- Page 1 HW-J4000 HW-JM4000 User manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
-
Page 2: Getting Started
GETTING STARTED GETTING STARTED SAFETY INFORMATION ● The following also applies to the Wireless Subwoofer (PS-WJ4000). SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash and arrowhead within the triangle CAUTION indicates that there is dangerous voltage Inside the... - Page 3 GETTING STARTED FCC NOTE (for U.S.A): Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Class B FCC Statement Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) The included module(s) has been tested and found to that produce heat.
- Page 4 GETTING STARTED PRECAUTIONS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches).
-
Page 5: Table Of Contents
GETTING STARTED CONTENTS GETTING STARTED 26 FUNCTIONS Safety Information Input Mode What’s Included Bluetooth Software Update DESCRIPTIONS 32 TROUBLESHOOTING Top / Front Panel Rear / Bottom Panel Troubleshooting Remote Control 33 APPENDIX 12 INSTALLATION Specifications Installing the Soundbar Installing the Wall Mount Placing the Soundbar on a TV stand Figures and illustrations in this User Manual are Installing the Soundbar as a Free-Standing... -
Page 6: What's Included
GETTING STARTED WHAT’S INCLUDED BEFORE READING THE USER’S MANUAL Note the following terms before reading the user manual. + Icons used in this manual Icon Term Definition Caution Indicates a situation where a function does not operate or settings may be canceled. Note Indicates tips or instructions on the page that help you operate a function. -
Page 7: Descriptions
DESCRIPTIONS DESCRIPTIONS TOP / FRONT PANEL VOL. - / + (Power) Button Controls the volume level. The numeric value of the volume level Turns the power on and off. appears in the front panel display. (Source) Button Display Selects the D.IN, AUX, HDMI, BT, TV, or USB Displays the current mode. -
Page 8: Rear / Bottom Panel
DESCRIPTIONS REAR / BOTTOM PANEL AUX IN HDMI IN Connect to the Analog output of an external Inputs digital video and audio device. signals simultaneously using an HDMI cable. Use when connecting a supported external device. OPTICAL IN (D.IN) HDMI OUT (TV-ARC) Connect to the digital Outputs digital video and (optical) output of an... -
Page 9: Remote Control
OFF - ANYNET+, ON - ANYNET+ The Anynet+ function lets you control the Soundbar with the remote from an Anynet+ compatible Samsung TV. The Soundbar must be connected to the TV via an HDMI cable. Press and hold the button for about 5 seconds to turn the Auto Power Link function on or off. - Page 10 DESCRIPTIONS Power Turns the Soundbar on and off. Volume Adjusts the volume level of the unit. Play / Pause Press the p button to pause a file temporarily. Press the p button again to play the selected file. Skip Back If there is more than one file on the device you are playing, and you press the [ button, the previous file is selected.
- Page 11 DESCRIPTIONS + Controlling the Soundbar using Your TV Remote Control 1. Press and hold the SOUND button for more than 5 seconds while the Soundbar is turned on. 2. "ON - TV REMOTE" appears on the Soundbar's display. 3. In the TV's menu, set the TV speaker to external speaker. ●...
-
Page 12: Installation
INSTALLATION INSTALLATION INSTALLING THE SOUNDBAR INSTALLING THE WALL MOUNT + Installation Precautions ● Install on a vertical wall only. ● For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the weight of the set. - Page 13 INSTALLATION Center Line Center Line 2. Mark the location where the screws will go through on the wall, and then remove the installation guide. Next, drill holes for the screws using an appropriately sized drill bit. 3. Fasten the 2 Bracket-Wall pieces firmly to the wall at the marked locations using the appropriate screws. 4.
- Page 14 INSTALLATION 5. Insert a Holder-Fix Mount into each hole on the product’s bottom side. Tighten each Holder-Fix Mount to fix the Soundbar to the 2 Bracket-Wall pieces. ● Do not hang onto the installed unit and avoid striking or dropping the unit. ●...
-
Page 15: Placing The Soundbar On A Tv Stand
INSTALLATION PLACING THE SOUNDBAR ON A TV STAND Place the Soundbar on a TV stand. 1. Align the Soundbar’s center with the center of the base of the TV, and then carefully push it onto the stand as far as it will go, as shown in the illustration. Be careful not to unbalance the TV. INSTALLING THE SOUNDBAR AS A FREE-STANDING UNIT 1. -
Page 16: Connections
CONNECTIONS CONNECTIONS ● Do not connect the power cord of this product or your TV to a wall outlet until all connections between components are complete. ● Before moving or installing this product, be sure to turn off the power and disconnect the power cord. CONNECTING THE SUBWOOFER CONNECTING TO THE SUBWOOFER AUTOMATICALLY The Subwoofer's linking ID is preset at the factory and the main unit and subwoofer should link (connect wirelessly) - Page 17 CONNECTIONS ● Before moving or installing the product, be sure to turn off the power and disconnect the power cord. ● If the main unit is powered off, the wireless subwoofer will in standy mode and the STANDBY LED on the front will blink Red directly.
