Related Manuals for Morgan AC20
Summary of Contents for Morgan AC20
- Page 1 A C 2 0 INSTRUCTION MANUAL...
- Page 2 PLUGGING IN guitarist. Joe Designed the AC20 to be reminiscent of the One of the best features of the AC20 is that you best of the early 60s class A British amplifiers. can’t get a bad sound out of it.
- Page 3 – for example, a bathtub, reference and for the duration of owning this washbowl, kitchen sink, laundry tub, wet Morgan Amplifier. Please carefully read and basement, or near a swimming pool, and the like. understand the instructions inside this user’s 6.
- Page 4 of plugs, convenience receptacles, and the point 20. Accessories – Do not place this product on an where they exit from the amplifier. unstable cart, stand, tripod, bracket, or table. The 12. Cleaning – The amplifier should be cleaned product may fall, causing serious injury to a child only as recommended by the manufacturer.
-
Page 5: Front Panel
FRONT PANEL POWER SWITCH: Turn this ON to power the amplifier. Turn on this switch and the standby switch at the same time for optimal tube life. STANDBY SWITCH: Turn ON this switch to put the amp in play mode. This switch should be utilized to put the amp into a wait state for extended periods of rest. -
Page 6: Rear Panel
REAR PANEL Speaker Jacks: Your amp is equipped with one 16 ohm and two 8 ohm speaker outputs. The amplifier should only be operated with a SPEAKER cable connected to the proper impedance output. The two 8 ohm jacks are wired in parallel. If you want to run 2 cabs they need to be 16 ohms and each connected to the two 8 ohm output jacks MAIN FUSE: Replace with a 2 Amp slo blow fuse for 120V or 1.5 Amp slo blow for 230V. - Page 7 WARRANTY. TUBES: Morgan warrants the original purchaser MORGAN LIMITED LIFETIME WARRANTY that the specific tubes used in Morgan will be free from defects in material and workmanship for a Thank you for choosing Morgan. Morgan period of 90 days from the original date of manufactures some of the world’s most reliable...
- Page 8 Morgan be liable for any incidental or consequential damages arising out of the use or inability to use of any Morgan product, even if a Morgan dealer has been advised of the possibility of such damages, or any other claim by any other party.
- Page 9 www.morganamps.com...
