- Page 1 LED TV Installation manual Thank you for purchasing Samsung product. To receive more service, please register your product at www.samsung.com Model Serial No.
- Page 2 SBB/STB. If the TV is in ONLINE mode, it stops receiving IR(Samsung remote) commands and acts according to interface protocol. Stand-Alone: If SBB/STB is not identified, the TV should be switched to STAND-ALONE mode with restricted operation.
-
Page 3: Table Of Contents
Contents • Accessories ..................................4 • Installing the LED TV Stand ............................5 • Assembling the swivel ..............................6 • Viewing the Connection Panel........................... 8 • TV Controller ................................. 11 • Viewing the Remote Control ............................12 • Connecting the TV to a SBB or STB ........................... 14 •... -
Page 4: Accessories
✎ The items’ colour and shapes may vary depending on the model. • Remote Control & Batteries (AAA x 2) • Hotel Mount Kit • Samsung Smart Control (sold separately) • Power Cord / Data Cable • Quick Setup Guide •... -
Page 5: Installing The Led Tv Stand
Installing the LED TV Stand The 32” and larger LED TVs have swivel stands. You can set these stands so that the TVs swivel 20 degrees left and right or 90 degrees left and right. Stand Components When installing the stand, use the provided components and parts. 1 EA 1 EA 32"... -
Page 6: Assembling The Swivel
Assembling the swivel [ WARNING: If you configure the TV to swivel, you must attach it securely to the floor, a desk, a dresser top, etc. as described in the installation instructions. The 32” and larger LED TVs have swivel stands. You can configure these stands so that the TVs swivel 20 degrees left and right, 60 degrees left and right, or 90 degrees left and right using the BRACKET HOLDER SWIVEL. - Page 7 Hotel Mount Kit ¦ Bolt + Nut Short Bolt (2EA) Long Bolt (2EA) Nut (2EA) Washer (2EA) Affix the stand to a flat surface such as a dresser Bottom top, desk top, or entertainment centre as shown. WARNING: To prevent injury, you must attach this TV securely to the floor, a table, a dresser top, etc. with the Hotel Mount Kit as described in these instructions.
-
Page 8: Viewing The Connection Panel
Viewing the Connection Panel HDMI IN 2 HDMI IN 3 (ARC) HDMI IN 1 LAN OUT CLOCK ✎ Whenever you connect an external device to your TV, make sure that power on the unit is turned off. ✎ When connecting an external device, match the colour of the connection terminal to the cable. COMPONENT / AV IN ‒... - Page 9 LAN OUT Wired LAN connection port used to connect an external device such as a laptop to connect to the Internet. (However, the TV must be connected to the Internet via wired LAN.) DATA ‒ Used to support data communication between the TV and the SBB. ‒...
- Page 10 Display Modes You can also select one of the standard resolutions listed in the Resolution column. The TV will automatically adjust to the resolution you choose. After connecting a computer to the TV, set the screen resolution for the TV on the computer. The optimal resolution is 1920 x 1080 @ 60 Hz.
-
Page 11: Tv Controller
TV Controller TV Controller is a multi directional button that helps navigate without using the remote control. ✎ Some functions which require a PIN code may not be available. ✎ The product colour and shape may vary, depending on the model. ✎... -
Page 12: Viewing The Remote Control
Viewing the Remote Control ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired persons. ✎ Some fuction may not available depending on models. Turns the TV on and off. Display and select available video sources. - Page 13 Installing batteries (Battery size: AAA) ✎ NOTE • Use the remote control within 7m of the TV. • Bright light may affect the performance of the remote control. Avoid using nearby special fluorescent light or neon signs. • The colour and shape may vary depending on the model. •...
-
Page 14: Connecting The Tv To A Sbb Or Stb
Connecting the TV to a SBB or STB TV Rear Panel ETH MODEM Data Cable • Connect the DATA jack of the TV to the [ETH MODEM] jack of the STB (SBB) with the Data cable. ✎ Use data communication. •... -
Page 15: Connecting The Bathroom Speakers
Connecting the Bathroom Speakers You can connect the Bathroom Speakers using the following method. Connecting through the Variable Output (available without an external amplifier) ¦ TV Rear Panel Speaker VOL+ Volume Control Box VOL- 1. Connect the VARIABLE AUDIO OUT port of the TV to the Bathroom Wall Speakers of the hotel. - Page 16 Audio Loop In ¦ An additional Headphone Box can be installed on a bed or business desk for added convenience. The installation procedures are given below. • Detailed Drawing of the Headphone Box. TV Rear Panel HEADPHON BOX Headphone Box Shield wire TV Headphones jack Red Wire (Audio-R)
-
Page 17: Connecting The Mediahub Hd
Connecting the MediaHub HD Output to any external source connected to MediaHub HD on the hotel desk. MediaHub HD Rear TV Rear Panel HDMI RS/232 HDMI IN 2 HDMI IN 3 (ARC) HDMI IN 1 LAN OUT LAN OUT 2 HDMI cable 1 RS-232 Data Cable CLOCK... -
Page 18: Connecting The Rjp (Remote Jack Pack)
4. Connect the port of the TV and the RS/232 port of the RJP. ✎ The RJP (Remote Jack Pack) compatible with this Samsung TV is TeleAdapt TA-7610, TA-7650 (HD) and TA-7660 (HD Plus). • RJP (Remote Jack Pack): RJP stands for Remote Jack Pack. The RJP is a hardware module that has different Audio Video inputs (A/V, Audio, PC and HDMI) and corresponding outputs. - Page 19 • The RJP can be returned to the factory default settings by pressing the A/V and HDMI buttons simultaneously for 10 seconds. All LEDs blink 5 times to acknowledge that this has been finished. • The RJP will automatically turn off any LEDs after 5 minutes to avoid unnecessary light pollution in the hotel room. The LEDs that were turned off will turn on again if the guest touches any of the buttons and the 5 minute timer will restart.
