Summary of Contents for LG Steam Dryer DLGX2551 Series
Page 1
OWNER’S MANUAL DRYER Please read this manual carefully before operating your dryer and retain it for future reference. DLEX2550* DLGX2551* DLEX2450* DLGX2451* DLEX2650* DLGX2651* DLEX2655* DLGX2656* www.lg.com P/No. MFL67731002...
Safety Instructions for Steam Functions ....6 Safety Instructions for Connecting Electricity ..7 Congratulations on your purchase PARTS AND FEATURES and welcome to the LG family. Your Special Features ............. 8 Key Parts and Components ........9 new LG Dryer combines the most...
READ ALL INSTRUCTIONS BEFORE USE wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons , or death. Your Safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance.
READ ALL INSTRUCTIONS BEFORE USE wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons , or death. BASIC SAFETY PRECAUTIONS wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:...
READ ALL INSTRUCTIONS BEFORE USE wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons , or death. GROUNDING INSTRUCTIONS This appliance must be grounded.
READ ALL INSTRUCTIONS BEFORE USE wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR INSTALLATION wWARNING: To reduce the risk of injury to persons , follow all industry recommended safety procedures including the use of long sleeved gloves and safety glasses.
READ ALL INSTRUCTIONS BEFORE USE wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons , or death. SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:...
The door hinge can be reversed to adjust for installation location. STEAM FUnCTIonS LG’s steam technology allows you to inject fabrics with a swirling jet of hot steam to refresh clothes, reduce static, and make ironing easier.
KEY PARTS AND COMPONENTS In addition to the special features and components outlined in the Special Features section, there are several other important components that are referenced in this manual. FRONT-MOUNT LINT FILTER Front-mount lint filter allows for easy access and cleaning after every load.
WARNING: Read all installation instructions completely before installing and operating your dryer! It is important that you review this entire manual before installing and using your dryer. Detailed instructions concerning electrical connections, gas connections, and exhaust requirements are provided on the following pages. INSTALLATION LOCATION REQUIREMENTS A location that allows for proper exhaust installation.
INSTALLATION WITH OPTIONAL PEDESTAL BASE OR STACKING KIT WARNING : If you are installing your dryer using an optional pedestal base or stacking kit, please refer to Optional Accessories in this manual or to the instructions for your pedestal or stacking kit before proceeding with the installation.
Position the dryer in the final location. Place a level across the top of the dryer. OPTIONAL ACCESSORIES For these and other LG products, contact your local LG dealer, or visit our Web site at www.lg.com. Stacking Kit Pedestal (sold separately)
TO REMOVE THE DOOR wWARNING THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure to follow the instructions below can result in damage to the dryer, property damage or injury to persons . • T o avoid damage to the dryer or the door, support the door with a stool or box that fits under the door, or have an assistant support the weight of the door. • A lways reverse the door BEFORE stacking the dryer on top of the washer.
TO INSTALL THE DOOR wWARNING THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure to follow the instructions below can result in damage to the dryer, property damage or injury to persons . • T o avoid damage to the dryer or the door, support the door with a stool or box that fits under the door, or have an assistant support the weight of the door. • A lways reverse the door BEFORE stacking the dryer on top of the washer.
(right-side venting is not available on gas models). screw. Pull out the exhaust duct. An adapter kit, part number 383EEL9001B, may be purchased from your LG retailer. This kit contains the necessary duct components to change the dryer vent location.
VENTING THE DRYER wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Do not crush or collapse ductwork. Failure • Rigid or semirigid metal ducting is to follow these instructions can result in fire recommended for use between the dryer or death.
Page 17
VENTING THE DRYER (cont.) Ductwork Maximum Length of 4-inch Diameter Wall Cap Type Number of 90° Elbows Rigid Metal Duct 65 ft. (19.8 m) Recommended 55 ft. (16.8 m) 47 ft. (13.7 m) 36 ft. (11.0 m) 4" 4" (10.2 cm) (10.2 cm) 28 ft.
CONNECTING GAS DRYERS wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Gas supply requirements: • Connect the dryer to the type of gas shown on As shipped from the factory, this dryer is the nameplate.
Page 19
CONNECTING GAS DRYERS (cont.) wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Installation and service must be performed • If necessary, the correct orifice (for the LP by a qualified installer, service agency, or the orifice kit order part number 383EEL3002D) gas supplier.
