  • Page 1 Operation Manual TWIN 7” portable DVD players Model no. E-DVKIT006...

  • Page 2: Important Safety Instructions

    Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 3 CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer to service manual for servicing instructions. 1) Read these instructions.
  • Page 4 Important Safety Instructions Copyright Protection This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.

  • Page 5: Features

    High-quality audio and video Excellent sound: Dolby Decoder delivers great sound. Advanced Playing Functions Compatibility: Compatible with DVD, CD and JPEG Particular Performance: Multi-speed, fast forward, fast backward and slow forward. Last Memory Playback: Memorizes the stopped playback track and continues playing the disk from this spot when the power is kept to supply.

  • Page 6: Accessories

    Accessories Accessories List ITEM NAME Remote Control Cell for Remote Control Power Adapter Car Adapter Audio/Video Cable (To connect one player with TV, Amplifier, and External AV source.) Audio/Video Cable (To connect two players) Owner’s Manual Earphone NOTE Accessories and their parts numbers are subject to modification without prior notice due to improvements.

  • Page 7: Table Of Contents

    …………………………………………..1 Important Safety Instructions …………………………………………...4 Features …………………………………………...5 Accessories …………………………………………...6 Contents …………………………………………...7 View of Front Panel …………………………………..……….9 View of Side Panels …………………………………………..11 View of Main Unit Bottom …………………………………………..12 View of Remote Control …………………………………………..14 Preparation and Using of RC. …………………………………………..15 System Connections …………………………………………..18 Power Supply Preparation …………………………………………..19...

  • Page 8: View Of Front Panel

    View of Front Panel -/+ button Press to adjust the value of brightness and color. AUDIO/ FUNC button Press AUDIO button to select different languages when a DVD disc which contains multiple audio languages is played. Press AUDIO button to select different audio track when a CD disc is played.
  • Page 9 MENU/ SOURCE button Press MENU button to access to or exit from the menu. Press SOURCE button to shift between AV MODE and DVD mode. ■ button ■ Press to stop playback. Then press the ■ stopped spot. Press button twice to stop playback completely. Press once to pause the playback and press it again to resume the playback.

  • Page 10: View Of Side Panels

    View of Side Panels Right Side View Volume Control Adjust the volume of the headphone and speaker. Headphone Jack Connect headphones for private listening. When the headphones are connected to this jack, the speaker will be turned off automatically. Audio input/output Jack For connecting an external amplifier or audio source.
  • Page 11 Left Side View Headphone Jack Connect headphones for private listening. When the headphones are connected to this jack, the speaker will be turned off automatically. Power Switch Turn the power on or off. View of Side Panels...

  • Page 12: View Of Main Unit Bottom

    View of Main Unit Bottom Rechargeable Battery Contacts For connecting the rechargeable battery pack. You can use the AC adapter to charge the battery as shown below. Note: This unit comes without rechargeable battery. Please buy corresponding rechargeable battery separately. Before charging, make sure that the power switch on the left side of the unit is switched off.

  • Page 13: View Of Remote Control

    MUTE button Press to turn off or on the speaker output. INFO button Press repeatedly to display or conceal the detailed information of the disc during playback. TITLE button Press to access to or exit from the title menu if it exists in the disc. Direction button Press to select different options.
  • Page 14 View of Remote Control NEXT button Press to skip to the next list, track or chapter. PREV button Press to return to the previous list, track or chapter. 10. SUBT button When playing a DVD coded with multi-subtitles, press to select a subtitle language or to turn subtitles off.

  • Page 15: Preparation And Using Of Rc

    Installation Steps Follow the steps below to install the battery. Pull the battery holder out from the remote control in the direction of the arrow. Load a new battery properly with the (+) side up. Insert the battery holder back into the remote control. Use of Remote Control Point the remote control unit from no more than about 5m from the remote control sensor and within about 60 degrees of the front of the unit.

  • Page 16: System Connections

    System Connections Always ensure that the DVD player, TV and any other electrical equipment to be connected with are switched off and unplugged from the power supply. Ensure that you observe the color coding when connecting audio and video cables. Connecting to TV Audio/Video connections Follow the drawings below to connect the DVD player to TV's Audio/Video inputs with...
  • Page 17 Connecting to Amplifier Refer to your Audio equipment's manual before connection. Follow the drawings below to connect the DVD player to AV amplifier. Connecting to Headphones Connect the headphones to the right side of the player for private listening. NOTE: Excessive loud volume could damage your hearing.
  • Page 18 System Connections Connecting to External AV Source The unit supports AV signal input function. Please use the audio/video cable to connect the unit to the external AV signal source such as a DVD, VCR etc. after connecting, press SOURCE button on the front panel to select AV mode. Note: Noise may occur in speakers when there is an external audio signal input while playing a DVD disc.

  • Page 19: Power Supply Preparation

    Using the AC Adapter The player is supplied with an AC adapter for powering the unit and charging the battery. Connect AC adapter to the right side of the DVD player in the jack marked DC 9.5V IN, as shown on the right. Plug the other end of the power cord into the wall AC outlet.

  • Page 20: Notes On Discs

    Notes on Discs Compatible Disc Formats COMPATIBLE DISC LOGO FORMAT JPEG Operation methods of some DVD discs are specified by the software manufacturer. Please follow the instructions of those discs. Care of Discs Holding Discs Do no touch the playing surfaces when loading or removing discs. Hold the disc as right picture.

