- Page 1 ver. 1.2 EN User Guide...
- Page 2 • Be sure to install the navigator where it does not block the driver’s view. Do not install the product over an air bag cover or within the air bag deployment zone. COWON assumes no responsibility of liability for injury or death as a result of car crashes and/or air bag deployment.
- Page 3 FM transmission when the FM radio is set to the same frequency. I/O Connection Terminal : Connection port for connecting COWON Q5W. Volume : Adjust the cradle speaker volume. Power LED : Shows the ON/OFF status NAVI Button : Executes the Navigator.
- Page 4 COWON CR1 Remote Keys for Navigator Music Mode Power Menu Previous Fast Forward (FF) Rewind (REW) Volume Move Focus Show File List Close Current Mode LCD off - Please refer to Q5W manual for full function of the remote - The remote is included in Q5W Package Windshield suction mount ①...
-
Page 5: Dashboard Installation
4. Use the number 2 and 3 knobs to adjust the angle and rotation of the pedestal to provide the best visibility. 5. Press and release the front of the cradle to release the cradle part for the COWON Q5W. 6. Make sure the COWON Q5W’s I/O terminal is completely inserted into the I/O connection terminal of the cradle. - Page 6 5. Use the number 2 and 3 knobs to adjust the angle and rotation of the pedestal to provide the best visibility. 6. Press and release the front of the cradle to release the cradle part for the COWON Q5W. 7. Make sure the COWON Q5W’s I/O terminal is completely inserted into the I/O connection terminal of the cradle.
-
Page 7: Additional Explanation
Additional Explanation ▶Product Specification COWON Q5W - Cradle Navigation Map Tele Atlas GPS Receiver SIRF III CHIP Supply Voltage DC 12 ~ 24V Charging Current 3A (MAX) Charging Voltage Frequency Scope 3 Channel : 88.1 / 88.5 / 88.9 Mhz... - Page 8 COWON CR1 ▶Activation Process After installing the NavMate navigation software on your device, please go to the following web site to obtain the code to activate the software: “http://www.horizonnav.com/activation/cowon” User name: cowon Password: 3r4t56 Voucher code is attached on the back of the cradle.
