  • Page 1 MAKEVMA400 4-CHANNEL RELAY MODULE USER MANUAL...
  • Page 2 MAKEVMA400 USER MANUAL Introduction To all residents of the European Union Important environmental information about this product This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized company for recycling.
  • Page 3 MAKEVMA400 Pin Layout 5 VDC power ground signal pin, connected with Arduino ® control relay 1 signal pin, connected with Arduino ® control relay 2 signal pin, connected with Arduino ® control relay 3 signal pin, connected with Arduino ®...
  • Page 4 MAKEVMA400 Example © COPYRIGHT NOTICE All worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the prior written consent of the copyright holder. V. 01 – 08/11/2017...
