Oresund
EFC102200
iSCSI to FC Gateway
User Manual
Eli-v4.05.204
Bridgeworks
Unit 1, Aero Centre, Ampress Lane,
Ampress Park, Lymington,
Hampshire SO41 8LW
Tel: +44 (0) 1590 615 444
Email: support@4bridgeworks.com

Advertisement

Table of Contents
loading

Related Manuals for Bridgeworks Oresund EFC102200

Summary of Contents for Bridgeworks Oresund EFC102200

  • Page 1 Oresund EFC102200 iSCSI to FC Gateway User Manual Eli-v4.05.204 Bridgeworks Unit 1, Aero Centre, Ampress Lane, Ampress Park, Lymington, Hampshire SO41 8LW Tel: +44 (0) 1590 615 444 Email: support@4bridgeworks.com...
  • Page 2 • Multi-mode Optical Fibre 50/125 OM4 Patch Cable (LC), up to 550 meters. Or EFC102200RM/TCX-1: Copper Interface Cable (SFP+) • A SFP+ Direct Attached Twin-Ax Copper interface cable, up to 5 meters. Bridgeworks Part Number 017/034. Or EFC102200RM/T: Category (Cat) 6/7 Cable •...

  • Page 3: Table Of Contents

    Table of Contents 1 Introduction 1.1 Manual Layout ........1.1.1 iSCSI Target Device .
  • Page 4 4.1.2.1 Setting the MTU ......23 4.1.2.2 Setting the IP Address ......24 4.1.2.3 Committing the Changes .
  • Page 5 8.6.1 Adding Tasks ........45 8.6.2 Removing/Editing Tasks .
  • Page 6 C.1 Discovering iSCSI Targets ....... . . 76 C.2 Logging into a target ........77 C.3 Logging out of a target .

  • Page 7: Introduction

    Introduction Thank you for purchasing the Bridgeworks Oresund EFC102200 iSCSI to Fibre Channel Gateway.

  • Page 8: Manual Layout

    Manual Layout Throughout the manual, symbols will be used to quickly identify different pieces of information. This icon represents a note of interest about a step or section of information. This icon represents an important piece of information. This icon represents a warning. Care must be taken and the warning should be read thoroughly.

  • Page 9: Logical Unit Number (Lun)

    Note: By convention, ID 7 on the SCSI Bus is reserved by the Server’s Host Bus Adaptor. Logical Unit Number (LUN) Each SCSI device on the SCSI bus can support sub-devices. These are called LUNs. Within the iSCSI Connect Bridge each SCSI ID on the SCSI bus can support 7 LUNs.

  • Page 10: Safety Notices

    Safety Notices This device should only be installed by suitably trained personnel. Protection provided by the equipment may be impaired if used in a manner not specified by the manufacturer. Do not block the enclosure’s vents. Air enters from the front and is exhausted out the back of the device.
  • Page 11 Class 1 Laser Product: Certain models will use a Small Form factor Pluggable (SFP) Transceiver module for connection to an optical network. These devices may use a Class 1 Laser device—it is important that you do not stare into the Laser beam.

  • Page 12: Installing The Efc102200 Gateway

    Installing the EFC102200 Gateway The following are the basic steps to installing the EFC102200: • Connecting the Ethernet cables • Connecting the 10Gb Ethernet cables • Connecting the Fibre Channel Interface • Connecting the Power Supply Connecting the Ethernet Interface The EFC102200 Management Interface can be used on the following network configurations: •...

  • Page 13: Connecting The 10Gb Ethernet Cables

    Rear Panel of the EFC102200 Showing Ethernet Cable Connections Connecting the 10Gb Ethernet Cables Depending on the configuration you have purchased, either one of the following cables will be required for your product. EFC102200RM/T Category (Cat) 6/7 Cable EFC102200RM/OPT Multi-mode Optical Fibre Cable (SFP) EFC102200RM/TCX-1 Copper Interface Cable (SFP+) Using a Multi-mode Optical Fibre Cable (SFP) If you have purchased a 10Gb card with the SFP’s already connected, the following cables may be...

