INSTALLATION INSTRUCTIONS
Curaflex Nova
Gasket inserts
Curaflex Nova
Uno/M/Z
®
Intended use
The gasket insert Curaflex Nova
the sealing of several pipes and cables with a smooth surface.
Curaflex Nova
Uno/M/Z is hinged, to accommodate sealing pipes
®
and cables that have already been laid.
Please note:
• Gasket inserts are not secure points or support bearings; they are
only used for elastic sealing of pipes/cables.
• Slight axial movements of the pipes and cables are permitted.
Furthermore, fixing tabs are optionally available and can be
screwed onto the frame ring (fixing set accessory). These tabs
additionally secure the gasket insert when the pressure loads are
higher.
• Curaflex
gasket inserts are maintenance-free. Once correctly
®
installed, it is not necessary to re-tighten the bolts.
• The relevant FHRK standard (minimum seal width) can be found
on the product label.
• The applicable national regulations governing the laying and
filling of pipes and cables must be observed.
®
Uno/M/Z is especially suitable for
®
Curaflex Nova
Uno/M/Z
®
Advertisement
Table of Contents
Related Manuals for DOYMA Curaflex Nova Uno/M/Z
Summary of Contents for DOYMA Curaflex Nova Uno/M/Z
- Page 1 English INSTALLATION INSTRUCTIONS Curaflex Nova ® Curaflex Nova Uno/M/Z ® Gasket inserts Curaflex Nova Uno/M/Z ® Intended use The gasket insert Curaflex Nova Uno/M/Z is especially suitable for ® the sealing of several pipes and cables with a smooth surface. Curaflex Nova Uno/M/Z is hinged, to accommodate sealing pipes ®...
- Page 2 - see on the carton Determine the diameter of the core boring or pipe sleeve, Media lines to be sealed are shown in Table 1. and the media line and check it against the information on the carton. www.doyma.com Page 2...
- Page 3 4e: Installation in combi- nation with a Quadro-Secura ® Curaflex Nova Uno/M/Z ® Prior to installation in a Quadro-Secura ADS the fixing tabs ® must be screwed onto the frame ring using a conventional screwdriver. www.doyma.com Page 3...
- Page 4 5 nm torque. continue the installation as described under 4, or ... DOYMA products are continuously being further developed. Technical changes will be performed without prior notice. 25 year warranty on all DOYMA products. More information at www.doyma.com DOYMA GmbH &...
