Datexx LED-45 Owner's Manual

Button
Ligth Switch
PM
Back Side

Set the Time

Note: To select Military Time Press 12/24 Button
Before Setting Time (Clock will only speak in regular Time Mode)
1. Press SET.
2. Press H and M to set hour and minute
3. Press SET twice.

Set the Alarm

1. Press SET twice.
2. Press H and M to adjust
the Alarm hour and minute.
3. Press iTALK button to choose a
Chirping or Beeping sound.
4. Press SET.
ALARM

When Alarm sounds:

Press iTALK button to snooze,
Press iTALK button twice to stop alarm.
Talking Clock
LED Flash Light
12/24
Hour
Display
(Speech
12 hr.
Reset Hole
only)
12/24
ALARM
SET H M CHIME
RESET
ON
OFF
Automatically Shuts
Light OFF when
Standing
Bottom

Inserting the Batteries

Before using your LED-45 insert
Five 1.5V AAA alkaline batter ies:
1. Remove back cover
2. Insert batteries, following
polarity diagram
3. Replace the cover
Note: Three batteries are for LIGHT
Two batteries are for CLOCK

To Reset the Clock

Insert paper clip into
RESET Hole

Hourly Chime

Press CHIME for an
hourly time and
temperature report.

Save Battery Power

Turn off Chime and
Alarm when not used.
When voice slows,
replace Batteries.
www.datexx.com

TELEDEX Limited U.S.A. Warranty

TELEDEX INC. warrants these products to the original purchaser to
be free from defective material and workmanship. The product will
be repaired or replaced at our option, for up to one year when
returned with proof of purchase to the address below. Include a
check or money order for $5.00 to cover postage.
TELEDEX INC. 1 Atlas st. Kenilworth, NJ 07033
Warranty valid only in the U.S.A.
LED-45
Printed in China 2/04