CONNECTING ELECTRIC DRYERS wWARNING: To help prevent fire, electric shock, serious injury, or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70 and all applicable local regulations. Please contact a qualified electrician to check your home’s wiring and fuses to ensure that your home has adequate electrical power to operate the dryer.
Page 21
CONNECTING ELECTRIC DRYERS (cont.) USA ONLY wWARNING: • Connect the power cord to the terminal block. Each colored wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block. Failure to follow these instructions may result in a short or overload. •...
Page 22
CONNECTING ELECTRIC DRYERS (cont.) USA ONLY wWARNING: • Connect the power cord to the terminal block. Each colored wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block. Failure to follow these instructions may result in a short or overload. •...
Page 23
CONNECTING ELECTRIC DRYERS (cont.) USA ONLY wWARNING: • Connect the power cord to the terminal block. Each colored wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block. Failure to follow these instructions may result in a short or overload. •...
Page 24
CONNECTING ELECTRIC DRYERS (cont.) USA ONLY WARNING: • Connect the power cord to the terminal block. Each colored wire should be connected to same color screw. Wire color indicated on manual is connected to the same color screw in block. Failure to follow these instructions may result in a short or overload. •...
SPECIAL REQUIREMENTS FOR MANUFACTURED OR MOBILE HOMES Any installation in a manufactured or mobile • The dryer exhaust duct must be affixed securely home must comply with the Manufactured Home to the manufactured or mobile home structure, Construction and Safety Standards Title 24 CFR, and the exhaust duct must be made of a Part 32-80 or Standard CAN/CSA0Z240 MH and material that will resist fire and combustion.
INSTALLATION TEST (Exhaust check) Once you have completed the installation of the dryer, use this test to make sure the condition of the exhaust system is adequate for proper operation of the dryer. This test should be performed to alert you to any serious problems in the exhaust system of your home.
Page 27
INSTALLATION TEST (Exhaust check) Check the Error Code before you call for service • Error Code Possible Causes Solutions Temperature sensor failure T urn off the dryer and call for • • tE1 or tE2 service. Humidity Sensor failure. T urn off the dryer and call for •...
NOTE: If you do not press the START/PAUSE STEAM FUNCTIONS button to resume a cycle within 4 minutes, the dryer turns off automatically. LG’s steam technology allows you to inject fabrics with a swirling jet of hot steam to refresh clothes, reduce static, MORE TIME/LESS TIME BUTTONS and make ironing easier.
OPERATING THE DRYER CLEAN THE LINT FILTER If the lint filter has not already been cleaned, lift out the filter and remove the lint from the last load. This will help ensure the fastest and most efficient drying performance. LOAD THE DRYER Load the dryer with the wet laundry from the washer.
Sensor Dry Cycles Manual Dry Cycles Sensor Dry cycles utilize LG’s unique dual sensor system Use Manual Dry cycles to select a specific amount of to detect and compare the moisture level in clothes and drying time and a drying temperature. When a Manual...
Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for more detailed information. w WARNING: To reduce the risk of fire, electric shock, or injury to persons , read this entire manual, including the Important Safety Instructions, before operating this dryer.
THE DISPLAY The display shows the settings, estimated time remaining, options, and status messages for your dryer. When the dryer is turned on, the light in the display will illuminate. ESTIMATED TIME REMAINING CHECK FILTER REMINDER When the START/PAUSE button is pressed, The display will show CHECK FILTER when the dryer will display the estimated (SENSOR the dryer is turned on as a reminder to check...
CYCLE SETTING BUTTONS SENSOR DRY cycles have preset settings Your dryer features several additional cycle that are selected automatically. MANUAL DRY options to customize cycles to meet your cycles have default settings, but you may individual needs. Certain option buttons also customize the settings using the cycle setting feature a special function (see the following page buttons.
SPECIAL FUNCTIONS The option buttons also activate special Fuctions, including CHILD LOCK, RACK DRY, DAMP DRY SIGNAL. Press and hold the option button marked with the special function for 3 seconds to activate. CHILD LOCK RACK DRY Use this option to prevent Use RACK DRY with items, such unwanted use of the dryer or to as wool sweaters, silk, and lingerie,...