  • Page 14: Using A Copper Interface Cable (Sfp+)

    Insert the multi-mode cables in to the SFP as shown below. When the plug is in the correct position a “click” should be heard. Using a Copper Interface Cable (SFP+) If you are using a copper based solution, an SFP+ Direct Attached Copper (DAC) Twin-Ax interface cable must be used;...

  • Page 15: Using A 10Gbase-T Category 6 Cable (Rj45)

    Note: Speeds other than 10Gb/sec may not be supported by your 10Gb NIC. Using a 10GBASE-T Category 6 Cable (RJ45) If you are using a copper based solution using the RJ45 connector, a Category 6 (or better) Ethernet cable is required, with a maximum length of 100 meters. To connect the EFC102200 to an Ethernet network or directly to a device, connect one side of the Category 6 Ethernet cable into a RJ45 port located on a 10 Gigabit Ethernet card at the back of the unit.

  • Page 16: Connecting The Power Supply

    Note: Only use SFP transceivers that meet or exceed the following standards: EU: IEC/EN 60825-1, North America: FCC, CDRH The following Optical Fibre cables may be used: • Multi-mode Optical Fibre 50/125 OM3 Patch Cable (LC), up to 300 meters. •...
  • Page 17 Note: Before powering up the EFC102200, ensure that all peripherals are properly connected and are powered up, and that you have connected a Management port to your network. To turn on the EFC102200 push the switch on the opposite side to the power connector. The following image shows the switch.

  • Page 18: Using The Web Interface

    Note: JavaScript must be enabled within the web browser to use the web interface. Important: If you choose to use a browser that is not in the list of supported browsers, Bridgeworks cannot guarantee the behaviour of the Gateway’s functionality. Connecting to the Web Interface Note: •...
  • Page 19 If the Gateway fails to receive a DHCP address, the web interface can be accessed from the default http://10.10.10.10/ http://10.10.10.12/ static IP address by navigating to: Important: Your host will likely need to be directly-connected to the Gateway if DHCP is not enabled, and its subnet set appropriately. See Appendix A: Accessing the Gateway from Windows using a static IP Address for help with accessing the Gateway web interface without DHCP.

  • Page 20: Management Console (Home Screen)

    Gateway to become accessible again. The Support link will open up a new tab in your browser at the Bridgeworks website support page. The Help is contextually aware of which page you are currently viewing on the web interface and...

  • Page 21: Gateway Configuration

    Gateway Configuration This section details the configuration of the Bridge’s basic network and service settings. Network Connections This configuration page allows the administrator to configure network interface settings and view network statistics. From the Home screen, select the Network Connections icon under the Bridge Configuration section.

  • Page 22: Global Network Configuration

    Global Network Configuration Hostname In the Hostname field, enter the name you wish to use to address this Gateway. It is a good idea to make the name relevant to the Gateway’s location and/or purpose. You can then access the web interface from this hostname in future, from any DHCP-enabled management interface.

  • Page 23: Setting The Mtu

    Setting the MTU Enabling larger frames on a jumbo frame-capable network can improve your network throughput. Jumbo frames are Ethernet frames that contain more than 1500 bytes of payload (MTU). Before enabling jumbo frames, ensure that all the devices/hosts located on the network support the jumbo frame size that you intend to use to communicate with the Gateway.

  • Page 24: Setting The Ip Address

    Important: Some networking switches require you to specify the size of the jumbo frame (MTU) when enabling, as opposed to a simple enable command. On these switches it might be required to add the necessary bytes needed for the frame header to the MTU size you specify in the Gateway’s port configuration.

  • Page 25: System Password

    The web interface will display the following: System Password This section allows the administrator to change the access password for the web interface. The new password must be between 5 and 65 characters and can contain symbols and numbers. Enter the existing password into the Old Password field; then enter the desired new password into the two following fields.

