UTE X2-1616 Manual

Modular 16x16 matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
X2-1616
Modular 16x16 Matrix Switcher
All Rights Reserved
Version: X2-1616_2015V2.5
www.ute.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X2-1616 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UTE X2-1616

Summary of Contents for UTE X2-1616

  • Page 1 User Manual X2-1616 Modular 16x16 Matrix Switcher All Rights Reserved Version: X2-1616_2015V2.5 www.ute.de...
  • Page 2 X2-1616: Modular 16x16 Matrix Switcher Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till August 2015.
  • Page 3 X2-1616: Modular 16x16 Matrix Switcher SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully and save the original box and packing material for possible future shipment ...

  • Page 4: Table Of Contents

    X2-1616: Modular 16x16 Matrix Switcher Table of Contents 1. Introduction ......................... 1 1.1. About X2-1616 ....................1 1.2. Features ......................1 1.2.1. X2 signal card (changeable cards) ............2 1.3. Package List ..................... 2 2. Panel Description ......................3 2.1. X2-1616 ......................3 2.1.1.
  • Page 5 4.3.2. RS232 Communication Commands ............. 18 4.4. TCP/IP Control (Optional) ................28 4.4.1. Control Modes ..................28 4.4.2. Control X2-1616 via TCP/IP communication software ......29 4.4.3. TCP/IP Configuration ................30 5. Specification ......................32 5.1. Main Unit ......................32 5.2.

  • Page 6: Introduction

    It has 1 RS232 port and 1 optional TCP/IP port for convenient control from third-party. With its flexible design, X2-1616 can be used for different project and tend to be an all-in-one solution. It is the combo solution for multimedia conference rooms, control rooms, broadcasting rooms, shopping center etc.

  • Page 7: X2 Signal Card (Changeable Cards)

    X2-1616: Modular 16x16 Matrix Switcher 1.2.1. X2 signal card (changeable cards) X2-1616 supports multiple signal cards as listed in the following charts: Spec Inputs Signal Format Models X2-4I-HD HDMI X2-4I-HS HDMI& analog audio X2-4I-DV DVI, HDMI, VGA, AV, X2-4I-DS YPbPr...

  • Page 8: Panel Description

    X2-1616: Modular 16x16 Matrix Switcher 2. Panel Description 2.1. X2-1616 2.1.1. Front Panel Figure 2- 1 Front Panel of X21616 Name Description IR sensor, receive IR signal sent from IR remote ① Power Illuminate red once powered on ② indicator Display real-time operation status ③...

  • Page 9: Rear Panel

    Note: There are only 4 input and 4 output slots for X2-1616, which enables only 4 input cards and 4 output cards to be installed on X2-1616. The input/output cards can be changed based on your requests and supports hot plug and play.
  • Page 10 X2-1616: Modular 16x16 Matrix Switcher X2-4O-DV: output card, maximum four output signal, output signals from X2-4I-DV, or other kinds of input cards. Pin Layout of the DVI-I connector (Dual-Link). (Female) Function Function T.M.D.S.Data2- T.M.D.S.Data3+ T.M.D.S.Data2+ +5V Power Ground (return for T.M.D.S.

  • Page 11: X2-4I-Ds & X2-4O-Ds

    5 resolutions: 1024x768, 1280x720, 1600x1200, 1920x1080, 1920x1200. Before using X2-4O-DS, upgrade the front-board and backboard of X2-1616. Seek technical assistant from our technical supporters. DVI interfaces on the signal card are same with the interfaces on X2-4I-DV &...

  • Page 12: X2-4I-Hd & X2-4O-Hd

    X2-1616: Modular 16x16 Matrix Switcher DVI- YPbPr: Signal Signal GREEN BLUE Other pins are unused. DVI- VGA (female): Signal Signal Horizontal Sync GREEN Analog Vertical Sync Analog Other pins are unused. 2.2.3. X2-4I-HD & X2-4O-HD HDMI signal card. (Please check the specification from 5.2.3) It boasts embedded EDID management, and supports DDC.

