Channel Plus SVC-10 Installation Manual & Users Manual

Specifications: typical @ 25 C ± 5 C
SVC-10 Distribution System
Video nominal level
impedance
3dB bandwidth (worst case 1000ft)
Digital audio nominal level
impedance
3dB bandwidth (worst case 1000ft)
Analog audio nominal level
impedance
3dB bandwidth (worst case 1000ft)
Power supply output voltage
input power
power consumption (transmitter)
power consumption (receiver)
transmitter size (h X w X d)
Physical
receiver size (h X w X d)
transmitter weight
receiver weight
operating temperature
Environmental
storage temperature
humidity
Warranty
Multiplex Technology, Inc. warrants this product to be free from defects in
materials and workmanship for a period of one year from the date of
purchase or MTI will repair, or at its option, replace the defective product.
To obtain warranty service, call MTI for a return material authorization
(RMA) number and return the product prepaid to Multiplex Technology,
Inc., 3001 Enterprise Street, Brea, CA 92821, Attention: Customer
Service. Please put the RMA number on the outside of the carton.
Any implied warranty arising from the sale of the product including implied
warranties of merchantability and fitness for purpose are limited to the
warranty stated above. MTI shall not be responsible for losses or damages
or expenses, whether direct, consequential or incidental arising from the
use of or the inability to use this product. Some states do not allow
limitations on how long the implied warranty lasts or the exclusion or
limitation or incidental or consequential damages, so the above limitations
and exclusions may not apply to you. This warranty gives you specific legal
rights, and you may have other rights which may vary from state to state.
600-227 Rev. B
O O
1.0 Vp-p
75
10MHz
0.5 Vp-p
75
15MHz
1Vrms
10K nominal
20Hz-20KHz
15VDC
105-125VAC
5 watts typical
5 watts typical
1.75" X 17.0" X 6.5"
1.0" X 4.6" X 3.2"
2 lbs 10 oz
9.6 oz
0 C to 50 C O O
-30 C to 70 C O O
5% to 90%
(non-condensing)
Multiplex Technology, Inc., Brea, CA 92821
PERFORMANCE MULTI-ROOM VIDEO
Installation Manual

Users Guide

CAT-5
Point to Point
Video Distribution System
Model
SVC-10
This device complies with the FCC's Part 15 Rules for TV
interface devices. Any change or modification to this device
without the permission of Multiplex Technology, Inc. may
void the user's authority to operate this equipment.
3001 Enterprise Street, Brea, CA 92821-6213, U.S.A.
714-996-4100 * 800-999-5225 * FAX 714-996-4900 * www.channelplus.com
&
power s-video video digital IR
SVC-10
