Summary of Contents for ATEN eco PE Series
- Page 1 PDU PE Low Profile Series PE5324LB / PE5324LG / PE5324LJ / PE5324LKJA / PE5324LJA / PE6324LB / PE6324LG / PE6324LJ / PE6324LJA / PE5340SLB / PE5340SLG / PE5340SLJ / PE5340SLJA User Manual www.aten.com...
-
Page 2: Emc Information
eco PDU PE Low Profile Series User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
ATEN is not liable for any loss or damage. -
Page 4: Pe Device Safety Notice
eco PDU PE Low Profile Series User Manual PE Device Safety Notice Set the maximum permissible breaker protection in the building circuitry to the current rating specified on the rating plate. Observe all national regulations and safety codes as well as deviations for breakers. Only connect the PE Device to a grounded power outlet or a grounded system! Make sure that the total current input of the connected systems does not exceed the current rating specified on the rating plate of the PE Device. -
Page 5: Package Contents
Please visit our website to download the most up-to-date version. Copyright © 2015 ATEN® International Co., Ltd. 2015-11-16 NRGence and the NRGence logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners. -
Page 6: Table Of Contents
eco PDU PE Low Profile Series User Manual Contents EMC Information..........ii SJ/T 11364-2006 . - Page 7 eco PDU PE Low Profile Series Securing the Cables ........29 Securing the Sensors .
- Page 8 eco PDU PE Low Profile Series User Manual Rack Mounting ......... . 71 The eco PDU’s Main Power Cord .
-
Page 9: About This Manual
eco PDU PE Low Profile Series About This Manual This User Manual is provided to help you get the most from your eco PDU system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. Chapter 1, Introduction, introduces you to the eco PDU system. -
Page 10: Product Information
For information about all NRGence products and how they can help you save money in the data center, visit NRGence on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers International –... -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Overview As part of its NRGence line, ATEN has developed a new generation of green energy power distribution units (PDUs) to effectively increase the efficiency of data center power usage. The NRGence PE5324LB / PE5324LG / PE5324LJ /... - Page 12 PDU PE Low Profile Series User Manual The low-profile series of ATEN PDUs have a circuit breaker alert that can sound an alarm and send SNMP trap or e-mail alerts when a trip occurs. This feature provides a faster response time to recover servers and other devices when a circuit overload causes a loss of power.
-
Page 13: Comparison Chart
Chapter 1. Introduction Comparison Chart Amps Metering Outlet Model Inlet / Cord Outlets Level Switching Total Port PE5324LB NEMA L6- 24 21 x IEC 320 C13 PDU/ (Max), (UL), 30P (208V) Bank 3 x IEC 320 C19 (UL) (Max) PE5324LJ (Max), (UL), (UL) - Page 14 eco PDU PE Low Profile Series User Manual Amps Metering Outlet Model Inlet / Cord Outlets Level Switching Total Port PE5340SLB NEMA L6- 40 40 x IEC320 C13 PDU/ (Max), (Max) Bank , 24A (UL) rated) PE5340SLJ (Max), (Max) , 24A (UL) rated) PE5340SLJA...
-
Page 15: Features
Chapter 1. Introduction Features Power Distribution Space saving 0U rack mount design with rear mounting IEC or NEMA outlet models 3 digit 7-segment front panel LED shows PDU/Bank current/IP address (PE5340SL), or PDU current/IP address (PE5324L, PE6324L) Remote users can monitor PDU / Bank status via web pages on their browsers Safe shutdown support Separate power for the unit's own power and its power outlets. -
Page 16: Security
eco PDU PE Low Profile Series User Manual LED indicators for current and IP address at the PDU device and/or Bank levels. Real-time aggregate current, voltage, and power and power dissipation displayed in a browser-based UI for monitoring at the PDU level and at the bank level Environment monitoring –... -
Page 17: Requirements
Chapter 1. Introduction Requirements Browsers accessing the eco PDU unit must support SSL 128 bit encryption. For cold booting of attached computers, the computer's BIOS must support Wake on LAN or System after AC Back. For Safe Shutdown: The computer must be running Windows (Windows 2000 or higher) or Linux. -
Page 18: Optional Accessories
Sensors can be managed via the eco PDU’s built-in graphical user interface (GUI) or with the NRGence eco Sensors software that can be downloaded from the ATEN website. The download link can be found on the software CD provided with the eco PDU package. -
Page 19: Components
Chapter 1. Introduction Components PE5324LB / PE5324LG / PE5324LJ Front View... - Page 20 100 Mbps data transmission speed. Readout Section, LEDs Details of this section are provided on page 23. and Reset Switch Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 29, for further information.