  • Page 26: Service Control

    You can use your own certifcate & key pair by selecting files to upload with the file-picker buttons. You may upload the key pair as two separate files, or one combined file. Service Control This configuration page allows the administrator to configure network services for the Gateway. From the Home screen, select the Service Control icon under the Bridge Configuration section.

  • Page 27: Simple Network Time Protocol

    Simple Network Time Protocol SNTP is a protocol for synchronising the clock of computer systems. This feature is critical if you are planning on using the scheduler or useful when viewing the logs to determine when an event occurred. Refer to Section 8.2: System Log for more information.

  • Page 28: Simple Mail Transfer Protocol (Smtp)

    Simple Mail Transfer Protocol (SMTP) for information on SMTP settings. To enable email alerts on the Gateway, select the Enable Email Alerts checkbox. The two following fields should then be completed: Recipient Email Address The email address/addresses to which the emails will be sent. Multiple email addresses can be specified, separated by a semicolon, e.g.: office@example.com;...
  • Page 29 To enable this feature, select Use iSNS, and enter the IP address or hostname of the iSNS Server with which to register in the iSNS Server field. Then click Save to apply changes.

  • Page 30: Iscsi Target Configuration

    iSCSI Target Configuration The iSCSI Target page of the web interface, allows the administrator to configure mutual CHAP authorisation, and TCP ports of each iSCSI target interface. From the Home page of the web interface, select the iSCSI Target icon under the Devices and Protocols section.

  • Page 31: Network Interfaces

    Initiator Secret This is the password defined on the initiating host. This must be 12 to 16 characters long. This should only be entered if mutual CHAP is enabled on the initiating host. Target Secret This is the password that must be entered on the initiating host. This must be 12 to 16 characters long.
  • Page 32 This page lists current connections to iSCSI initiators. The IQN of the initiator is shown in the Initiator column, and the IQN of the device it is logged on to is shown in the Target column. See Section 1.1.2: iSCSI Qualified Name (IQN) for more information.

  • Page 33: Fibre Channel Initiator Connections

    Fibre Channel Initiator Connections The configuration page shown below will allow the administrator to configure ports designated as Fibre Channel Initiator interfaces. From the Home screen of the web interface, select the FC initiator icon from the Devices and Protocols section. You will see the following page: This page lists each Fibre Channel port which has been designated as an initiator.
  • Page 34 Display status information for this Fibre Channel port allows you to see verbose information about the Fibre Channel port. Configuration settings allows you to manually configure the Link Speed and Port Topology: 1. The Link Speed drop down menu has the following options: Auto, 2 Gbit, 4 Gbit, and 8 Gbit.
  • Page 35 The default configuration type is set to Automatic. Using the Configuration Link drop down, you can change this to manual. This allows you to enable or disable each individual target on the Fibre Channel link. Select the FC target by clicking on its World Wide Port name, and then click enable or disable.

  • Page 36: Scsi Device Management

    SCSI Device Management The SCSI Device Management page of the web interface allows the administrator to view details of devices connected to the EFC102200. Viewing Attached Devices From within the Home screen of the web interface, select the SCSI Device Management icon under the Devices and Protocols section.

  • Page 37: Viewing Device Mappings

    Viewing Device Mappings Clicking on the Mappings option in the menu on the left-hand side of the page will display information about all connected devices, as shown in the following image.
  • Page 38 A target entry exists on this page for each device that is presented on the system. By clicking on the blue triangle in the Device Info section you can display further information about each device.

  • Page 39: Gateway Maintenance

    Gateway Maintenance The following section describes the various pages that are available to the administrator to monitor performance and maintain the Gateway. System Information The System Information page allows the administrator to view the performance of the Gateway. From the Home screen, select the System Information icon from the Bridge Maintenance section. The following page will be displayed: In the Bridge &...

  • Page 40: System Log

    iSCSI IQN is the iSCSI Qualified Name of that specific EFC102200. Uptime is the amount of time the EFC102200 has been powered on for. The System Performance section contains three meters which provide an approximation of the following performance parameters: Data Throughput This indicates the current performance in MB/s.

