- Page 1 PAGE: MODEL： PRODUCT 1 OF 4 ZT-823T INSTRUCTION DESCRIPTION Wireless Camera ZT-823T WIRELESS CAMERA USER’S MANUAL REVISIONS DESCRIPTION DATE DESIGN APPROVAL SHENZHEN ZHONGWANG ELECTRON CO., LTD PAGES FILE ISSUE DATE CHECK TOTAL NUMBER DESIGN...
- Page 2 MODEL：ZT-823T FILE NUMBER： PAGES: 2 OF 4 Operation instruction 1. Connecting the receiver antenna. (Figure 1) 2. Connecting the 12V adapter (Figure 2), open up the switch(Figure 5),LED indicator lights up (ch1),Press the Key-press(Figure 8), LED indicator （ch1、 ch2、 ch3、 ch4） lights up in proper order。...
- Page 3 MODEL：ZT-823T FILE NUMBER： PAGES: 3 OF 4 Technical data ITEM TYPE Transmission Frequency 2.414~2.468GHz Electric power: DC 12V Output power 0±3dBm Video input: 1.0V (MAX) Power consumption current 63~85(IR OFF)/85~250(IR ON)mA Audio input: (Max.) Effective range (no obstacles) 100m CMOS...
- Page 4 MODEL：ZT-823T FILE NUMBER： PAGES: 4 OF 4 ⑦ ⑥ ① ③ ①: Antenna ⑧ ②: Power Jack ③: Flash LED(ch1、ch2、ch3、ch4) ② ④: Video and Audio Jack ⑤: Switch ⑤ ⑥: Camera Power Line ⑦: Lens of camera ④ Audio ⑧ Key-press Video 2.4G Receiver...