-
Page 21: Pe5324Lkja Front View
Chapter 1. Introduction PE5324LKJA Front View... - Page 22 100 Mbps data transmission speed. Readout Section, LEDs Details of this section are provided on page 23. and Reset Switch Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 29, for further information.
-
Page 23: Pe5324Lja Front View
Chapter 1. Introduction PE5324LJA Front View... - Page 24 100 Mbps data transmission speed. Readout Section, LEDs Details of this section are provided on page 23. and Reset Switch Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 29, for further information.
-
Page 25: Pe6324Lb / Pe6324Lg / Pe6324Lj Front View
Chapter 1. Introduction PE6324LB / PE6324LG / PE6324LJ Front View... - Page 26 Outlet Status LEDs These 24 LEDs indicate the outlet power status. Lights ORANGE for powered on. Off for powered off. Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 29, for further information.
-
Page 27: Pe6324Lja
Chapter 1. Introduction PE6324LJA... - Page 28 Outlet Status LEDs These 24 LEDs indicate the outlet power status. Lights ORANGE for powered on. Off for powered off. Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 29, for further information.
-
Page 29: Pe5340Slb / Pe5340Slg / Pe5340Slj Front View
Chapter 1. Introduction PE5340SLB / PE5340SLG / PE5340SLJ Front View... - Page 30 100 Mbps data transmission speed. Readout Section, LEDs Details of this section are provided on page 24. and Reset Switch Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 29, for further information.
-
Page 31: Pe5340Slja Front View
Chapter 1. Introduction PE5340SLJA Front View... - Page 32 eco PDU PE Low Profile Series User Manual Item Description Power Cord This is the power cord that connects the unit to an AC power source via NEMA L5-30P plug. Circuit Breakers (Bank 1 2 x 16A Slim Breakers. As a safety measure, if there is an overcurrent situation regarding the and Bank 2) device’s power, the circuit breakers will trip.
-
Page 33: Pe6324L / Pe5324L Readout Section
Chapter 1. Introduction PE6324L / PE5324L Readout Section Item Description LEDs These LEDs indicate status for Power, PDU Current, IP address and Sensors Readout Section The selection (PDU Current / IP Address) appears in the first part of the display window. PDU Current / IP Address appear in the second part of the display window The LEDs above the items indicate which one the readout... -
Page 34: Pe5340Sl Readout Section
eco PDU PE Low Profile Series User Manual PE5340SL Readout Section POWER / PHASE BANK SELECT SENSOR 1 SENSOR SENSOR 2 RESET Item Description Status LEDs Power: Lights when the unit is powered on and ready to operate. ID Section The ID of the selected PDU/Phase / Bank / IP appears in the LED display window. -
Page 35: Chapter 2. Hardware Setup
Chapter 2 Hardware Setup Before You Begin 1. Important safety information regarding the placement of this device is provided on page 69. Please review it before proceeding. 2. Make sure that power to all the devices you will be connecting have been turned off. -
Page 36: Pdu Placement
eco PDU PE Low Profile Series User Manual PDU Placement For safety reasons the eco PDU should not be installed with the power sockets facing directly up or down, and thus should only be installed with the power sockets facing out from a vertical position as shown below: Right Floor Wrong... -
Page 37: Installation
1. For each device you want to connect, use its power cable to connect from the device's AC socket to any available outlet on the eco PDU. Use ATEN Lok-U-Plug cable holders to secure them. Note: See Securing the Cables, page 29, for details. - Page 38 eco PDU PE Low Profile Series User Manual...