CUSTOM PROGRAM If you have a special combination of settings NOTE: You may save only one custom that you use frequently, you can save these program at a time. Pressing and holding the settings as a CUSTOM PROGRAM. CUSTOM PROGRAM button will overwrite any previously saved custom program.
Page 36
STEAM FUNCTIONS (cont.) Using the Steam Options: LG’s new steam technology allows you to inject fabrics with a swirling jet of hot steam to refresh This option injects steam late in the clothes, reduce static, and make ironing easier. drying cycle to reduce the static...
STEAM FUNCTIONS (cont.) IMPORTANT NOTES ABOUT STEAM CYCLES: wWARNING: • S team may not be clearly visible during the • Do not open the dryer door during steam steam cycles. This is normal. cycles. Steam can cause severe burns. • D o not use STEAMFRESH with items such as ™ • Do not fill the steam feeder with gasoline, wool, wool blanket, leather jackets, silk, wet dry-cleaning solvents, or other flammable or clothes, lingerie, foam products, or electric explosive substances.
REGULAR CLEANING wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Unplug the dryer before cleaning to avoid the risk of electric shock. Failure to follow this warning can cause serious injury, fire, electric shock, or death.
BEFORE CALLING FOR SERVICE Your dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If your dryer does not function properly or does not function at all, check the following before you call for service. Problem Possible Causes Solutions...
Page 40
BEFORE CALLING FOR SERVICE (cont.) Problem Possible Causes Solutions • The drying time for a load will vary depending on Drying time is not • Heat settings, load size, or dampness of clothing is not the heat setting, the type of heat used (electric, consistent natural gas, or LP gas), the size of the load, the consistent.
Page 41
BEFORE CALLING FOR SERVICE (cont.) Problem Possible Causes Solutions Steam doesn’t • Water level error. • Unplug dryer and call for service. generate but no error code is shown Garments still • Too many or too different • Small loads of 1 to 5 items work best. wrinkled after types of garments in dryer. • Load fewer garments. Load similar-type garments. STEAM FRESH ™ • Use an iron to make creases.
OPTIONAL ACCESSORIES For these and other LG products contact your local LG dealer, or visit our Web site at www.lg.com. Stacking kit Pedestal (sold separately) (sold separately)
PEDESTAL INSTALLATION The pedestal accessory includes: To ensure safe and secure installation, please thoroughly follow the instructions below. • Drawer divider (1) • Wrench (1) • S crews (18) † • Retainers (4) †† wWARNING • Incorrect installation can cause serious accidents. • The appliances are heavy. Two or more people are required when installing the pedestal.
Page 45
PEDESTAL INSTALLATION (cont.) For dryer For washer/combo Make sure the screws on the pedestal align Place the dryer on the pedestal. Make sure with the holes in the retainers, then install 4 the front and back feet are in the correct screws on each side to securely attach the positions.
STACKING KIT INSTALLATION This stacking kit includes: To ensure safe and secure installation, please observe the following instructions. • T wo (2) side rails • O ne (1) front rail wWARNING • F our (4) screws • Incorrect installation can cause serious accidents.
STACKING KIT INSTALLATION (cont.) Dryer Washer Place the dryer on top of the washer by Insert the front rail between the bottom of fitting the dryer feet into the side brackets as the dryer and the top of the washer. Push the illustrated.
Page 49
MANUAL DE PROPIETARIO SECADORA Lea este manual con cuidado antes de utilizar la secadora y guárdelo para futuras consultas. DLEX2550* DLGX2551* DLEX2450* DLGX2451* DLEX2650* DLGX2651* DLEX2655* DLGX2656*...
Page 50
............5 Felicitaciones por su compra y Instrucciones de seguridad para funciones de vapor ..........6 Instrucciones importantes para conectar bienvenido a la familia LG. Su la electricidad ............7 nueva Secadora LG combina la PIEZAS Y CARACTERÍSTICAS Características especiales........8 tecnología de sensor de secado más...
LEA TODAS LA INSTRUCCIONES ANTES DE USAR wADVERTENCIA Por su seguridad, debe seguir la información indicada en este manual para minimizar el riesgo de incendio o explosión, descarga eléctrica, o para prevenir daños a la propiedad, lesiones personales o muerte. Su Seguridad y la de los demás son de suma importancia.
