- Page 1 OWNER’S MANUAL REFRIGERATOR Please read this manual carefully before operating your set and retain it for future reference. www.lg.com P/N: MFL62880461 _REV01...
- Page 3 Electrical Connections (In the UK Only) Important The wires in this mains lead are coloured in accordance with the following code: As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol( Green or Green and Yellow.
-
Page 4: Table Of Contents
Table of contents Introduction Introduction Important safety instructions Where to install Installation Door removal Door replacement Feed water pipe installation Height adjustment Starting Operation Adjusting the temperature and functions Refreshment center (Applicable to some models only) No Plumbing Ice & Water (Applicable to some models only) Shelf (Applicable to some models only) Wine holder (Applicable to some models only) Egg box... -
Page 5: Introduction
Introduction Entry The model and serial numbers are found on the inner case on the back or one side of the refrigerator compartment of this unit. These numbers are unique to this unit and are not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 6 Child entrapment DANGER: Risk of child entrapment. Warning Before you dispose of your old refrigerator please remove doors but leave the shelves in place so that children cannot climb inside. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 7: Identification Of Parts
Introduction Identification of parts *Non dispenser model - Type 1 Space plus Door rack Shelf Lamp Shelf Ice Maker Door rack Drawer Door rack Lower cover *Non dispenser model - Type 2 Door rack Shelf or drawer Lamp Shelf or drawer Door rack Drawer (2 or 3) Door rack... - Page 8 *Dispenser model - Type 1 Freezer Compartment Space plus Door rack Automatic ice maker Lamp Shelf Door rack Drawer Door rack Lower cover NOTE • Parts, features, and options vary by model. Your model may not include every option. *Dispenser model - Type 2 Freezer Compartment Space plus...
- Page 9 Introduction *Dispenser model - Type 3 Extra door rack(option) Automatic Icemaker Shelf Lamp (bulb/LED) Shelf or Drawer Door rack Drawer (2 or 3) Door rack Lower cover *Dispenser model - Type 4 Extra door rack (option) Automatic Icemaker Shelf Lamp (bulb/LED) Shelf Door rack Drawer (2 or 3)
-
Page 10: Installation
Where to install 1. Place your appliance where it is easy to use. Select a good 2. Avoid placing the unit near heat sources, di- location rect sunlight or moisture. Do not operate the appliance outdoors where it can be exposed directly, or indirectly to sun, wind and rain. -
Page 11: Door Replacement
Installation 3) Remove the freezer compartment door by lifting it upward. The door should be lifted high enough for the feed water pipe tube to be completely pulled out. • If you have removed the refrigerator compartment door to pass the appliance through an access door, lay the door down, but be careful not to damage the feed water pipe tube. -
Page 12: Feed Water Pipe Installation
Feed water pipe installation (Dispenser model only) Before ▪Automatic ice maker operation needs water pressure of 147~834kPa (1.5~8.5kgf/cm2) (The pressure is correct when an instant paper cup (180cc) is installation filled in 3 sec.). ▪If water pressure does not reach the rating 147kPa(1.5kgf/cm is necessary to purchase a separate pressure pump for normal automatic icing and cool water feed. - Page 13 Installation The refrigerator doors will close smoothly by adjusting the front side using the After levelling height adjustment screw. If the doors do not close correctly, performance may be the door height affected. 1. Wipe off all dust accumulated during shipping and clean your appliance Next thoroughly.
-
Page 14: Operation
Starting When your r rigerat temperatur Optional Type-1 Type-2 Type-3 NOTE Your model may not include every option. ay Type - 3: The contr ay panel ma d, allow it t rior t nterrupted, wait 5 minut ore r temperatur Type 1 Function display board rated by touch. - Page 15 Operation *Non dispenser model - Type 2 Optional Type-1 Display Power Saving Mode Type-2 NOTE Your model may not include every option. Refreshment Centre Button Refreshment Centre (Applicable to some models only) Function display board...
- Page 16 *Dispenser model - Type 1 Water/Ice output Dispenser push switch Optional Type-1 Type-2 Type-3 Type-4 NOTE Your model may not include every option. moisture on the display panel may cause a malfunction. Please keep display clean and dry. Function display board LIGHT/ LIGHT/ ay Type - 3 and Type - 4: The control display is operated by touch.
- Page 17 Operation *Dispenser model - Type 2 Water/Ice output Dispenser push switch Dispenser Lamp (hidden) Optional Type-1 Type-2 Type-3 NOTE • Your model may not include every option. Function display board Display Power Saving Mode Display Power Saving Mode Display Power Saving Mode Refreshment Center Button Refreshment Center...
- Page 18 This function save the display power Display power- Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for saving (on some 5 seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When model) the power saving mode is activated, the display will remain off until the next time the door is opened.
- Page 19 Operation *Dispenser model - Type 3 Water/Ice output Dispenser push switch Dispenser Lamp (hidden) Type 1 Type 2 Type 3 Display Power Saving Mode NOTE • Your model may not include every option. • The control display panel is operated by touch. Excessive moisture on the display panel may cause a malfunction.
- Page 20 Display Power Saving Mode Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for 5 seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.
- Page 21 Operation It is possible to select water or ice Dispenser use *Select water and cubed ice by pressing the (on some model) relevant button *Activate the dispenser by using a cup to press against it The function selected is highlighted on the panel.