  • Page 21: Playback Operation

    READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE USING YOUR DVD PLAYER FOR THE FIRST TIME. WARNING: Do not play poor-quality discs to avoid damaging the lens. Pre-operation 1. Connect the unit to power supply through the provided AC adaptor. 2. Switch “POWER ON/OFF” to “ON” on the left panel to turn on the DVD player. 3.

  • Page 22: Dvd Playback

    Playback Operation DVD Playback Buttons Operation Press the ENTER/ENT button to start playback; press ENTER/ENT button play or use 0-9 buttons to select directly. Press the PAUSE/ PAUSE/ step frame by frame playback button button to resume normal playback. During playback, press the Stop/ playing, then press the PLAY/ STOP/ playback from the stopped point.
  • Page 23 DVD Playback (continued) Press the TITLE button during playback. The title menu will appear on the screen. Press the TITLE button title/chapter to play, and press the ENTER/ENT button to confirm your selection. Or press the 0-9 buttons to select directly.
  • Page 24 Playback Operation DVD Playback (continued) Press the SLOW button repeatedly, and the slow playback will be undergoing at the speed of 1/2, 1/4, SLOW button 1/6, 1/8 and normal playback in sequence. Press the PLAY/ playback. Press the INFO button to display or conceal the detailed INFO button information.
  • Page 25 DVD Playback (continued) Press the REP button to repeat a Chapter, Title or REP button cancel the repeat in sequence. Press the ANGLE button to play the disc in multi-angle. Multi-angle means that a scene is shot from different angle so that audience can watch from any angle, like the drawings below: ANGLE button If there are multiple angles in a scene, you can use the...

  • Page 26: Cd Playback

    Playback Operation CD Playback When a CD disc is loaded, the player will read the disc. Then a playback menu will appear on the screen and the player will play the disc automatically by the default sequence of the disc. You can use the the number buttons to input the number of the desired track first and then press the ENTER/ENT button to confirm to play.
  • Page 27 CD Playback (continued) Press the REP button to repeat signal, all or cancel the REP button repeat in sequence. Press the A-B button once to set the starting point A, press it again to set the end point B. Then the player will A-B Button play the segment between A and B continuously.

  • Page 28: Jpeg Playback

    Playback Operation JPEG Playback Pre-operation Load a JPEG in the disc tray, the player will read the disc automatically. The screen displays the root folder with several subdirectories/subfolders. Press the ENTER/ENT button to enter. Use the press the ENTER/ENT button to confirm your selection. The screen enters the selected subfolder with several pictures.
  • Page 29 JPEG Playback (continued) During playback, press the & buttons previous picture; press the picture. Press the REP button to repeat single, folder or cancel REP button the repeat in sequence. Picture Rotate During browsing a picture, you can use the direction buttons to rotate the current picture.

  • Page 30: System Setup

    System Setup You can change the default settings of this unit to customize its performance to your own preference. Read this section to learn how to set up the system. Follow the steps below to set up your system: Press the SETUP button and the setup menu will appear on the screen. Press the buttons to select a sub-menu that you want to set up and press the button to enter the menu.
  • Page 31 Language setup (continued) System Setup 2. Subtitle This item is used to set the subtitle language. Press the buttons to highlight this item. Press the ENTER/ENT or button to enter the setup of this item. There are several items for you to choose. Press the buttons to choose the proper one.

  • Page 32: Video Setup

    System Setup Video setup Press the SETUP button and press the buttons to select Video. The screen will display as shown left. 1. Aspect Ratio This item is used to set aspect ratio. Press the buttons to highlight this item. Press the ENTER/ENT or button to enter the setup of this item.

  • Page 33: Misc Setup

    Misc setup System Setup Press the SETUP button and press the buttons to select Misc. The screen will display as shown left. 1. Use Default Settings This item is used to reset the unit to the default. Press the buttons to highlight this item. Press the ENTER/ENT button to enter the setup of this item.

  • Page 34: Use Of Straps

    Usage of straps Follow the steps below to fix the DVD Player onto a car seat headrest. Place the DVD player on a soft and smooth surface with the bottom facing up. Loose the strap and remove the buckle from the strap. Insert the strap through the holes as the Fig.1.
  • Page 35 Repeat these steps for the other strap. Adjust the length of the strap according to the backrest of the seat. Fasten the straps on the headrest of the seat as in Fig.4. Make sure the two straps are between the headrest support rods (if your car has them). NOTE: The drawings show the outside and the inside of the buckle and the strap.

  • Page 36: Definitions

    Definitions Letterbox screen This refers to a screen on which the playback picture of wide-screen DVDs appears with black bands running along the top and bottom. Pan & Scan screen This refers to a screen on which the playback picture of wide-screen DVDs is cut off at the left and right sides.

  • Page 37: Troubleshooting

    Take steps described in the tables below to solve simple problems before contacting after-sales service. If You Suspect Something Wrong, immediately turn the power off. Disconnect the power connector and check that there is neither smoke nor heat from the unit before asking for repairs.
  • Page 38 Troubleshooting PROBLEM POSSIBLE CAUSE The LCD may be off or not be in correct video mode. The system connection may There is no picture. be not correct. The unit may be not in AV out mode. The disc may be dirty or Poor AV performance.

  • Page 39: Specifications

    TFT screen size Laser Wavelength Video System Frequency Response Audio Signal-to-noise Rate Audio distortion+noise Channel Separation Dynamic Range Analog Audio Audio Out Video Out Video Out Power Power Consumption Dimensions 230mmX154mmX39.5mm (L*W*D) Weight DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Manufactured under license from Dolby Laboratories.