LEA TODAS LA INSTRUCCIONES ANTES DE USAR wADVERTENCIA Por su seguridad, se debe seguir la información indicada en este manual para minimizar el riesgo de incendio o explosión, descarga eléctrica, o para prevenir daños a la propiedad, lesiones personales o muerte. PRECAUCIONES BáSICAS DE SEGURIDAD wADVERTENCIA Para minimizar el riesgo de incendio o explosión, descarga eléctrica,...
LEA TODAS LA INSTRUCCIONES ANTES DE USAR wADVERTENCIA Por su seguridad, se debe seguir la información indicada en este manual para minimizar el riesgo de incendio o explosión, descarga eléctrica, o para prevenir daños a la propiedad, lesiones personales o muerte. INSTRUCCIONES DE CONEXIÓN A TIERRA Este electrodoméstico deberá...
LEA TODAS LA INSTRUCCIONES ANTES DE USAR wADVERTENCIA Por su seguridad, se debe seguir la información indicada en este manual para minimizar el riesgo de incendio o explosión, descarga eléctrica, o para prevenir daños a la propiedad, lesiones personales o muerte. INSTRUCCIONES IMPORTANTES PARA LA INSTALACIÓN wADVERTENCIA Para reducir el riesgo de lesiones personales, cumpla con...
LEA TODAS LA INSTRUCCIONES ANTES DE USAR wADVERTENCIA Por su seguridad, se debe seguir la información indicada en este manual para minimizar el riesgo de incendio o explosión, descarga eléctrica, o para prevenir daños a la propiedad, lesiones personales o muerte. INSTRUCCIONES IMPORTANTES PARA CONECTAR LA ELECTRICIDAD wADVERTENCIA Para reducir el riesgo de incendio, descargas eléctricas o...
Se puede invertir el sentido de la puerta para adaptarlo al lugar de la instalación. FUNCIONES DE VAPOR ÚTILES La nueva tecnología de vapor de LG le permite inyectar las telas con un chorro giratorio de vapor caliente para refrescar las prendas, reducir la estática y facilitar el planchado.
PIEZAS Y COMPONENTES CLAVE Además de las características y componentes descritos en la sección de Características especiales, hay varios componentes importantes adicionales a los cuales se hace referencia en este manual. FILTRO DE PELUSA MONTADO AL FRENTE el filtro de pelusa montado al frente permite un fácil acceso y limpieza después de cada carga.
ADVERTENCIA: Siga las instrucciones de funcionamiento y cuidado incluidas en este manual y conseguirá que su secadora ofrezca un servicio fiable y duradero. Es importante que revise todo este manual antes de instalar y usar su secadora. Se proporcionan instrucciones detalla- das pertinentes a las conexiones eléctricas, de gas y los requisitos de escape en las siguientes páginas.
INSTALACIONES CON LA BASE PEDESTAL O KIT DE APILADO OPCIONALES w ADVERTENCIA : Si está instalando su secadora con una base de pedestal o un kit de apilado opcionales, consulte la sección de Accesorios opcionales incluida en este manual o las instrucciones de su pedestal o kit de apilado antes de continuar con la instalación.
Coloque la secadora en la posición final. Coloque un nivelador sobre la secadora. ACCESORIOS OPCIONALES Para estos y otros productos LG, llame a su distribuidor LG local, o visite nuestro sitio Web en www.lg.com. Pedestal Kit de apilado Adquirido por...
PARA RETIRAR LA PUERTA wADVERTENCIA LA PUERTA DE LA SECADORA ES MUY GRANDE Y PESADA. El no seguimiento de las instrucciones siguientes puede dañar la secadora, ocasionar daños materiales o físicos. • P ara evitar daños en la secadora o en la puerta, sujete dicha puerta con un taburete o una caja de un tamaño acorde o consiga un apoyo que soporte el peso de la puerta. • G ire la puerta siempre hacia atrás ANTES de colocar la secadora en la parte superior de la lavadora.
PARA INSTALAR LA PUERTA wADVERTENCIA LA PUERTA DE LA SECADORA ES MUY GRANDE Y PESADA. Si no se siguen las instrucciones siguientes, se pueden pro- ducir daños en la secadora, a la propiedad, o bien lesiones personales. • P ara evitar dañar la secadora o la puerta, apoye la puerta sobre una banqueta o con una caja, o pida a otra persona que sujete la puerta mientras realiza este procedimiento.
