ASMML4000
Installationsmanual
Mercedes NTG 4.5 A/B/CLA/GLA
Installation instructions/User
CARVISION 05-2019
2013-2015 CarPlay kit
guide
CARVxxx
CarVision ApS
Tlf. +45 62 800 900
Telemarken 3A
www.carvision.dk
DK-5600 Faaborg
mail@carvision.dk
CVR-nr. 19519236
support@carvision.dk
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for CarVision ASMML4000
- Page 1 ASMML4000 Installationsmanual Mercedes NTG 4.5 A/B/CLA/GLA 2013-2015 CarPlay kit Installation instructions/User guide CARVISION 05-2019 CARVxxx CarVision ApS Tlf. +45 62 800 900 Telemarken 3A www.carvision.dk DK-5600 Faaborg mail@carvision.dk CVR-nr. 19519236 support@carvision.dk...
- Page 2 Installation – Please note installation is performed at your own risk – this guide is for reference only. If you are unsure of your ability to install this equipment, please consult an automotive professional. Installation steps overview – 1) Remove vent trim to expose radio unit bolts, remove radio unit 2) Make connections behind radio unit 3) Run microphone wiring and locate microphone (can route to a location of your preference or hide behind existing microphone cover)
- Page 3 Once vents have been removed, if you look into the space behind them, you will see a TORX screw behind each of the left/right air vents, screwed into a plastic bracket going straight down. These two screws and brackets hold the Mercedes original radio in place. When both screws are removed, reach your hands into space behind air vents and you can feel that the radio is released, carefully push out the radio unit a little to make sure it is free to move (it is recommended to lay down a cloth to protect centre console trim...
- Page 4 When this is disconnected you will be able to see the rear of the stereo unit. Connections – Behind the radio itself, we are only working with 2 connections 1) Quadlock (large black plastic multi plug – held in place with a swivelling clip) 2) LVDS (Video) connection –...
- Page 5 Remove quadlock from original radio unit – locked in place with swivelling clip Connect factory quadlock connector to CarPlay quadlock female end.
- Page 6 Connect male end of CarPlay quadlock to rear of original radio – ensure clip at bottom of connector is fully pressed home. Remove blue LVDS cable (marked with red arrow) from rear of original radio (may be in a different location in your vehicle – however it is usually marked with text ‘DISP’ above) – depress small clip at side of connector whilst carefully pulling out –...
- Page 7 Audio Connection – Depending on your preference, there are two ways to connect the AUX Audio pass-through cable coming from the power wiring loom – either connect directly to the quadlock pass- through connector, or connect the 3.5mm lead directly from ‘AUDIO OUT’ on CarPlay power loom to the cars 3.5mm AUX socket.
- Page 8 Sørg for at Bluetooth er tændt/aktiveret i din iPhones indstillinger Søg efter Bluetooth-enheder på din iPhone. Efter søgningen vises CarPlay boksen som ‘IDCORE’, når du søger efter enheder. Vælg IDCORE og par denne med din iPhone. Indtast dernæst koden nedenfor og tryk par. CarVision ApS Tlf. +45 62 800 900 Telemarken 3A www.carvision.dk DK-5600 Faaborg mail@carvision.dk...
- Page 9 Hvis du har forbindelsesproblemer med det trådløse CarPlay modul, eller du ønsker at oprette forbindelse til en anden iPhone, skal du vælge ‘Reboot’ under Smartphone i Settings menuen på CarPlay boksens hovedmenu, som vist nedenfor og forsøg nu at genoprette forbindelse ved hjælp af tidligere trin. CarVision ApS Tlf. +45 62 800 900 Telemarken 3A www.carvision.dk DK-5600 Faaborg mail@carvision.dk...
- Page 10 CarPlay" - skal tilsluttes - se video til demo på følgende link: https://www.youtube.com/watch?v=IDLuUPCo5dE Hvis CarPlay menu ikke kommer op på skærmen: 1. Tjek at SiRi er sat ON på din telefon. CarVision ApS Tlf. +45 62 800 900 Telemarken 3A www.carvision.dk DK-5600 Faaborg mail@carvision.dk...