  • Page 41: Load/Save Configuration

    Below the log display pane are two options: Click Here to Download This will download the log file to your local machine. Clear System Log This will clear all logs within the Gateway. For information on troubleshooting your Gateway, see Chapter 9: Troubleshooting. Load/Save Configuration Saving the Configuration to Disk Once you have finished configuring your Gateway we recommend that you save your configuration...

  • Page 42: Restore To Factory Defaults

    The following page will be displayed: To save the configuration data, click on the Click here to Download link from within the Export Configuration subsection. Then choose to save the file. The Gateway will now download an encoded file that contains all of its configuration settings. To reload the configuration, click on the Browse button and locate the configuration file to upload to the Gateway.
  • Page 43 Gateway. It is recommended to check for new versions of the firmware downloadable from the Bridgeworks web site at: http://www.4bridgeworks.com/support/download-firmware/ Warning: Do not load on a firmware which has an earlier release revision unless you have been instructed to by the Bridgeworks support team. Always ensure that you have the correct firmware for your product.

  • Page 44: Diagnostics

    Important: If an issue arises with your EFC102200, check Chapter 9: Troubleshooting for information on how the issue may be resolved. Note: The following instructions are demonstrated in the Bridgeworks Support https: Video “WANrockIT: Downloading Diagnostic Information” found at //www.youtube.com/watch?v=8RZXFGCy3ZU.

  • Page 45: Adding Tasks

    From the Home screen, select the Task Scheduler icon from the Bridge Maintenance section. The web interface will now display the following: Adding Tasks Tasks can be added by clicking on the Add New Scheduling Task button, which will start the task wizard.
  • Page 46 Clicking on a task will expand it as shown: Clicking the Remove button will remove the task from the task scheduler. Clicking the Edit button will start the task wizard for the task, allowing it to be edited.

  • Page 47: Task Wizard

    Task Wizard The task wizard will guide you through the adding or editing of scheduled tasks. There are a few common buttons across the individual sections of the wizard: Help Clicking this button will display the Online Help page for the Task Scheduler. Cancel Clicking this button will discard the changes being made to the task and close the wizard.

  • Page 48: Trigger

    Trigger On the Trigger section of the wizard, you can pick the frequency of the event. The options are: Once This means the action will be performed at the specified time and not repeat. Daily This means the action will be performed every day at the specified time. Weekly This means the action will be performed on specified days every week at the specified...

  • Page 49: Start Date

    time. When selecting this option, you will be able to pick which days to trigger the action by selecting checkboxes. Each day will have its own checkbox, as shown: Start Date On the Start Date section of the wizard, you can pick the starting date and time for the new task. Enter a time into the Time for the first trigger box and select your start date using the calendar.

  • Page 50: End Date

    End Date On the End Date section of the wizard, you can pick the end date for the new task. You can either select the Ongoing Event checkbox for a task that should run until cancelled, or select a date using the calendar.
  • Page 51 On the Summary section of the wizard, a brief description of the task will be displayed. If you are happy with this task, click the Save button to add the task to the task scheduler. Saving will automatically close the wizard.

  • Page 52: Troubleshooting

    If none of the above resolves your problem, then after consulting with your Network Administrator, please contact support. See Appendix D: Useful Links for information on how to contact Bridgeworks Support. Device Related Problems Once the Gateway has finished booting up, and the target devices have finished initialising, these devices should be available on the host machine.

  • Page 53: Poor Performance

    If none of the above resolves your problem, please contact support. See Appendix D: Useful Links for information on how to contact Bridgeworks Support. Poor Performance Poor performance can be caused by many differing reasons. The following checklist is provided as a guide to where you may find ways to improve performance.

  • Page 54: Lost Ip Address

    The utility “LAN Scan” can be used to find any device irrespective of its IP address. This can be helpful in determining the IP address of a Bridgeworks device with an unknown IP address and for checking the number of Bridgeworks devices on a network.