Puede adquirirse el kit adaptador, número de pieza 383EEL9001B, de su distribuidor LG. Este kit contiene los componentes de conducto necesarios para cambiar la ubicación de la ventilación de la secadora.
CONEXIÓN DEL CONDUCTO DE VENTILACIÓN DE LA SECADORA wADVERTENCIA Para reducir el riesgo de incendio, descargas eléctricas o heridas al usar su electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente: • No aplaste ni doble el sistema de conducto. • Se recomiendan conductos rígidos o semirígidos para usar entre la secadora Si no se siguen estas instrucciones se podrá...
Page 65
CONEXIÓN DEL CONDUCTO DE VENTILACIÓN DE LA SECADORA (cont.) Sistema de conducto Long. máx. de conducto metálico Tipo de tapa de pared Número de Codos de 90° flexible de diám. 4" 65 pies (19,8 m) Recomendado 55 pies (16,8 m) 47 pies (13,7 m) 36 pies (11,0 m) 4"...
CONEXIÓN DE SECADORAS A GAS wADVERTENCIA Para reducir el riesgo de incendio, descargas eléctricas o heridas al usar su electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente: • Requisitos de suministro de gas: • Conecte la secadora al tipo de gas indicado en Como enviado de fábrica, si configura la secadora la placa del nombre.
Page 67
CONEXIÓN DE SECADORAS A GAS (cont.) wADVERTENCIA Para reducir el riesgo de incendio, descargas eléctricas o heridas al usar su electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente: • La instalación y el mantenimiento deben se usará (gas natural o petróleo líquido, LP). proveerse por un instalador calificado, agencia Si no se cumple con esto se podrá...
CÓMO CONECTAR LAS SECADORAS ELÉCTRICAS wADVERTENCIA: Para ayudar a evitar incendios, descargas eléctricas, heridas graves o muerte, el cableado e instalación a tierra deben cumplir con la última edición del Código Eléctrico Nacional, ANSI/NFPA 70 y todas las regulaciones locales aplicables. Por favor comuníquese con un electri- cista calificado para que controle el cableado y los fusibles y así...
Page 69
CÓMO CONECTAR LAS SECADORAS ELÉCTRICAS (cont.) SÓLO EE.UU. wADVERTENCIA: • Conecte el cable de suministro de corriente al bloque terminal. Cada cable de color, se debe conectar al tornillo del mismo color. El color del cable que figura en el manual se conecta el tornillo del mismo color en el bloque.
Page 70
CÓMO CONECTAR LAS SECADORAS ELÉCTRICAS (cont.) SÓLO EE.UU. wADVERTENCIA: • Conecte el cable de suministro de corriente al bloque terminal. Cada cable de color se debe conectar al tornillo del mismo color. El color del cable que figura en el manual se conecta el tornillo del mismo color en el bloque.
Page 71
CÓMO CONECTAR LAS SECADORAS ELÉCTRICAS (cont.) SÓLO EE.UU. wADVERTENCIA: • Conecte el cable de suministro de corriente al bloque terminal. Cada cable de color se debe conectar al tornillo del mismo color. El color del cable que figura en el manual se conecta el tornillo del mismo color en el bloque.
Page 72
CÓMO CONECTAR LAS SECADORAS ELÉCTRICAS (cont.) SÓLO EE.UU. wADVERTENCIA: • Conecte el cable de suministro de corriente al bloque terminal. Cada cable de color se debe conectar al tornillo del mismo color. El color del cable que figura en el manual se conecta el tornillo del mismo color en el bloque.
REQUISITOS ESPECIALES PARA VIVIENDAS MÓVILES O PREFABRICADAS Cualquier instalación en una vivienda móvil o • El conducto de escape de la secadora debe prefabricada debe realizarse de conformidad con estar bien fijado a la estructura de la vivienda los Estándares de seguridad y construcción de móvil o prefabricada, y el conducto de escape viviendas prefabricadas, Título 24 CFR, Parte debe estar fabricado de un material resistente al 32-80 o estándar CAN/CSA0Z240 mh y con los...
