  • Page 1 Full HD Optical transmitter and receiver Model: LM-HF01 User Guide...
  • Page 2 Product Overview HDMI Optical transmitter and receiver adopts the uncompressed digital HD video and high-speed digital optical fiber transmission technology advanced,It can transfer signal source(computer signal source, HDMI signal source high digital DVD/DVR) to long distance terminal easily, with strong performance, ensure the signal completed and stable. Main features 1.
  • Page 3 Interface overview Installation 1. Connect HDMI input signal to HDMI_IN port by cable 2. Connect HDMI output signal to HDMI_OUT port by cable 3. Connect Audio input signal to AUDIO IN port 4. Connect Audio output signal to AUDIO OUT port 5.
  • Page 4 Performance and Specification Temperature -5°C to +75°C Humidity 5 to 90 % RH (no condensation) Pixel band width 165MHz 800x600P60/1024x768P60 1280x800P60/1280x1024P60 1360x768P60 /1366x768P60 1400x1050P60/1440x900P60 1600x900P60/1600x1200P60 Video format 1680x1050P60/1280x720P50 1280x720P60/1920x1080P24 1920x1080P25/1920x1080P30 1920x1080P50/1920x1080P60 1920x1080I60 /1920x1080I50 1920x1200P60 The signa of Audio input and output 3.5MM Audio Audio format 44.1K,48K,96K,176K,192K...
  • Page 5 Connection...
