Summary of Contents for Universal E-40
- Page 1 R-20 / R-25 E-40 / E-45 Manual en Español Latino Americano: ASSEMBLY MANUAL / OWNER’S MANUAL http://www.UniversalHomeFitness.com...
-
Page 2: Table Of Contents
Or go to: www.UniversalHomeFitness.com Nautilus, Inc., (800) NAUTILUS / (800) 628-8458, www.NautilusInc.com - Customer Service: North America (800) 605-3369, csnls@nautilus.com | outside U.S. technics@nautilus.com | Printed in China | © 2015 Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Universal, Bowflex, Schwinn, and Nautilus are trademarks owned by or licensed to Nautilus, Inc. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions. - Page 4 Before using this equipment, obey the following warnings: Read and understand the complete Manual. Keep the Manual for future reference. Read and understand all warnings on this machine. If at any time the Warning labels become loose, unreadable or dislodged, contact Nautilus Customer Service for replacement labels. To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and the machine and wait 5 minutes before cleaning, maintaining or repairing the machine.
-
Page 5: Safety Warning Labels / Serial Number
SAFETY WARNING LABELS AND SERIAL NUMBER • • • • • • • • • • • Serial number • Product specification FCC Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The power supply complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Specifications
SPECIFICATIONS Maximum User Weight: 275 lbs. (125 kg) Power Requirements: 4 D Batteries (LR20) – not included Operational Voltage: 6VDC Regulatory Approvals: O ptional AC Power Adapter: UL listed, CSA certified (or equivalent), Rated 120V60Hz Input, 9VDC, 0.5 A Output. Class 2 or LPS. This product, its packaging, and components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is provided in accordance with 64.5”... -
Page 7: Parts
PARTS A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly. Item Description Item Description Frame Pedal Arm, Right Front Stabilizer Pedal Arm, Left Water Bottle Holder Lower Left Handlebar Arm Console Lower Right Handlebar Arm Console Mast... -
Page 8: Hardware
HARDWARE / TOOLS Item Description Item Description Flat Head Hex Screw, M8x20 Sleeve, Plastic Button Head Hex Screw, M8x15 Flat Washer, M6 Washer, Curved Button Head Hex Screw, M6x12 Spring Washer, M8 Shaft Flat Washer, Wide Pedal Mount Plate Plastic Washer (D16.2) Flat Washer, M8 Wave Washer, Small (D16.5) Carriage Bolt, M6x25 Washer Button Head Hex Screw, M6x14 Wave Washer, Large (D20) Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware after the proper assembly of your machine. -
Page 9: Assembly
ASSEMBLY Note: Do not fully tighten the Hardware until the machine is completely assembled. 1. Attach Front Stabilizer to Frame 2. Attach Rail Assembly to Frame Assembly... - Page 10 3. Connect the Console Cable NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp the Console Cable. 4. Attach Console Mast to Frame Assembly NOTICE: Do not crimp the Console Cable.
- Page 11 5. Install the Static Handlebar to the Console Mast Note: H ardware is pre-installed on Static Handlebar and not on Hardware Card. Make sure that the Console Cable (5a) does not fall into the Console Mast. NOTICE: Do not crimp cables. 6. Attach Legs to Frame Assembly...
- Page 12 7. Attach Lower Handlebar Arms to Frame Assembly 8. Attach Pedals to Pedal Arms...
- Page 13 9. Attach Pedal Arms to Legs and Lower Handlebar Arms NOTICE: To avoid damage to the Arms, attach Pedal Arms to Legs first.
- Page 14 10. Attach Upper Handlebar Arms to Frame Assembly 11. Attach Media Tray to Console and Install the Console to the Console Mast Note: Before you attach the Media Tray, remove the protective plastic film from the front of the console. Be sure the tabs on the Media Tray snap into the Console.
- Page 15 12. Install Water Bottle Holder Note: H ardware is pre-installed on Console Mast and not on Hardware Card. 13. Tighten all Hardware Note: Fully tighten all Hardware from the previous steps. Make sure that the machine is level. If necessary, adjust the levelers (refer to the “Leveling the Machine” section).
- Page 16 14. Install Batteries in Console Note: The console uses D size batteries (LR20). Make sure that the batteries point in the direction of the +/– indicators in the battery bay. If you use rechargeable batteries, the optional power adapter will not recharge the batteries. Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or – rechargeable (Ni-Cd, Ni-MH, etc) batteries.