  • Page 13: X2-4I-Hs & X2-4O-Hs

    X2-1616: Modular 16x16 Matrix Switcher TMDS Data 1- DDC Clock TMDS Data 0+ No Connect TMDS Data 0 Shield TMDS Data 0- TMDS Clock- TMDS Clock TMDS Clock+ Shield 2.2.4. X2-4I-HS & X2-4O-HS Seamless HDMI signal card with auxiliary audio port (Please check the specification from 5.2.4)
  • Page 14 X2-1616: Modular 16x16 Matrix Switcher Output card only supports VGA output X2-4I-VG: input card, maximum four input signal, support VGA (RGBHV), YPbPr, S- video, C-video& CVBS. Input signal can pass to output device through any kinds of output cards. X2-4O-VG: output card, maximum four VGA output signal and 4 stereo audio outputs, output video signal from X2-4I-VG, or other kinds of input cards, and output audio signal from the audio of the input signal.

  • Page 15: X2-4I-Va

    X2-1616: Modular 16x16 Matrix Switcher VGA- C-VIDEO: Signal Signal Other pins are not used. 2.2.6. X2-4I-VA VGA signal card. (Please check the specification from 5.2.6) Scale all inputs to 1080p or 1920x1200; Input signal can be VGA (RGBHV), YPbPr, S-video, C-video or CVBS;...

  • Page 16: X2-4I-Ss

    X2-1616: Modular 16x16 Matrix Switcher The BNC connector is shown as the figure below. Tip (+) Sleeve ( ) BNC Connector 2.2.8. X2-4I-SS Seamless SDI signal card (Please check the specification from 5.2.8) It is compatible with different SDI signal formats, including SD/HD/3G-SDI (adaptive), support seamless transmission for high-definition signal up to 1080p;...

  • Page 17: X2-4I-Uh & X2-4O-Uh

    X2-1616: Modular 16x16 Matrix Switcher X2-4O-TP: output card, maximum output four HDMI TP signal, output signals from X2-4I-TP, or other kinds of input cards, need to work with HD-70XR. How the indicators work: Color Definition Status Blink once powered on;...

  • Page 18: X2-4I-Uf & X2-4O-Uf

    X2-1616: Modular 16x16 Matrix Switcher It also boasts embedded EDID management. X2-4I-UH: input card, maximum four input signal. Input signal can pass to output device through X2-4O-UH, or other kinds of output cards. Note: When matching with output cards that do not support 4kx2k, adjust the input resolution to 1080p to enable reliable output.

  • Page 19: X2-4I-Bt & X2-4O-Bt

    Multi-mode optical fiber cable Before using X2-4I-UF & X2-4O-UF, upgrade the front-board and backboard of X2-1616. Seek technical assistant from our technical supporters. 2.2.12. X2-4I-BT & X2-4O-BT 4K Twisted pair card (Please check the specification from 5.2.12) Support HDTV, compatible with HDBT 1.0, HDMI1.4a&...

  • Page 20: System Connection

    X2-1616: Modular 16x16 Matrix Switcher 3. System Connection 3.1. Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safe.

  • Page 21: Control Operations

    X2-1616: Modular 16x16 Matrix Switcher 4. Control Operations 4.1. Front Panel Button control Users can control X2-1616 rapidly and directly with its front panel buttons. To switch AV signal, please operate the buttons under the following format: Format: “Input Channel” + “AV” +“Output Channel”+“Enter”...

  • Page 22: Ir Remote Control

    X2-1616: Modular 16x16 Matrix Switcher 4.2. IR Remote control With the IR remote, X2-1616 could be controlled remotely. As the function buttons on the IR remote are the same with the ones on the front panel, the IR remote shares the same operations and commands with the control panel.

