LCD
Item
Surface Treatment
Typical White Luminance (cd/m
also called Brightness
Luminance Uniformity
Contrast Ratio
Response Time (Optical Rise Time/Fall
Time)msec
Nominal Input Voltage VDD
Typical Power Consumption (watt)
Weight
Physical Size(mm)
Support Color
Viewing Angle (degree)
Horizontal: Right/Left
Vertial: Upper/Lower
Temperature Range( C)
Operating
Storage (shipping)
AC Adapter
Item
Vendor & model name
Input Requirements
Maximum input current (A,
@90Vac, full load)
Nominal frequency (Hz)
Frequency variation range (Hz)
Input voltage range (Vrms)
Inrush current
Efficiency
Output Ratings (CV mode)
DC output voltage
Noise + Ripple
Load
Output Ratings (CC mode)
DC output voltage
Constant current mode
Dynamic Output Characteristics
Turn-on delay time
Hold up time
Chapter 1
Haze 0 (Glare), Hardness 3H
2 200
)
not show
300
25(rise+falling)
not show
3.7 (for backlight unit)
not show
344(W)x222(H)x6.5(D)
Native 262K colours
45/45
15/35
°
0 to 50
-20 to -60
DELTA SADP-65KB BFD
LITE-ON PA-1650-02 Q2 19V
HIPRO HP-OK066B13QT
1.5 A @ 110Vac
1.0 A @ 240Vac
50-60
47-63
90-270
The maximum inrush current will be less than 50A and 100A when the adapter
is connected to 115Vac and 230Vac respectively.
It should provide an efficiency of 80% minimum, when measured at maximum
load under 115Vac.
19V
300mVp-pmax (20 MHz bandwidth)
0(min) 3.16A(max)
19V +/-1.0V for CV mode
3.6 +/- 0.3A
3 sec (@ 115Vac)
5ms (@115Vac, Full load)
Specification
Hard coating (2H) glare+ Anti
reflective treatment of the front
polarizer
185
not show
300
30(rise+falling)
not show
Total 5.26 @LCM circuit 1.12,
backlight input 4.14
590
344(W)x222(H)x6.5(D)
262K colours
60/60
40/50
0 to 50
-20 to -60
Specification
25