-
Page 18: Connecting The Swa-8000S (Sold Separately)
CONNECTIONS CONNECTING THE SWA-8000S (SOLD SEPARATELY) ● Expand to true wireless surround sound by connecting the Samsung Wireless Rear Speaker Kit (SWA-8000S) to your Soundbar. (Sold separately) ● Before connecting to the Wireless Receiver Module, connect your subwoofer first. ● Use the speaker cable to connect the wireless receiver module to the speakers. - Page 19 CONNECTIONS CONNECTING THE SURROUND SPEAKERS (SOLD SEPARATELY) SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3Ω ID SET Surround Speaker (L) Surround Speaker (R) Wireless Receiver Module ● Place these speakers to the side of your listening position. If there isn't enough room, place these speakers so they face each other.
-
Page 20: Connecting To A Tv
CONNECTIONS CONNECTING TO A TV ● Important: Before you begin, put the battery into the remote. See page 11 for instructions. CONNECTING TO A TV USING A DIGITAL OPTICAL CABLE Optical Cable OPTICAL OUT OPTICAL IN DC 14V HDMI IN AUX IN HDMI OUT 5V 0.5A... -
Page 21: Connecting To A Tv Using An Hdmi (Digital) Cable
● Anynet+ must be turned on. ● This function is not available if the HDMI cable does not support ARC. TV SOUNDCONNECT You can enjoy TV sound through your Soundbar when it is connected to a Samsung TV that supports the TV SoundConnect function. Connect 1. - Page 22 To connect to the other TV, follow Steps 1 through 4 above. ● The TV SoundConnect (SoundShare) function is supported by some Samsung TVs released from 2012 on. Check whether your TV supports the TV SoundConnect (SoundShare) function before you begin.
-
Page 23: Connecting To External Devices
CONNECTIONS CONNECTING TO EXTERNAL DEVICES OPTICAL OR ANALOG AUDIO CABLE This unit comes equipped with one digital optical in jack and one analog audio (AUX) in jack, giving you two ways to connect it to external devices. Optical Cable OPTICAL IN OPTICAL OUT Audio Cable BD / DVD player /... -
Page 24: Hdmi Cable
CONNECTIONS HDMI CABLE HDMI is the standard digital interface for connecting to TVs, projectors, DVD players, Blu-ray players, set top boxes, and more. HDMI prevents any degradation to the signal due to conversion to analog and maintains the video and audio quality of the original digital source. - Page 25 CONNECTIONS ● Connect USB devices directly to the USB port of the product. Otherwise, you may encounter a USB compatibility problem. ● Do not connect multiple storage devices to the product via a multi-card reader. It may not operate properly. ●...
-
Page 26: Functions
FUNCTIONS FUNCTIONS INPUT MODE button on the main unit’s top panel or the SOURCE button on the remote control to select the mode Press the you want. Input mode Display Optical Digital input D.IN ARC (HDMI OUT) input AUX input HDMI HDMI input BLUETOOTH mode... -
Page 27: Bluetooth
• The device name can only be displayed in English. An underline " _ " will be displayed if the name is not in English. • If the Bluetooth device has failed to pair with the Soundbar, delete the previous "[Samsung] HW-Jxxxx J-Series" found by the Bluetooth device and have it search for the Soundbar again. - Page 28 ● You cannot connect the Soundbar to a Bluetooth device that supports only the HF (Hands Free) function. ● Once you have paired the Soundbar to a Bluetooth device, selecting "[Samsung] HW-Jxxxx J-Series" from the device's scanned devices list will automatically change the Soundbar to BT mode.
- Page 29 Market search : Samsung Audio Remote + Launching the Samsung Audio Remote App To launch and use the Samsung Audio Remote app, touch the Audio Remote icon on your smart device, and then follow the directions on the screen. ● The Samsung Audio Remote app is only compatible with Android mobile phones and mobile devices...
-
Page 30: Software Update
UPDATING PROCEDURE 1. Follow the steps below to download the product software: Go to the Samsung website at (samsung.com/sec) search for the model name - select the customer support option (the option name is subject to change) 2. Save the downloaded software to a USB stick and select "Extract Here" to unzip the folder. - Page 31 CONNECTIONS IF UPDATE IS NOT DISPLAYED 1. Turn off the Soundbar, connect the USB storage device that contains update files to the Soundbar’s USB port. 2. Disconnect the power cord, reconnect it, and then turn on the Soundbar. ● Insert a USB device containing the firmware update into the USB port on the main unit. ●...
-
Page 32: Troubleshooting
Refer to the table below if this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord, and contact Samsung Electronics at 1-800-SAMSUNG (1-800-726-7864). -
Page 33: Appendix
● If you have a problem with this product, we strongly recommend you read the appropriate section of this manual, review the Troubleshooting section on page 32, visit the Support page for your product at www.samsung.com, or call Samsung Product Support (1-800-726-7864) to find an answer before you contact a service center for a repair. - Page 34 To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.