-
Page 20: Setting The Hotel Option Data
• Standalone mode: TV works alone, without an SI STB or SBB. • Interactive mode: Samsung / 2M / Locatel / VDA / VDA-S / Acentic / Sustinere / Quadriga / ETV / IBahn / Magilink / Otrum / Siemens / Amino / MDC / Enseo... - Page 21 Hotel TV Function Description Category Item Gives you direct, immediate access to some of the Channel menu functions on the user Channel Channel Setup menu such as Auto Program, Antenna selection, etc. The Channel Editor lets you edit the channels stored in the TV's memory. Using Channel Editor you can: •...
- Page 22 Hotel TV Function Description Category Item Picture Menu Lock Enable or disable the Picture Menu. • ON: The Main Menu is displayed. Menu Display • OFF: The Main Menu is not displayed. • OFF: Broadcasting submenu is disable for guest. Channel Menu Display Menu OSD •...
- Page 23 Hotel TV Function Description Category Item Lets you set the priority of the 7610 RJP AV jack. You can choose 1, 2, with 1 being the highest and 2 the lowest. The TV automatically displays the source with the higher priority. For example, lets say AV is set to 1 and HDMI is set to 2.
- Page 24 Hotel TV Function Description Category Item Determines the Sub AMP operation mode. • 0: Turns the Sub AMP function off (PWM off). • 1: Determines the Sub volume according to the main volume control. Sub AMP Mode Bathroom • That is, the sub volume is determined according to the Power On Volume, the Min Volume, Speaker and the Max •...
- Page 25 Hotel TV Function Description Category Item If this item is entered into, network setup menu is displayed. The network setup menu is used for setting network like access internet. Soft AP: Using this function, you can connect the TV on your mobile devices. Set the options for connection of Wi-Fi device.
- Page 26 Hotel TV Function Description Category Item Disable entry to Hotel menu. Factory Lock • ON: The password is needed before entering factory menu. • OFF: disable this feature. Enable/disable Password Popup. If this option is set to OFF, the TV will not display the password Password Popup input popup window when entering the Factory menu.
- Page 27 Lets you upgrade the TV SW with a USB memory stick. If the Samsung Sound Bar device is connected to this TV, this item lets you to select where the TV sound is outputted when the TV is turned on.
- Page 28 Hotel TV Function Description Category Item You can turn on or off the REACH RF Mode. When set to On, the TV can operate with the REACH REACH RF Mode Server (Modulator) through the RF channel (DTV cable). You can turn on or off the REACH IP Mode. When set to On, the TV can operate with the REACH REACH IP Mode IP Server through the IP network.
- Page 29 Hotel TV Function Description Category Item You can turn on or off the HMS Mode. When set to On, the TV can operate with the HMS Server HMS Mode through the IP network. HMS Server URL You can enter the HMS Server's address. (Example: http://192.168.1.2:8080) Setting When there is one TV per room, set to 'Master'.
- Page 30 Welcome Message ¦ The welcome message is used to display custom messages on the TV every time TV is turned on by a Guest in Hotel room. ‒ Welcome message settings are found in the Hotel Option Menu. ‒ Welcome message should be ON in order to display the message on power-on. Welcome Message Edit Welcome Message Hospitality Logo...
- Page 31 • Logo File Format ‒ The TV supports only BMP and AVI format. ‒ The file name must be samsung.bmp or samsung.avi. ‒ The maximum resolution of the BMP format is 960 x 540. ‒ The maximum file size for AVI format is 30MB.
- Page 32 USB Cloning ¦ USB Cloning is used to download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV set and upload them to other TV sets. All the user-defined settings from the TV (Master Set) can be copied to the USB device. ✎...
- Page 33 Setting Auto Initialize ¦ When you clone settings from one TV to another, you clone both the guest side menu and hotel side menu settings: Picture, Sound, Input, Channel, Setup, and Hotel Setup). This lets you set nearly all of the menu values on your hospitality TVs to the same, standard settings.