  • Page 55: Appendix A Accessing The Gateway From Windows Using A Static Ip Address

    Accessing the Gateway from Windows using a static IP Address This appendix describes how to configure a Windows host to access the Gateway’s web interface from its default static IP address, if DHCP is not enabled on the Gateway. Windows Server 2003 If your computer is running Windows Server 2003, follow the instructions below.
  • Page 56 A general status page will be displayed. From within this page select Properties. Select the Internet Protocol (TCP/IP) entry and then Properties.
  • Page 57 Make a note of your current set up, then: 1. Click Use the following IP Address. 2. Enter 10.10.10.11 into the IP Address field. 3. Enter 255.255.255.0 into the Subnet Mask field. 4. Finally click the OK button.

  • Page 58: Windows Vista, Server 2008 Or 7

    Note: Once you have completed the initial set up of the Gateway, return your computer to the original settings and reconnect to the Gateway. Windows Vista, Server 2008 or 7 If your computer is running Windows, Vista or 7 follow the instructions below. From the Start menu, select Control Panel.
  • Page 59 A general status page will be displayed. From within this page select Properties. Select the Internet Protocol Version 4 (TCP/IPv4) entry and then Properties.
  • Page 60 Make a note of your current set up, then: 1. Click Use the following IP Address. 2. Enter 10.10.10.11 into the IP Address field. 3. Enter 255.255.255.0 into the Subnet Mask field. 4. Finally click the OK button. Note: Once you have completed the initial set up of the Gateway, return your computer to the original settings and reconnect to the Gateway.

  • Page 61: Appendix B Connecting To An Iscsi Device Using The Microsoft Iscsi Initiator

    Connecting to an iSCSI Device using the Microsoft iSCSI Initiator There are many iSCSI Initiators available. However, for the purpose of this user guide we shall concentrate only on the Microsoft iSCSI Initiator. In this example we have used the Microsoft iSCSI Initiator that is available with Microsoft Vista.

  • Page 62: Discovery Of Devices

    Enter in the CHAP (Initiator) Secret and click OK. The secret should be between 12 and 16 characters. Make a note of this secret as you will need to enter this as part of configuring CHAP on the iSCSI Gateway. Discovery of Devices Before you can connect to an iSCSI Target, the iSCSI targets must be discovered.

  • Page 63: Adding An Iscsi Target Portal

    • Adding an iSCSI target portal and directly performing a discovery; • Adding an iSNS server to which the target portal is registered. Adding an iSCSI Target Portal To add an iSCSI Target portal, click on Add Portal. You should now be presented with the following window: Enter the IP address for the iSCSI Target.
  • Page 64 The Connect by using section allows you to specify which iSCSI adapter to use and the Source IP. The Local adapter should only differ from Microsoft iSCSI Initiator if an iSCSI offload card has been installed. For the purpose of this guide, we shall only use the Microsoft iSCSI Initiator. Leaving this setting as Default will also use the Microsoft iSCSI Initiator.

  • Page 65: Adding An Isns Server

    Note: For mutual CHAP to be performed, the Initiator Secret must be set on the general tab, and be the same as the one configured on the iSCSI Gateway. Note: The use of RADIUS is beyond the scope of this guide. Once you are satisfied that all advanced options are correct, click OK.

  • Page 66: Connecting To A Target

    Enter the address of the iSNS server with which your iSCSI Gateway is registered, then click OK. The Microsoft iSCSI Initiator will now query the iSNS server and perform discoveries on registered target portals. Click on the Targets tab. The discovered devices should now be listed. In this example two iSCSI targets have been discovered.
  • Page 67 If you wish to reconnect to the target automatically when this Windows server reboots, select the Automatically restore this connection when the computer starts checkbox. Click on the Advanced button to see the advanced settings. The following window should appear: The Advanced Settings page is the same as that of the discovery except for one addition.
  • Page 68 Interfaces subsection, on the iSCSI Target page of the iSCSI Gateway’s web interface: See Chapter 5: iSCSI Target Configuration for more information. Important: If you wish to connect to a target over multiple network interfaces, see Appendix B.5: Creating Multiple Connections (Optional).