-
Page 39: Securing The Cables
Chapter 2. Hardware Setup Securing the Cables For added safety, use ATEN Lok-U-Plug cable holders to secure the cables from your attached devices in place on the eco PDU unit. Secure the cable holders using the specially designed holes around the individual power outlets, as shown below: Note: 1. -
Page 40: Securing The Sensors
eco PDU PE Low Profile Series User Manual Securing the Sensors Connect the sensors to the eco PDU’s front panel sensor ports and secure them using sensor mounts, tie wraps, and adhesive cable tie holders. If you use a tie wrap to secure the sensor, tighten the tie wrap over the recessed channel on the sensor, as shown in the following diagram: Note: 1. -
Page 41: Basic Operation And First Time Setup
Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. NRGence eco Sensors can be downloaded from the ATEN website, along with a separate eco Sensors User Manual. -
Page 42: First Time Setup
eco PDU PE Low Profile Series User Manual First Time Setup Once the eco PDU installation has been cabled up, the next task the Administrator needs to perform involve configuring the network parameters, changing the default Super Administrator login settings, and adding users. The way to accomplish this is to log in over the network with a browser. -
Page 43: Network Configuration
Chapter 3. Basic Operation and First Time Setup Network Configuration To set up the network, do the following: 1. Click the Setup tab. 2. The interface displays the Device Configuration page. A screen similar to the one below appears: 3. Fill in the IPv4 Configuration fields according to the information provided under IPv4 Configuration, page 50. -
Page 44: Changing The Administrator Login
eco PDU PE Low Profile Series User Manual Changing the Administrator Login To change the default Administrator username and password, do the following: 1. Click the User tab. The Accounts page has a detailed list of user accounts – with more information about them –... -
Page 45: Chapter 4. Browser Operation
Chapter 4 Browser Operation Logging In The eco PDU can be accessed via a supported Internet browser from any platform. Note: Browsers must support SSL 128 bit encryption. To access the eco PDU do the following: 1. Open your browser and specify the IP address of the eco PDU you want to access in the browser's URL location bar. -
Page 46: The Eco Pdu Main Page
eco PDU PE Low Profile Series User Manual The eco PDU Main Page After you have successfully logged in, the eco PDU Main Page comes up with the Outlet Access Connections page displayed: Note: The screen depicts an Administrator’s page. Depending on a user’s type and permissions, and your PE model, not all of these elements appear. -
Page 47: Page Components
The Sidebar provides a tree view listing of outlets that relate to the various tab bar and menu bar selections. Help Connects to on-line help at the ATEN website for the device’s configuration and operation. Logout Click this button to log out of your eco PDU session. -
Page 48: Energy
eco PDU PE Low Profile Series User Manual Energy Connections When you log in to the eco PDU, the interface opens with its default selection of the Outlet Access tab; and the Connections menu. The contents of the PDU Status and Outlet Status sections are displayed in the main panel. Note: Only enabled eco PDU models will display the Outlet Status submenu section. - Page 49 Chapter 4. Browser Operation PDU Status All eco PDU models support PDU device level monitoring. The PDU Status section allows you to set up a power management configuration for the PDU device as a whole: PDU Threshold Settings These fields are used to set the maximum, minimum, and fluctuation threshold settings for Aggregate Current, Voltage, Power, and Aggregate Power Dissipation.
- Page 50 eco PDU PE Low Profile Series User Manual Bank Status If your eco PDU model supports Bank level metering the threshold and power management can be performed on this page. Outlet Measurement and Threshold Settings These fields are used to set the maximum, minimum, and fluctuation threshold settings for Current, Voltage, Power, and Power Dissipation.
- Page 51 Chapter 4. Browser Operation Outlet Status If your eco PDU models supports outlet level power management you can preform manual On/Off/Reboot switching as described on this page. On / Off / Reboot You can manually turn the outlet On and Off from this page by clicking the radio buttons.