- Page 34 Menu Item Sound Output Sound Mode Balance Equalizer Sound HDMI Input Audio Format Expert Settings Digital Output Audio Format Audio Delay Auto Volume Sound Feedback Audio Options Preferred Language Digital Text (MHEG) Primary Teletext Language Broadcasting Expert Settings Teletext Language Primary Audio Language Secondary Teletext Settings...
- Page 35 Next Previous Next Previous Next Welcome to Samsung TV! Terr./Cable Signal Detected Scan Channels Select your language to start the on screen setup. Select each item and choose the correct setting. Then select Next to search for channels. Scanning for channels...
- Page 36 ‒ If the country is changed, the TV automatically turns off and on. ‒ If you select the incorrect country, execute TV Reset again after entering the System section of the Hotel Menu. • Welcome to Samsung TV! OSD ‒ Initially highlighted: Welcome (English) ‒...
- Page 37 Multi Code Remocon ¦ Multi Code Remocon is a special transmitter which is designed to control each TV with one remote. This is useful where there is more than one TV in a location, such as in a hospital. The set ID number is displayed in the source osd.
- Page 38 Channel Bank Editor (Smovie TV Only) ¦ Channel Bank Editor edits channels, with 3 different Bank Options. Depending on the Bank card, there are specific channels Hotel customers can enjoy. Setting the Channel Bank Editor under Stand-alone Mode 1. Enter the Hotel Standalone menu by “MUTE →...
- Page 39 5. Edit the channel bank like below example. a. BANK1 (Free channel): Select the channel that will be used when remote doesn’t have any card. b. BANK2 (Family Card - Green): Select the channel that will be used when remote has a GREEN CARD. c.
- Page 40 Channel Editor ¦ Channel Editor edits channel number a and name. Use Channel Editor to sort the channels as user-desired channel numbers. Hospitality Mode Standalone System Manager SI Vendor Security Power On Channel System Menu OSD Home Menu Clock REACH Solution Music Mode H.Browser Solution Remote Jack Pack...
- Page 41 Smovie On sequence Smovie TV used ( Air / Cable ) Step Mixed Channel Map On (Air and Cable both used) Only Air or Cable used Only Air or Cable used If the tv starts with Hotel P&P If P&P already done If the tv starts with Hotel P&P If P&P already done Do the P&P, except channel...
- Page 42 My Channel ¦ Determines the country and genre for the channels provided by the hotel, and if the user selects a country and genre, shows the corresponding channels. • You must select the country first, or you can not set a genre. •...
- Page 43 • Samsung Sound-Bars and Hospitality TV ‒ Use Samsung Sound-Bars and Hospitality TV that support the ARC feature with HDMI. If you connect a compatible Samsung Sound-Bar to a compatible Samsung hospitality TV using a single HDMI cable, guests can listen to theTV’s sound through the Sound-Bar.
- Page 44 Security mode ¦ Design Specifications • This is to restrict some functions such as TTX and external source (HDMI, USB) input in specific facilities such as a correctional facility. • The Security menu is password-protected. Access to the Security menu is denied without the password. •...
-
Page 45: Installing The Wall Mount
Contact a technician for assistance when installing the wall mount bracket. We do not advise you to do it yourself. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you select to install the TV on your own. -
Page 46: Securing The Tv To The Wall
Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration, depending on the manufacturer. -
Page 47: Specifications
Specifications Environmental Considerations Operating Temperature 10°C to 40°C (50°F to 104°F) Operating Humidity 10% to 80%, non-condensing Storage Temperature -20°C to 45°C (-4°F to 113°F) Storage Humidity 5% to 95%, non-condensing Model Name HG32AF690 HG43AF690 Display Resolution 1920 x 1080 1920 x 1080 Stand Swivel 20˚... -
Page 48: Dimensions
943.9 532.1 559.6 570.1 623.0 54.0 226.5 HG49AF690 1105.8 1076.8 607.0 559.6 645.0 698.0 54.6 226.5 HG55AF690 1241.6 1212.6 683.4 559.6 721.4 774.3 54.5 226.5 Jack panel detail / Rear view ✎ Detailed dimensions can be checked at Displaysolutions.samsung.com. English... - Page 49 Base Stand detail HG32AF690 (Unit: mm) 55.9 135.0 R9.5 R3.75 152.0 451.3 192.6 159.8 HG43AF690 / HG49AF690 / HG55AF690 (Unit: mm) 70.0 135.0 R9.5 R3.75 152.0 559.6 226.5 168.7 ✎ NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV.
-
Page 50: Licence
HDMI Licensing LLC in the United States and other countries. Open Source License Notice Open Source used in this product can be found on the following webpage. (http://opensource.samsung.com) Open Source Licence Notice is written only English. English... - Page 51 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre Web Site SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support AUSTRALIA 1300 362 603 www.samsung.com/au/support NEW ZEALAND 0800 726 786 www.samsung.com/nz/support...
