DOSKO 200-6HC Operating Instructions

OPERATING INSTRUCTIONS
Adjustable Brake Lever
Model 200-6HC
Engine Throttle & Choke
Gas Tank
On-Off Switch
Recoil Rope
Side Discharge Frame
Cutting Tooth
Cutter Wheel Disc
Know Your Dosko:
BEFORE GRINDING STUMPS
• Be aware of all underground utilities before grinding stump.
STARTING GRINDER
• Lock handle in the upright, operating position.
• Pull out on-off switch (located on control panel).
• Turn switch to "On" position (located on engine).
• If engine is cold move choke lever to closed position
(located on engine).
• Engage operator presence handle located on left side of
operating station by pushing handle (small diameter bar)
towards "Handle Bar Bow."
• Pull recoil rope to start engine (located on engine).
• When engine starts — close choke.
• Press down on handle bar so that cutter wheel is off the
ground.
• Press throttle lever/bail (located on right side) towards
"Handle Bar Bow." Engine will increase and centrifugal clutch
will engage and begin rotating cutter wheel automatically.
20195 South Diamond Lake Road, Suite 100 • Rogers, MN 55374 • USA (Toll-Free): 866-298-3659 • International: + 1-763-428-0302 • www.dosko.com 20195 South Diamond Lake Road, Suite 100 • Rogers, MN 55374 • USA (Toll-Free): 866-298-3659 • International: + 1-763-428-0302 • www.dosko.com
Throttle Lever/Bail
Handle Bar Bow
Handle Bar
Air Filter
Discharge Flap
BEFORE STARTING OR USING THIS MACHINE, READ AND REVIEW THIS SAFETY SHEET! BE AWARE OF ALL POTENTIAL DANGERS,
PROTECT WINDOWS AND VEHICLES FROM POSSIBLE FLYING DEBRIS AND BE AWARE OF ALL NECESSARY SAFETY PRECAUTIONS!
GRINDING STUMP
• Push grinder to stump so that the stump is located just in
front of the cutter wheel.
• Using the brake lever — lock the one wheel.
• Move throttle to full open (located on engine).
• Lower the cutter wheel slowly using a left-to-right motion to
grind the stump.
• Grind stump to desired depth.
• Reposition grinder further on stump and begin this process
again.
• Release handle to disengage.
• Allow cutter wheel to stop before resting it on ground.
TO TURN FOR A SHORT PERIOD AFTER ENGINE IS
SHUT OFF.
Operator
Presence Handle
Operating Station
Folding Handle Lock
Belt Guard
Folded Down Position
ALWAYS
THINK
SAFETY
: CUTTING WHEEL WILL CONTINUE
Item # E786116