- Page 22 Door mounted automatic icemaker (on some model) The icemaker automatically makes 6 cubes of ice at any one time, which equals approximately 50-60 cubes per day. These quantities, however, may vary according to climatic conditions. E.g. the duration and amount of times the refrigerator door is opened.
- Page 23 Operation When the ice dispenser will not operate properly It is normal that the ice maker will not operate correctly when there is only a small amount of ice left in the storage bin. Allow approximately one day for the ice maker to restock.
- Page 24 Express Freeze Please select this function for fast freezing. OFF ON OFF is repeated whenever pressing The arrow graphic remains On after flickering 4 times when selecting Express Freeze Express Freeze will automatically turn off after a fixed time passes. Lock This button locks the other buttons Locking or Release is repeated whenever...
- Page 25 Operation Door open warning The other A warning bleep will sound 3 times every 30 seconds if the main or minibar door is functions left open or ajar for more than a minute. Please contact your local service centre if the warning continues to sound when the door is closed.
-
Page 26: Refreshment Center (Applicable To Some Models Only)
Freezer basket Two stars section (two stars section) Two stars means the temperature in the section is -12°C~ -18°C. Freezer foods for short-term storage. Refreshment center(Applicable to some models only) Open the minibar door. You can access the minibar without How to use opening the refrigerator door, thus saving electricity. -
Page 27: No Plumbing Ice & Water (Applicable To Some Models Only)
Operation No Plumbing Ice & Water (Applicable to some models only) You can use the water in the water tank or general water bottles to use the Auto Ice Maker function and Water Dispenser function without having to connect the water pipe to the refrigerator. -
Page 28: Shelf (Applicable To Some Models Only)
Shelf (Applicable to some models only) Folding Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder (Applicable to some models only) Wine holder Bottles can be stored laterally with this... -
Page 29: Humidity Control In The Vegetable Compartment
Operation Humidity control in the vegetable compartment (Applicable to some models only) The humidity can be controlled by adjusting the humidity control switch to the left/right when storing vegetables or fruits. High humidity Low humidity Convert into a vegetable or meat compartment (Applicable to some models only) The bottom drawer in the refrigerator can be converted into a vegetable or meat compartment... -
Page 30: Deodorizer(Applicable To Some Models Only)
Deodorizer (Applicable to some models only) This system efficiently absorbs strong odours by using an optical catalyst. This system does not have any affect on stored food. How to use the The deodoriser is located behind the vegetable compartment. It can be removed for cleaning with soapy warm water from time to time. -
Page 31: Opti Temp Zone Temperature Transition Corner (Applicable To Some Models Only)
Operation Opti Temp Zone Temperature Transition Corner (Applicable to some models only) By pressing the button, store vegetables, fruits or other types of food such as defrosting meat, raw fish, etc. Temperature Change at Opti Temp Zone (Applicable to some models only) Method to use You can select optimum temperature range depending on types of foods... -
Page 32: Suggestion On
Location of foods (Refer to identification of parts) Wine holder Store wine. Snack drawer Store small foods such as bread, snacks, etc.. Freezer Store various frozen foods such as meat, fish,ice cream, compartment frozen snacks, etc.. shelf Freezer Store small packed frozen food. compartment Temperature is likely to increase as door opens. -
Page 33: Storing Foods
Suggestion on food storage Storing foods Freezer Compartment - You may get chill blains, and glass containers may break when frozen, causing Refrigerator Compartment Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavour. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 34: Care And
How to dismantle parts NOTE Freezer compartment lamp Refrigerator compartment lamp NOTE Freezer compartment ② shelf Door rack and support Ice storage bin (Applicable to some models only) After dispenser is used (Applicable to some models only) ntle by rev rt . - Page 35 Care and maintenance Refreshment centre (Applicable to some models only) Vegetable compartment cover Vacuum Fresh (Applicable to some models only) Space Plus (Applicable to some models only) Ice storage bin (Applicable to some models only) Ice maker (Applicable to some models only) ①...
-
Page 36: General Information
General information Vacation time During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odour formation. -
Page 37: Trouble Shooting
Care and maintenance General information Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Running of refrigerator Refrigerator control is off. Refrigerator Refrigerator is in defrost cycle. - Page 38 Occurrence Refrigerator compressor Thermostat is keeping the refrigerator at a does not run constant temperature. Temperatures are too cold Temperature in the Freezer control is set too cold freezer is too cold but refrigerator temperature is satisfactory. Temperature in the Refrigerator control is set too cold refrigerator is too cold but freezer...
- Page 39 Care and maintenance Occurrence Sound and noise Louder sound levels when Today’s refrigerators have increased refrigerator is on. storage capacity and maintain more even temperatures. Louder sound levels Refrigerator operates at higher pressures when compressor during the start of the ON cycle. comes on.
- Page 40 Occurrence Odours in refrigerator Interior needs to be cleaned. Food with strong odour is in the refrigerator. Some containers and wrapping materials produce odours. Opening/Closing of doors/Drawers Door(s) will not close. Food package is keeping door open. Door was closed too hard, causing other door to open slightly Refrigerator is not level.
-
Page 41: Disposal Of Your Old Appliance
Care and maintenance Occurrence Dispenser will not Ice has melted and frozen around auger due dispense ice. to infrequent use, temperature fluctuations and/or power outrages. Ice dispenser is Ice cubes are jammed between the icemaker jammed. arm and back of the bin. Ice cubes are frozen together.