-
Page 52: Configuration
eco PDU PE Low Profile Series User Manual Configuration The Configuration page is used to configure the settings of the eco PDU at the individual power outlet level: Power On Time Schedule Settings Check the Enable Power On Time Schedule box to use the Power ON Delay setting to set the amount of time the eco PDU waits before powering on an outlet. - Page 53 Chapter 4. Browser Operation Power ON Delay Sets the amount of time the eco PDU waits after the Power Button is clicked (see Bank Status, page 40), before it turns on the power to the outlet. Note: The default delay time is 0 seconds; the maximum is 999 seconds. When a series of outlets are scheduled to be powered up, they turn on in sequence with a default delay of 10 milliseconds between each outlet.
-
Page 54: User
eco PDU PE Low Profile Series User Manual User When you select the User tab the screen comes up with Administrator Information and User Information displayed in the main panel. The eco PDU supports one Administrator account and up to eight User accounts. Note: 1. -
Page 55: User Information
Chapter 4. Browser Operation User Information To add a user, do the following: 1. Select the user type in the Management drop-down menu. 2. Key in a name and password in the Name and Password fields. 3. Set the outlet-by-outlet permissions of the user in the Outlet field. 4. -
Page 56: Log
eco PDU PE Low Profile Series User Manual The Log tab keeps a record of transactions that take place on its installation, and stores up to 128 events at one time. The System Log page provides a powerful array of filters and functions that allow you to view and export the log file data, as well as be informed by email of specified events as they occur. -
Page 57: Notification Settings
Chapter 4. Browser Operation Notification Settings The Notification Settings page is used to specify which of the eco PDU’s components will receive notification of a log event. When you click the Notification Settings menu item, a page similar to the one below appears: The event categories are listed in the left column. -
Page 58: Setup
Firmware Version This item displays the current firmware version number. You can reference it to see if there are newer versions available on the ATEN website. Rack Location This field lets you give the rack location a unique name for easy Name reference. - Page 59 Chapter 4. Browser Operation Service Ports As a security measure, if a firewall is being used, the Administrator can specify the port numbers that the firewall will allow. If a port other than the default is used, users must specify the port number as part of the IP address when they log in.
- Page 60 eco PDU PE Low Profile Series User Manual IPv4 Configuration The PDU’s IPv4 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned dynamically (DHCP), or a fixed IP address can be specified. For dynamic IP address assignment, select the Obtain IP address automatically radio button.
- Page 61 Chapter 4. Browser Operation IPv6 Configuration IPv6 is the new (128-bit) format for specifying IP addresses. The PDU°¶s IPv6 IP and DNS addresses can either be assigned dynamically (DHCP), or a fixed IP address can be specified. For IP address assignment, select the Enable autoconfiguration radio button.
- Page 62 eco PDU PE Low Profile Series User Manual Event Notification The Event Notification section is divided into three sections: SMTP Settings; SNMP Trap Receivers; and Syslog Server. Each section is described below. SMTP Settings To have the eco PDU device email reports from the SMTP server to you, do the following: 1.
- Page 63 Chapter 4. Browser Operation SNMP Trap Receivers Up to four SNMP management stations can be specified. If you want to use SNMP trap notifications, do the following: 1. Check Enable SNMP Trap. 2. Select which version of SNMP you want to use. 3.
- Page 64 eco PDU PE Low Profile Series User Manual Syslog Server To record all the events that take place on eco PDU devices and write them to the eco PDU Syslog server, do the following: 1. Check Enable Syslog Server. 2. Key in the IP address and the port number of the Syslog server. The valid port range is 1-65535.
-
Page 65: Date/Time
Chapter 4. Browser Operation Date/Time The Date/Time dialog page sets the eco PDU time parameters: Time Zone To establish the time zone that the eco PDU is located in, drop down the Time Zone list and choose the city that most closely corresponds to where it is at. - Page 66 eco PDU PE Low Profile Series User Manual Manual Input Use this section to specify the eco PDU’s date and time manually. Click the calendar icon and click the calendar entry for the date. Key the time into the Time field, using the HH:MM:SS (hours, minutes, seconds) format.