  • Page 69: Viewing Iscsi Session Details

    Viewing iSCSI Session Details When you have connected to an iSCSI Target, you can check that the device is connected by clicking on the Details button. The following window will appear:...

  • Page 70: Creating Multiple Connections (Optional)

    In this window you can view the iSCSI Sessions associated to the iSCSI Target, how many connections are attached to each iSCSI Session, and the Target Portal Group. If you click on the Device tab, details of the target device will be displayed. Here for example, we can see that the device is an IBM LTO Tape drive.
  • Page 71 Click on the Connections button to open the Session Connections window: This shows how many iSCSI Connections are active and the type of load balance used. For all iSCSI Sessions, there will be at least one leading connection. iSCSI connections can be added and removed at any time, all apart from the leading connection, which can only be removed when the iSCSI Session is logged off.
  • Page 72 Note: The Load balance policy specifies how the data is distributed over multiple connections. The main policies that should be used are Round Robin and Fail Over Only: Round Robin will utilize all connections for data and evenly distribute the data.
  • Page 73 In the Connect by using section, select the Source IP address and the Target portal address for the new connection. In most instances these should be different from the source and target addresses of the original connection. In this example we have connected to 10.10.10.50 / 3260 as the leading connection, and the second connection will be 10.10.11.50 / 3260.
  • Page 74 Note: Up to 8 connections can be added to one session. Once you have completed setting up the connections, click OK to return to the Target Properties page. Under Session Properties, you will see that the Connection count field value has increased:...

  • Page 75: Logging Off An Iscsi Session

    Now click on OK to return to the Microsoft iSCSI Initiator main window. Important: If you have been experiencing a performance decrease when transferring data to more than one device using multiple connections, please refer to Chapter 9: Troubleshooting. Logging off an iSCSI Session To log off an iSCSI Session, follow the following procedure.

  • Page 76: Appendix C Connecting To An Iscsi Device Using Iscsiadm

    Connecting to an iSCSI Device using iscsiadm Important: The iscsiadm command may require root privileges to function. This guide will assume that the user has root privileges. Discovering iSCSI Targets To get a list of available targets on the Gateway, run a discovery using the following command: iscsiadm -m discovery -t st -p <Target IP Address>:<Port Number>...

  • Page 77: Logging Into A Target

    Logging into a target Once you have discovered the available targets, you can then login to the target. The following command will allow you to login to an individual target: iscsiadm -m node -T <Complete Target Name> -I -p <Target IP Address>:<Port Number> The example below shows logging into the discovered target iqn.2002-12.com.4bridgeworks.001c03:naa.500110A001104E3C.0:...
  • Page 78 When you have successfully logged in to the target device, the screen should update as shown below: To login to all targets found, the following command can be used: iscsiadm -m node -l...

  • Page 79: Logging Out Of A Target

    Logging out of a target To log out of an individual target enter the following command at the prompt: iscsiadm -m node -u -T <Complete Target Name> -p <Target IP Address>:<Port Number> When you have successfully logged out of the target device, the screen should update as shown below:...

  • Page 80: Logging Out Of All Targets

    Logging out of all targets To log out of all targets enter the following command at the prompt: iscsiadm -m node -u...
  • Page 81 When you have successfully logged out of the targets, the screen should update as shown below:...

  • Page 82: Appendix D Useful Links

    Bridgeworks Support If you continue to experience problems with the EFC102200, please contact support at http://www.4bridgeworks.com/support/. Bridgeworks Support Videos These videos will guide you through some of the instructions found in this manual. https://www.youtube.com/user/SANSlide/. http://www.4bridgeworks.com/ Product Manuals The latest product manuals can be found at support/user-manuals/.
  • Page 83 Technical Specifications Physical Form Factor 19 rack mount Overall Depth 673.3mm with redundant PSU, 656.2mm with cabled PSU Rack Depth Required 612.6mm Height 42.8mm Width 482.4mm with rack latches Weight 19.3kg at maximum configuration Recommended minimum 100mm on front and rear faces clearance for cooling Electrical Input voltage...
  • Page 84 Fibre Channel Link & Status...