  • Page 23: Rs232 Communication Commands

    Unused Unused Unused Unused When X2-1616 connects to the RS232 port of a computer with control software, users can control it by that computer. To control the switcher, users need to use RS232 control software. 4.3.2. RS232 Communication Commands With this command system, users are able to control and operate the X2-1616 with RS232 software remotely.
  • Page 24 X2-1616: Modular 16x16 Matrix Switcher Communication protocol: Baud rate: 9600; Data bit: 8; Stop bit: 1; Parity bit: none. Command Description Feedback X2-1616 /*Type; Inquire the models information. System Locked! /%Lock; Lock front panel buttons. System Unlock! /%Unlock; Unlock front panel buttons.
  • Page 25 X2-1616: Modular 16x16 Matrix Switcher Save the present operation to the Save To F8 Save[Y]. preset command [Y]. [Y] ranges from 0 to 9. Recall From F8 V: 01->001 Recall[Y]. Recall the preset command [Y]. A: 01->001 … … Clear F8 Clear[Y].
  • Page 26 X2-1616: Modular 16x16 Matrix Switcher Custom command for signal cards, USER/[Y]/[X]:*****; [Y]=I/O; [X]= port number; *****: User-definable command, e.g. 0623% Restore factory default. All I/O connection will be restored to 0911%. straight through: 1->1, 2->2,…; saved operation status will remain the same.
  • Page 27 X2-1616: Modular 16x16 Matrix Switcher X2-4O-HS Set the resolution of output [x] to Resolution USER/O/[x]:0804%; 1280x720P @60Hz Out03 1280x720P Set the resolution of output [x] to Resolution USER/O/[x]:0813%; 1280x1080P @60Hz Out03 1920x1080P Set the resolution of output [x] to Resolution USER/O/[x]:0824%;...
  • Page 28 X2-1616: Modular 16x16 Matrix Switcher Set the resolution of input [x] to USER/I/[x]:0621%; 0621% 1600X1200@60Hz. Set the resolution of input [x] to USER/I/[x]:0629%; 0629% 1920X1080@60Hz. Set the resolution of input [x] to USER/I/[x]:0620%; 0620% 1920X1200@60Hz. Restore input [x] to factory default.
  • Page 29 X2-1616: Modular 16x16 Matrix Switcher Set the resolution of input [x] to USER/I/[x]:0619%; 0619% 1360x768, HD Set the resolution of input [x] to USER/I/[x]:0626%; 0626% 1024x768, XGA Set the resolution of input [x] to USER/I/[x]:0627%; 0627% 1280x720, 720P Set the resolution of input [x] to USER/I/[x]:0628%;...
  • Page 30 X2-1616: Modular 16x16 Matrix Switcher Set the resolution of input [x] to USER/I/[x]:0629%; 0629% 1920x1080, 1080P Set the resolution of input [x] to USER/I/[x]:0620%; 0620% 1920x1200, WUXGA Set the resolution of input [x] to USER/I/[x]:0621%; 0621% 1600x1200, UXGA Software update USER/I/[x]:0698%;...
  • Page 31 X2-1616: Modular 16x16 Matrix Switcher Select audio source for input [X] [X] is port number; [Z] stands for audio AUDIO[X]I[Z]. AUDIO1I0. source, can be 0 (embedded HDMI audio) or 1 (analog audio) Examples: 1、 Transfer signals from an input channel to all output channels: [x]All.
  • Page 32 X2-1616: Modular 16x16 Matrix Switcher 14、EDID management command:. EDIDM[X]B[Y]. Example: “EDIDM5B3.” to enable input 3 to learn the EDID data of output 5. 15、Command for signal cards: USER/[Y]/[X]*****. Example: “USER/I/7:0623%;” to set the input 7 to support YPbPr signal, the card is plugged in the second input slot of the matrix.

  • Page 33: Tcp/Ip Control (Optional)

     Controlled by PC(s) in LAN The X2-1616 can be connected with a router to make up a LAN with the PC(s), this make it able to be controlled in a LAN. When control, just make sure the X2-1616’s network segment is the same with the router.

  • Page 34: Control X2-1616 Via Tcp/Ip Communication Software

    Step3. Set the X2-1616’s network segment to the same as the router. Step4. Set the PC’s network segment to the original one. Step5. Connect the X2-1616 and PC(s) to the router. In the same LAN, each PC is able to control the X2-1616 asynchronously.

  • Page 35: Tcp/Ip Configuration

    X2-1616: Modular 16x16 Matrix Switcher 2) After connect successfully, we can enter commands to control the X2-1616, as below: Enter your command here. Commands are the same with RS232 commands listed in 4.3.2 RS232 Communication Commands Here you will receive the feedback when a command is sent.
  • Page 36 X2-1616: Modular 16x16 Matrix Switcher In this interface, you can: Change website display language  Modify network settings: Go to Internet Settings -> WAN  Upgrade TCP/IP module: Go to Administration -> Upload Program -> Select  program file -> Start upgrading Reboot the device after upgrading.