-
Page 67: Security
Chapter 4. Browser Operation Security The Security page controls access to the eco PDU device. Login Failures Allowed sets the number of consecutive failed login attempts that are permitted from a remote user. Timeout sets the amount of time a remote user must wait before attempting to login again after exceeding the number of allowed failures. -
Page 68: Account Policy
eco PDU PE Low Profile Series User Manual Account Policy The Account Policy section governs policies in regard to usernames and passwords. Check a policy and enter the required information in the appropriate fields. Item Description Minimum Username Length Sets the minimum number of characters required for a username. -
Page 69: Login String / Ip Filter / Mac Filter
Chapter 4. Browser Operation Login String / IP Filter / Mac Filter Login String The Login String entry field is used to specify a login string (in addition to the IP address) that users must include when accessing the eco PDU device with a browser. - Page 70 eco PDU PE Low Profile Series User Manual IP Filter / MAC Filter If any filters have been configured, they appear in the IP Filter and/or MAC Filter list boxes. IP and MAC Filters control access to the eco PDU based on the IP and/or MAC addresses of the client computers attempting to connect.
- Page 71 Chapter 4. Browser Operation To add a MAC filter, do the following: 1. Click Add. A dialog box similar to the one below appears: 2. Specify the MAC address in the dialog box (for example, 001074670000), then click OK. Repeat these steps for any additional MAC addresses you want to filter. IP Filter / MAC Filter Conflict If there is a conflict between an IP filter and a MAC filter –...
-
Page 72: Authentication & Authorization
eco PDU PE Low Profile Series User Manual Authentication & Authorization The Authentication & Authorization page is used to set up login authentication and authorization management from external sources. RADIUS Settings To allow authentication and authorization for the eco PDU device through a RADIUS server, do the following: 1. -
Page 73: Private Certificate
For enhanced security, the Private Certificate section allows you to use your own private encryption key and signed certificate, rather than the default ATEN certificate. There are two methods for establishing your private certificate: generating a self-signed certificate;... - Page 74 3. Click Upload to complete the procedure. Note: 1. Clicking Restore Default returns the device to using the default ATEN certificate. 2. Both the private encryption key and the signed certificate must be imported at the same time.
-
Page 75: Pdu
Chapter 4. Browser Operation The PDU tab is used to upgrade the eco PDU’s firmware, and to backup and restore the device’s configuration settings. Firmware File When you click the Maintenance tab, the display opens with the Firmware Upgrade menu page, which looks similar to the one below: A description of the items shown in this panel are given in the table, below: Item Description... - Page 76 eco PDU PE Low Profile Series User Manual Upgrading the Firmware To upgrade the firmware refer to the screenshot on the preceding page, and do the following: 1. Go to our website and download the new firmware file to a convenient location on your computer.
-
Page 77: Backup/Restore
Chapter 4. Browser Operation Backup/Restore Selecting Backup/Restore on the menu bar gives you the ability to back up the switch’s configuration and user profile information: Backup To backup the device’s settings do the following: 1. In the Password field, key in a password for the file. Note: Entering a password is optional. - Page 78 eco PDU PE Low Profile Series User Manual This Page Intentionally Left Blank...
-
Page 79: Appendix
Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 80 eco PDU PE Low Profile Series User Manual To help protect your system from sudden, transient increases and decreases in electrical power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS). Position system cables and power cables carefully; Be sure that nothing rests on any cables.
-
Page 81: Rack Mounting
To secure the cables in the eco PDU’s power outlets, use only the ATEN Lok-U-Plug cable holders that have been specifically designed to work with the eco PDU. Using any other kind of cable securing device could be highly dangerous. Please contact your ATEN dealer for information about ATEN Lok-U-Plug. -
Page 82: Technical Support
PDU PE Low Profile Series User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For telephone support, see Telephone Support, page iii North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support Technical... -
Page 83: Ip Address Determination
Appendix IP Address Determination If you are an administrator logging in for the first time, you need to access the eco PDU in order to give it an IP address that users can connect to. There are two methods to choose from. In each case, your client computer must be on the same network segment as the eco PDU. - Page 84 ALTUSEN eco Sensors allows you to determine/assign an IP address in order to configure a PDU device and monitor power status of the equipment connected to it. ALTUSEN eco Sensors can be obtained from the Download area of the ATEN web site.
