  • Page 2 1. BUTTONS LOCATION AND FUNCTIONING VARIABLE COLOR PANEL DISPLAY RELEASE POWER BUTTON(COLOR) BUTTON BUTTON ENCODER MUTE AUDIO VOLUME BUTTON BUTTON BUTTON MONO/ DISP STEREO BUTTON BUTTON AUTOMATICALLY SOURCE SCAN STORE / PRESET BUTTON / BUTTON SCAN BUTTON SUB-WOOFER PRESET EQUALIZER BUTTON PRESET MEMORY BUTTONS (M1~M6) REMOTE...

  • Page 3: Handling Compact Discs

    2. HANDLING COMPACT DISCS MOISTURE CONDENSATION On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an hour until the moisture has evaporated.

  • Page 4: Installation

    3. INSTALLATION Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.

  • Page 5: Din Rear-Mount (Method B)

    Removing the unit Trim Plate Installation: Push the trim plate against the chassis until it is fitted. You must do this before you install the front panel, otherwise it can't be attached. DIN REAR-MOUNT (METHOD B) Installation using the screw holes on the sides of the unit. Fastening the unit to the factory radio mounting bracket.

  • Page 6: Detachable Control Panel (D.c.p .)

    4. DETACHABLE CONTROL PANEL (D.C.P .) Removing The Detachable Control Panel (D.C.P .). PANEL RELEASE BUTTON Attaching the DCP CAUTION DO NOT insert the D.C.P from the left side. Doing so may damage it. The D.C.P can easily be damaged by shocks. After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks.
  • Page 7 5. WIRING DIAGRAM (20 PIN HARNESS PLUG) FUSE 20-PIN AUDIO/POWER HARNESS (See Figure 1) LEFT FRONT WHITE-BLACK LF- WHITE LF+ LEFT REAR GREEN-BLACK LR GREEN LR+ WIRE COLOR FUNCTION/LABEL RIGHT FRONT SPEAKER (-) GREY/BLACK RIGHT FRONT SPEAKER (+) GREY VIOLET RIGHT REAR SPEAKER (+) VIOLET/BLACK RIGHT REAR SPEAKER (-)
  • Page 8 6.PANEL OPEN/CLOSE OPERATION After the CD is loaded or unloaded, push the panel at position A and the panel will return to its original position. in correct position E - 7...

  • Page 9: Basic Operations

    7. BASIC OPERATIONS 1) PANEL RELEASE BUTTON (REL) Press this button to remove the control panel. 12)POWER ON/OFF BUTTON Press this button to turn on or off the power. 6) DISPLAY BUTTON (DISP) Press this button briefly, the LCD will display the clock for about 2 seconds, then return to previous display mode.

  • Page 10: Audio Operations

    8. AUDIO OPERATIONS 10) ENCODER VOLUME BUTTON To increase the volume, rotate the volume control clockwise to decrease the volume, rotate the volume control counter clockwise. When volume is adjusted, the volume level will be shown on the display panel as a number ranging from 0 (lowest) to 46 (highest).

  • Page 11: Radio Operations

    9. RADIO OPERATIONS 11) AUTO MEMORY STORE/PRESET SCAN BUTTON (AS/PS) 1.PRESET SCAN: Press AS/PS button briefly to enter Preset Scan mode, it will scan all the preset stations in the memories, you can hear that it will stay on each station for about 5 seconds. 2.AUTO MEMORY STORE: Press AS/PS button for couple of seconds to enter Auto Store mode, this feature will automatically scan the current band and enter up to 6 strongest stations into the 6 preset memories.
  • Page 12 10.CD OPERATIONS M1) PAUSE BUTTON (PAUSE) Press this button to pause CD play, press again to release pause. M2) SCAN BUTTON (SCAN) Press this button, the first 10 seconds of each track will be played sequentially until this button is pressed again, then normal play will resume at the current track. M3) REPEAT BUTTON (REPEAT) Press this button, the current track will be played repeatedly until this button is pressed again.

  • Page 13: Remote Control

    11.REMOTE CONTROL OPERATIONS: 1. Power 2. Volume Up/Down 3. DISP 4. Stereo/Mono 5. Track Up/Down 6. Loc 7. Scan 8. Mute 9. Audio 10. Sub-woofer(SUB)/ Source 11. Band/Loud 12. AS/PS 13. EQ 14. Numeric Key(1) Radio Mode Power On/Off Adjust Vol,Bas, Tre,Fad,Bal Display Clock, Spectrum FM Mono/ Stereo...

  • Page 14: Specifications

    12.SPECIFICATIONS CD PLAYER System Usable disc Sampling frequency No of quantization bits Frequency Number of channels S/N Ratio RADIO SECTION Frequency Range Intermediate Frequency Usable Sensitivity Stereo Separation S/N Ratio AM/MW Frequency Range Intermediate Frequency Usable Sensitivity S/N Ratio GENERAL Power Supply Polarity Speaker impedance...

  • Page 15: Troubleshooting

    13.TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power The car ignition is not on. The fuse is blown. Disc cannot be loaded Presence of CD disc inside or ejected...
