies at +1 800-634-9091 (U.S.) or +1 905-871-4720 (Canada). -
Page 4: General Information
Warning: Do not connect the unit’s power cord to a supply receptacle unless the inlet and power modules are in their proper position and latched together. Warning: Abatement Technologies air filtration systems are not intrinsically safe for use in hazardous environments. Always consult a certified industrial hygienist before using them. Do NOT use this... -
Page 5: Alternate Filter (Purchased Separately)
OVG can occur when the adsorption capacity of the filter is reached, replace the carbon filter as soon as odor breakthrough is sensed. More detailed information on carbon adsorption can be found in an article titled: “Activated Carbon: How Is It Used? How Does It Work?” which can be found on the Abatement Technologies website, www.abatement.com. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS 1. The PAS600s require a minimum of 110 volts AC, 60 Hz to operate properly; however, maximum air flow performance requires 120 volts AC, 60 Hz. 2. Due to momentary start-up current surge, the unit requires a 15 amp circuit that is free of other loads. 3. -
Page 7: Key Component Descriptions
KEY COMPONENT DESCRIPTIONS 1. First Stage Filter. 1” Coarse/Particulate Pre-filter (P/N: F621). 6. Filter Access Door. 2. Second Stage Filter. 2” Pleated Particulate Pre-filter (P/N: H502). 7. Control Panel. 3. Alternate Second Stage Filter. 2” High Capacity Carbon Filter 8. Rubber Feet. (P/N: VL1002). -
Page 8: Control Panel
OSHA/CDC requirements. The Abatement Technologies Portable Pressure Monitors are recommended to ensure that requirements are being met. Important Note: Do not operate the unit unless the pre-filter(s) and HEPA filter are installed and the filter access door and panel are in place and closed. -
Page 9: Transporting The Unit
USER SERVICING INSTRUCTIONS Abatement Technologies’ portable air scrubbers are designed to be low maintenance devices and basic maintenance should be performed as follows: Filters should be changed as needed based on the filter change indicator light. Follow the FILTER •... -
Page 10: Filter Change Indicator
Warning: To reduce the risk of fire, electrical shock or personal injury, always turn the unit “OFF” and disconnect the power cord from supply receptacle before replacing the HEPA filter and before cleaning or servicing the unit. Filter Change Indicator The Filter Change Indicator light illuminating indicate one or more of the following: 1. -
Page 11: Component Replacement And Care Of The Unit
5. Close the pre-filter access door and lock it in position. Warning: Use only Abatement Technologies pre-filters, HEPA filters, and replacement parts. Substitute parts void the warranty, jeopardize worker and environmental safety, and adversely affect engineered performance levels. COMPONENT REPLACEMENT AND CARE OF THE UNIT Warning: To reduce the risk of fire, electrical shock or personal injury, always turn the unit “OFF”... -
Page 12: Pas600 Specifications
PAS600 SPECIFICATIONS FEATURE SPECIFICATIONS Net weight with filters: 33.5 lbs. Shipping weight: 42.5 lbs. Unit dimensions: 23.75” L x 18” W x 17.5” H Power supply requirements: Minimum 120 VAC, 60 Hz, 15 A Normal operating amps: 1.9 amps or less Integrated circuit breaker: 12 amps 225 watt motorized impeller with thermal overload protection, auto... -
Page 13: Troubleshooting Guide
Remove carbon filter from polybag. removed from polybag. Note: If the unit does not start or malfunctions after carefully following the TROUBLESHOOTING GUIDE, call Abatement Technologies service department at +1 800-634-9091 (U.S.) or +1 905-871-4720 (Canada) for assistance. -
Page 14: Certification Of Room Air Filtration Units
Nationally Recognized Testing Laboratory (NRTL). LIMITED WARRANTY Abatement Technologies, Inc (ATI) warrants that goods sold to the original user shall be free from defects in material and workmanship for a period of 1 year, except such as are commercially acceptable. This warranty does not include useful filter life. -
Page 15: Pas600 Diagrams
PAS600 DIAGRAMS...