-
Page 85: Specifications
Appendix Specifications PE5324LB / PE5324LJ / PE5324LG Function PE5324LB PE5324LJ PE5324LG Power Outlets Direct Connectors Power Cord 1 x NEMA L6-30P (208V) 1 x IEC 60309 Power Outlets Total: 21 x IEC320 C13 + 3 x IEC320 C19 Bank 1-1: Outlet 1–8; 7 x C13 + 1 x C19 Bank 1-2: Outlet 9–16;... -
Page 86: Pe5324Lkja / Pe5324Lja
eco PDU PE Low Profile Series User Manual PE5324LKJA / PE5324LJA Function PE5324LKJA PE5324LJA Power Outlets Direct Connectors Power Cord 1 x NEMA L5-30P, 100V Power Outlets Total: 24 x NEMA 5-15R Total: 24 x NEMA 5-15R twist lock Bank 1-1: 8 x NEMA 5-15R Bank 1-1: 8 x NEMA 5-15R Bank 1-2: 8 x NEMA 5-15R twist lock... -
Page 87: Pe6324Lb / Pe6324Lj / Pe6324Lg
Appendix PE6324LB / PE6324LJ / PE6324LG Function PE6324LB PE6324LJ PE6324LG Power Outlets Direct Connectors Power Cord 1 x NEMA L6-30P (208V) 1 x IEC 60309 Power Outlets Total: 21 x IEC320 C13 + 3 x IEC320 C19 Bank 1-1: Outlet 1–8; 7 x C13 + 1 x C19 Bank 1-2: Outlet 9–16;... -
Page 88: Pe6324Lja
eco PDU PE Low Profile Series User Manual PE6324LJA Function PE6324LJA Power Outlets Direct Connectors Power Cord 1 x NEMA L5-30P Power Outlets Bank 1-1: Outlet 1–8; 8 x NEMA 5-15R Bank 1-2: Outlet 9–16; 8 x NEMA 5-15R Bank 2: Outlet 17–24; 8 x NEMA 5-15R Sensor 2 x RJ-11 1 x RJ-45 Female (Silver) + LEDs (Orange/Green) -
Page 89: Pe5340Slb / Pe5340Slj / Pe5340Slg
Appendix PE5340SLB / PE5340SLJ / PE5340SLG Function PE5340SLB PE5340SLJ PE5340SLG Power Outlets Direct Connectors Power Cord 1 x NEMA L6-30P 1 x IEC 60309 Power Outlets Total: 40 x IEC320 C13 Bank1: Outlet 1–20; 20 x C13 Bank2: Outlet 21–40; 20 x C13 Sensor 2 x RJ-11 1 x RJ-45 Female (Silver) + LEDs (Orange/Green) -
Page 90: Pe5340Slja
eco PDU PE Low Profile Series User Manual PE5340SLJA Function PE5340SLJA Power Outlets Direct Connectors Power Cord 1 x NEMA L5-30P Power Outlets Total: 40 x NEMA 5-15R Bank1: Outlet 1–20; 20 x NEMA 5-15R Bank2: Outlet 21–40; 20 x NEMA 5-15R Sensor 2 x RJ-11 1 x RJ-45 Female (Silver) + LEDs (Orange/Green) -
Page 91: Administrator Login Failure
Appendix Administrator Login Failure If you are unable to perform an Administrator login (because the Username and Password information has become corrupted, or you have forgotten it, for example), you can clear the login information with the following procedure: 1. Power off the eco PDU and remove its housing. 2. -
Page 92: Limited Warranty
PDU PE Low Profile Series User Manual Limited Warranty ATEN warrants this product against defects in material or workmanship for a period of one (1) year from the date of purchase. If this product proves to be defective, contact ATEN's support department for repair or replacement of your unit.