TEST DE INSTALACIÓN (Comprobación del sistema de evacuación) Una vez haya instalado la secadora, haga este test para asegurarse de que las condiciones del sistema de evacuación son las adecuadas para el funcionamiento correcto de la secadora. Este test tiene como objetivo mostrarle si existe algún problema importante en el sistema de evacuación de su vivienda.
Page 75
TEST DE INSTALACIÓN (Comprobación del sistema de evacuación) Compruebe el código de error antes de llamar al servicio técnico • Código de error Causas posibles Soluciones Fallo del sensor de temperatura. A pague la secadora y llame al • • tE1 o tE2 servicio técnico.
FUNCIONES ÚTILES CON VAPOR detener un ciclo en 4 minutos, la secadora se apagará automáticamente. La nueva tecnología con vapor de LG le permite inyectar a la ropa un chorro de BOTONES DE MáS TIEMPO/MENOS vapor caliente en forma de remolino, el...
FUNCIONAMIENTO DE LA SECADORA LIMPIAR EL FILTRO DE PELUSAS Si aún no ha limpiado el filtro de pelusas, extráigalo y elimine las pelusas procedentes de la última carga. Esto le ayudará a asegurar un funcionamiento más rápido y eficiente de secado. CARGAR LA SECADORA Cargue en la secadora la carga húmeda procedente de la lavadora.
Los ciclos de SECADO CON SENSOR utilizan el Use los ciclos de SECADO mANUAL para seleccionar sistema exclusivo de sensor doble de LG para detectar una cantidad especifica de tiempo y temperatura de y comparar el nivel de humedad en las prendas y en secado.
A continuación encontrará instrucciones para comenzar a usar su secadora nueva. Para más información por favor consulte las secciones específicas de este manual. w ADVERTENCIA: Para reducir el riesgo de incendios, descargas eléctricas o heridas, lea este manual en su totalidad, incluyendo las Instrucciones Importantes de Seguridad, antes de operar la secadora.
LA PANTALLA La pantalla muestra los ajustes, el tiempo restante estimado, las opciones y los mensajes de estado correspondientes a su secadora. Cuando se gira el secador, la luz en la exhibición iluminará. VERIFICAR FILTRO TIEMPO RESTANTE ESTIMADO La pantalla mostrará VERIFICAR FILTRO Cuando se presiona el boton INICIO/ cuando se ha encendido la secadora como PAUSA, la pantalla indicara el tiempo...
BOTONES DE AJUSTE DE CICLOS Su secadora dispone de varias opciones de ciclo Los ciclos de SECADO POR SENSOR tienen adicionales, las cuales personalizan los ciclos ajustes preprogramados que se seleccionan para satisfacer sus necesidades individuales. automaticamente. Los ciclos de SECADO Ciertos botones de opción también incorporan mANUAL tienen ajustes predeterminados, pero una función especial (vea la siguiente página para...
FUNCIONES ESPECIALES Los botones de opcion tambien activan las funciones especiales, incluyendo, SEGURO PARA NIÑOS, SECADO CON RACK, PLANChAR EN hÚmEDO. Para activar, presione y sostenga el boton marcado con la funcion especial durante 3 segundos. SECADO CON RACK SEGURO PARA NIñOS Use el ciclo SECADO CON RACK Utilice esta opcion para evitar un con artículos tales como suéteres...
PROGRAMA PERSONALIZADO NOTA: Puede guardar solo un programa Si tiene una combinacion especial de ajustes que usa con frecuencia, puede guardar personalizado a la vez. Al apretar y estos ajustes a manera de PROGRAmA mantener apretado el botón PROGRAmA PERSONALIZADO. PERSONALIZADO, reemplazará...
Page 84
FUNCIONES DE VAPOR (cont.) Cómo usar las opciónes de vapór La nueva tecnologia de vapor de LG le permite inyectar las telas con un chorro giratorio de vapor La opcíon REDUCIR ESTÁTICA caliente para refrescar las prendas, reducir la nyecta vapor al final del ciclo de estatica, y facilitar el planchado.
FUNCIONES DE VAPOR (cont.) NOTAS IMPORTANTES SOBRE LOS CICLOS wADVERTENCIA: DE VAPOR: • No abra la puerta de la secadora durante ciclos • P uede que el vapor no sea claramente visible de vapor. El vapor puede provocar quemaduras durante los ciclos de vapor. Esto es normal. graves. • N o use el ciclo STEAmFRESh con elementos ™ • No llene el alimentador de vapor con gasolina, como lana, manta de lana, camperas de cuero, solventes para limpieza en seco, u otras seda, ropa húmeda, lencería, productos de...
