Model VF5720***/VF5718*** Language English Page 22 2/1 Material 100g Date 2009/01/08 Part No. MFL56848301 Chage Record Change content Color(cover/body) Size(W*H) 145*215 Designer LIU GUANG QUAN Description MANUAL,OWNERS Designer Confirm Date ECO No.
INFORMATION FOR YOUR SAFETY...3-4 PARTS AND FEATURES ...5 TELESCOPIC HANDLE RELEASE ...6 CORD RELEASE ...6 SWITCH OPERATION ...7 BODY RELEASE AND POSITIONS ...7 RECOMMENDED PILE HEIGHT SETTINGS ...7 ATTACHMENT USE CHART ...8 VACUUMING TIPS ...8 ATTACHMENTS ...8 PERFORMANCE FEATURES...10 VACUUM CLEANER CARE Vacuum Storage ...11 Dust bin assembly...11 Dust bin cleaning ...12...
Do not use the vacuum cleaner If the power cord is damaged or faulty. If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard. Do not unplug by pulling on cord.
INFORMATION FOR YOUR SAFETY Thermal protector: This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the cleaner suddenly shuts off, turn off the switch and unplug the cleaner. Check the cleaner for a possible source of overheating such as a full dust chamber, a blocked hose or clogged filter.
It is important to know your vacuum cleaner’s parts and features to assure its proper and safe use. Review these before using your cleaner. Telescopic release lever Quick release cord hanger Crevice tool Body release pedal Cord hook Motor protector PARTS AND FEATURES Telescopic handle Switch...
TELESCOPIC HANDLE RELEASE Release the telescopic handle by pulling telescopic release lever up with fingers and pulling up the telescopic handle. To lower the telescopic handle pull the telescopic release lever up with fingers and push down on the telescopic handle. Note : For your convenience, adjust telescopic handle height properly to your height.
Switch operation • Off • Floor: Hard floors (Agitator off) • Carpet: Agitator on WARNING Personal injury hazard To avoid personal injury, do not turn switch On/Off if the vacuum or your hand is wet. BODY RELEASE AND POSITIONS Release the vacuum body by pressing down on the body release pedal with your foot and pulling back and down.
ATTACHMENT USE CHART ATTACHMENT DUSTING BRUSH CREVICE TOOL MINI NOZZLE (Option: ONLY VF5720***) * Always clean attachments before using on fabrics. * The attachments are subject to change according to the buyer's request. Carpet edges Use attachments such as crevice tool, dusting brush, Mini-nozzle on carpet edges.
Page 10
Dusting brush: Functions as a dusting brush,also an upholstery nozzle which is useful for furniture, shelves etc. Attach as shown. Crevice tool: Crevice tool is attached as shown and used for corners, between cushions etc. Note : For added reach the dusting brush can be used with crevice tool as shown.
PERFORMANCE FEATURES Motor protector This vacuum has a motor protector bypass valve which automatically opens to provide cooling air to the motor when a clog prevents the normal flow of air to the motor. If the by- pass valve opens to prevent motor overheating and possible damage to the vacuum, you will notice a change of sound as air rushes through the valve opening.
VACUUM CLEANER CARE Always follow all safety precautions when cleaning and servicing the vacuum cleaner. WARNING Electrical shock and personal injury hazard. Disconnect electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. To store the vacuum cleaner when it is not used, assemble its cord and return its telescopic handle to its lower space saving...
For best performance always empty the dust bin when the dust is full. WARNING Electrical shock and personal injury hazard. Always unplug power cord from electrical outlet before performing any service on vacuum. When the alarm sounds, check the dust bin. If the dust bin is full, empty the dust bin.
FILTERS CLEANING / CHANGING Filter cover button Filter frame Dust bin cover Press the filter cover button and separate the filter frame and the filter from the dust bin cover as shown. Clean the filter frame and the filter in cold water only.
BELT CHANGING AND AGITATOR CLEANING WARNING Electrical shock and personal injury hazard. Disconnect electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. Frequently check and remove hair, string, and lint build-up in the agitator brush area.
Remove string or hair that may be wrapped around the agitator. WARNING Be careful when removing the agitator as the belt tension is high. Failure to do so could result in personal injury from the agitator releasing quickly and snapping away. TO REPLACE BELT Seat the right end of agitator into nozzle base.
Unplug power cord from wall outlet. Clean exterior using a clean, soft cloth that has been dipped in a solution of mild liquid detergent and water and wrung dry. The hose located on the vacuum cleaner carries the dirt from the nozzle up to the dust bin.
Review this chart to find do-it-yourself solutions for a minor performance problems. Additional service needed, other than those described in this owner's manual, should be performed at an authorized LG Electronics Service agency. WARNING Electrical shock and personal injury hazard.