  • Page 37: Specification

    X2-1616: Modular 16x16 Matrix Switcher 5. Specification 5.1. Main Unit Control parts Serial control RS-232, 9- female D 2 = TX, 3 = RX, 5 = Configurations port connector Front panel Installation Rack Mountable Buttons control Options TCP/IP control General...

  • Page 38: X2-4I-Ds & X2-4O-Ds

    X2-1616: Modular 16x16 Matrix Switcher 5.2.2. X2-4I-DS & X2-4O-DS X2-4I-DS X2-4O-DS Input 4 DVI Output 4 DVI Input Output Female DB24+5/HDMI Female DB24+5/HDMI Connector Connector output Input Level T.M.D.S. 2.9V~3.3V T.M.D.S. 2.9V~3.3V Level Input Output 75Ω 75Ω Impedance Impedance General...

  • Page 39: X2-4I-Hs & X2-4O-Hs

    X2-1616: Modular 16x16 Matrix Switcher 5.2.4. X2-4I-HS & X2-4O-HS X2-4I-HS X2-4O-HS 4 HDMI 4 HDMI Input Output 4 Analog Audio 4 Analog Audio 19-pin Type-A 19-pin Type-A Female Input Output Female 3-pin pluggable Connector Connector 3-pin pluggable terminal block terminal block...

  • Page 40: X2-4I-Va

    X2-1616: Modular 16x16 Matrix Switcher 5.2.6. X2-4I-VA Video Audio Input 4 VGA Input 4 Stereo Audio Input Input 3-pin Pluggable Female 15 pin HD Connector Connector Terminal Block Input Level 0.5 ~ 2.0Vp-p CMRR >90dB @20Hz ~ 20KHz Input Input 75Ω...

  • Page 41: X2-4I-Ss

    X2-1616: Modular 16x16 Matrix Switcher 5.2.8. X2-4I-SS Input Output Input 4 SDI Output 4 SDI Input Output Female BNC Female BNC Connector Connector General 8, 10, 12 bit Audio Signal SDI, HD-SDI, 3G-SDI Color Depth Transmission 1080p≤100M 1080p Distance Resolution...

  • Page 42: X2-4I-Uf & X2-4O-Uf

    X2-1616: Modular 16x16 Matrix Switcher Frequency 20Hz～20K Hz Input Impedance 100Ω (Differential) Response X2-4O-UH Video Output Audio Output Output 4 HDMI Output 4 Stereo Output Output 3.5mm Stereo audio Female HDMI Connector Connector connector Min.～Max. Output T.M.D.S. 2.9V~3.3V 75Ω Level...

  • Page 43: X2-4I-Bt & X2-4O-Bt

    X2-1616: Modular 16x16 Matrix Switcher Up to 4Kx2K Resolution 1km (Single mode transmission, using Single Mode Optical Transmission Module and OM3 Single Mode Fiber Cable) Distance 300m (Multi-mode transmission, using Single/ Multi mode Optical Module and OM3 Multi-Mode Fiber Cable) Data Rate 10.2Gbit/s...
  • Page 44 X2-1616: Modular 16x16 Matrix Switcher Audio Format Analog audio: PCM HDMI Support HDMI1.4a Standard EDID& HDCP Compliant with HDCP 1.4; Support manual EDID management Management U.T.E. electronic GmbH & Co. KG www.ute.de...

  • Page 45: Troubleshooting & Maintenance

    X2-1616: Modular 16x16 Matrix Switcher 6. Troubleshooting & Maintenance Problems Causes Solutions Bad quality of the Try another high quality connecting cable cable Output image with ghost Impropriate image setting Adjust corresponding of the displayer image settings Output image with color...
  • Page 46 RS232 / IR remote / been broken. dealer for repairing. front panel buttons If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support (info@ute.de). U.T.E. electronic GmbH & Co. KG www.ute.de...

  • Page 47: After-Sales Service

    X2-1616: Modular 16x16 Matrix Switcher 7. After-sales Service If there appear some problems when running X2-1616, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for two years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
  • Page 48 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de...