LIMPIEZA REGULAR wADVERTENCIA – Para reducir el riesgo de incendio, descargas eléctricas o heridas al usar su electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente: • Desenchufe la secadora antes de limpiar la misma para evitar el riesgo de descargas eléctricas. Si no se cumple con esta advertencia se podrán producir heridas graves, incendios, descargas eléctricas o muerte.
ANTES DE LLAMAR A MANTENIMIENTO Su secadora está equipada con un sistema de monitoreo de errores automático para la detección y el diagnóstico de problemas en una etapa temprana. Si su secadora no funciona adecuadamente o no funciona en lo absoluto, revise lo siguiente antes de llamar a mantenimiento. Problema Causas posibles Soluciones...
Page 88
ANTES DE LLAMAR A MANTENIMIENTO (cont.) Problema Causas posibles Soluciones • El tiempo de secado para una carga variará dependiendo El tiempo de • Los ajustes de calor, el del ajuste de calor, tipo de calor utilizado (eléctrico, secado no es tamaño de la carga o la natural, o gas LP), el tamaño de la carga, el tipo de tela, constante humedad de las prendas el nivel de humedad de las prendas y la condición de los...
Page 89
ANTES DE LLAMAR A MANTENIMIENTO (cont.) Problema Causas posibles Soluciones • Verifique el cajón del alimentador de vapor: La luz de AñADIR • Error de entrada de agua. (1) E l alimentador de vapor debe estar lleno de agua AGUA ( ) esta hasta la línea mAX. encendida durante el ciclo de secado (2) Constate que el alimentador de vapor esté bien colocado y que el cajón esté...
Page 90
ANTES DE LLAMAR A MANTENIMIENTO (cont.) Problema Causas posibles Soluciones No se ve vapor • Es difícil ver el vapor con la puerta cerrada. • Esto es normal. durante el ciclo de Sin embargo, la condensación se forma vapor normalmente en el interior de la puerta de la secadora si el sistema funciona con normalidad. El tambor no gira • El tambor está apagado para que el vapor • Esto es normal.
La efectividad de esta función depende de diversos factores, entre los cuales se incluyen, la recepción del teléfono celular utilizado para la transmisión, cualquier ruido externo que pueda presentarse durante la transmisión, y la acústica de la habitación donde está ubicada la lavadora. Por lo tanto, LG no garantiza que SMARTDIAGNOSIS resuelva con precisión cualquier cuestión dada.
ACCESORIOS OPCIONALES Para estos y otros productos LG, llame a su distribuidor LG local, o visite nuestro sitio Web en www.lg.com Pedestal Kit de apilado (Adquirido por separado) (Adquirido por separado)
INSTALACIÓN DEL PEDESTAL El accesorio de pedestal incluye: Para asegurar la instalación segura, siga cuidadosamente las siguientes instrucciones. • Divisor de cajón (1) • L lave (1) • Tornillos (18) † • Sujetadores (4) †† wADVERTENCIA • L a instalación incorrecta puede causar accidentes graves. • L os electrodomésticos son muy pesados. Se requiere de dos o más personas para instalar del pedestal.
Page 94
INSTALACIÓN DEL PEDESTAL (cont.) Para la secadora Para la lavadora/combinación Asegúrese de que los orificios del Coloque el electrodoméstico encima del pedestal se alinean con los orifiicios de los pedestal. Asegúrese que los pies frentes y sujetadores, luego instale 4 tornillos en cada traseros se encuentren en las posiciones esquina para ajustar en forma segura el elec- correctas.
INSTALACIÓN DEL KIT DE APILADO Para asegurar la instalación segura, siga las siguientes instrucciones. Este kit de apilado incluye: wADVERTENCIA • D os (2) rieles laterales. • L a instalación incorrecta puede causar • U n (1) riel frontal. accidentes graves.
INSTALACIÓN DEL KIT DE APILADO (cont.) Secadora Lavadora Coloque la secadora sobre la lavadora Insterte el riel frontal entre la parte inferior haciendo coincidir las patas en las de la secadora y la parte superior de la abrazaderas laterales como se indica. lavadora.