-
Page 17: Leveling The Bike
BEFORE YOU START Moving the Machine The machine may be moved by one or more persons depending on their physical abilities and capacities. Make sure that you and others are all physically fit and able to move the machine safely. Remove the power cord (if equipped). Use the Transport Handle to carefully lift the machine onto the transport rollers. -
Page 18: Features
FEATURES FUN RIDES CHALLENGES ROLLING HILLS UPHILL FINISH RIDE IN THE PARK CROSS-TRAINING MOUNTAINS PIKES PEAK PYRAMIDS QUICK START ENTER FUN RIDES MOUNTAINS CHALLENGES START STOP Console Water Bottle Holder Swing Handlebar Arm Contact Heart Rate (CHR) sensors Static Handlebar Power Connector Main Frame Assembly Battery Bay... -
Page 19: Console Features
Console Features The Console provides important information about your workout and lets you control the resistance levels while you exercise. The Console has a grid display with touch control buttons to navigate you through the exercise programs. Keypad Functions QUICK START Begins a Quick Start workout START/STOP Starts a Program workout, pauses an active workout. And if pushed and held down for 3 seconds during a paused workout, ends and FUN RIDES CHALLENGES... -
Page 20: Contact Heart Rate (Chr)
Speed / Distance The SPEED/DISTANCE display field shows the machine speed in kilometers per hour (km/h) or miles per hour (mph) for 6 seconds, then the Distance for 6 seconds. The Distance display shows the distance count (miles or km) in the workout. Note: To change the measurement units to English Imperial or metric, refer to the “Changing Unit Measures” sec- tion in this manual. RPM / KCAL (Calories) The RPM/KCAL display field shows the machine revolutions per minute (RPM) for 6 seconds, then the KCAL display shows the estimated calories that you have burned during the exercise for 6 seconds. Level / HR (Heart Rate) The LEVEL/HR display field shows the current resistance level (1–8) for 6 seconds, then your Heart Rate for 6 sec- onds. - Page 21 The Heart Rate table is an estimate of what Heart Rate Zone (HRZ) is effective to burn fat and better your cardiovascular system. Physical conditions vary, therefore, your individual HRZ could be several beats higher or lower than what is shown. The most efficient procedure to burn fat during exercise is to start at a slow pace and gradually increase your intensity until your heart rate reaches between 60 – 85% of your maximum heart rate. Continue at that pace, keeping your heart rate in that target zone for over 20 minutes.
-
Page 22: Operations
OPERATIONS What to Wear Wear rubber-soled athletic shoes. You will need the appropriate clothes for exercise that allow you to move freely. How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only. •... -
Page 23: Profile Programs
3. To change the resistance level, push the Increase/Decrease buttons. The default Quick Start resistance level is 1. The time will count up from 00:00. Changing Resistance Levels Push the Increase() or Decrease() buttons to change the resistance level at any time in a workout program. Profile Programs These programs automate different resistances and workout levels. -
Page 24: Changing Unit Measures (English Imperial/Metric)
Changing Unit Measures (English Imperial/Metric) To change the measurement units (for distance and speed) to English Imperial or metric: 1. Push the Fun Rides button. 2. The display shows the Rolling Hills program. Push the ENTER button. 3. The display shows the time of the workout. Push the ENTER button. 4. The display shows the Level value. Push the ENTER button. 5. -
Page 25: Maintenance
MAINTENANCE Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done. Worn or damaged components must be repaired or replaced immediately. Only manufacturer supplied components can be used to maintain and repair the equipment. - Page 26 Maintenance Parts Console Shroud, Right HR Cable Static Handlebar Rails Data Cable Console Mast Leveler Battery Bay Water Bottle Holder Front Stabilizer Machine Type Switch Upper Right Handlebar Arm Transport Roller AC Adapter Plug Lower Right Handlebar Arm Shroud, Left Brake Magnet Assembly Crank, Right Leg, Left...
- Page 27 Replacing the Console Batteries If the Battery Indicator comes on, replace the batteries in the back of the console with fresh batteries. Make sure the batteries point in the +/– direction shown in the battery bay. Note: The console uses D size batteries (LR20). If you use rechargeable batteries, the optional power adapter will not recharge the batteries.
-
Page 28: Troubleshooting
TROUBLESHOOTING Condition/Problem Things to Check Solution No display/partial display/ Check electrical (wall) Make sure unit is plugged into a functioning wall outlet. unit will not turn on outlet Check connection at Connection should be secure and undamaged. Replace console adapter or connection at unit if either are damaged. Check data cable integrity All wires in data cable (inside console mast) should be intact. - Page 29 Console shuts off (enters Check data cable integrity All wires in the cable should be intact. If any are cut or sleep mode) while in use crimped, replace cable. Check data cable Be sure cable is connected securely and oriented prop- connections/orientation erly.
- Page 30 [ page intentionally left blank ]...
-
Page 31: Warranty
WARRANTY Who Is Covered This warranty is valid only to the original purchaser and is not transferable or applicable to any other person(s). What Is Covered Nautilus, Inc. warrants that this product is free from defects in materials and workmanship, when used for the purpose intended, under normal conditions, and provided it receives proper care and maintenance as described in the Product’s Assembly and Owner’s manual. - Page 32 Nautilus Bowflex Schwinn Fitness Universal ® ® ® ® 8008555.111515.C...
