Slush & Smoothie Machine
User
s Manual
'
ST 12 x 2 , ST 12 x 3 , MI 7.5 x 2
The product has been designed for indoor use only.
So do not use it outdoors.
Before use of the product, be sure to become familiar with this manual.
Keep the manual in a convenient place for quick and easy reference.
This manual contains the product warranty card.
The product design is subject to change for performance enhancement
without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST 12x2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blue Ice ST 12x2

  • Page 1 Slush & Smoothie Machine User s Manual ST 12 x 2 , ST 12 x 3 , MI 7.5 x 2 The product has been designed for indoor use only. So do not use it outdoors. Before use of the product, be sure to become familiar with this manual. Keep the manual in a convenient place for quick and easy reference.
  • Page 2: Table Of Contents

    Contents 1.Names of Parts 2.Overview 3.Safety Signs, Symbols, and Labels 4.Safety Instructions 5.Installation Requirements 6.Safety Cautions for Operation 7.Operation Procedure 1 ~1 7.1 Controllers 7.2 Operations 7.3 Cleaning and sterilization procedure 7.3.1 Disassembling the product 7.3.2 Cleaning the product 7.3.3 Sterilizing the product 7.3.4 Assembling the product 7.3.5 Sterilizing the site 8.Daily Check...
  • Page 3: Names Of Parts

    1. Names of Parts : MI7.5X2 MODEL : SSM-52...
  • Page 4 : ST12X2 MODEL : SSM-280...
  • Page 5 : ST12X3 MODEL : SSM-420...
  • Page 6: Overview

    2.Overview To become familiar with this product, be sure to read this manual carefully. This product requires cleaning and maintenance activities as in other machines. Any disassembly or cleaning mistakes may cause a product failure. It is highly recommended for the person in charge to have immersion training for activities. 3.Safety Signs, Symbols, and Labels The warnings and safety instructions in this manual do not cover all possible conditions and situations.
  • Page 7: Safety Instructions

    4.Safety Instructions Be sure to use the grounded Do not pull off the power consent. plug. It may cause a failure or It may cause a failure or electric shock. electric shock. Do not move the product Do not contact the power by pulling the power plug.
  • Page 8: Installation Requirements

    5. Installation Requirements Do not install the product Do not install the product near the heat generating in a humid, dusty, or water source. (e.g. rain) splashing place. It may cause a fire. It may cause an electric shock or fire. Do not install the product near When moving the product, combustible gases...
  • Page 9: Safety Cautions For Operation

    6.Safety Cautions for Operation Keep away any flammable If the product makes heavy noise or materials. does not operate properly, remove the power plug and contact the service It may cause a fire or explosion agency. due to electric spark. It may cause an electric shock or fire.
  • Page 10: Operation Procedure 1 ~1

    7.Operation Procedure Clean and sterilize the product according to the instructions in this manual. See 7.3 Cleaning and sterilization procedure. Fill up the liquid material up to the level specified on the canister. Do not overfill it. The optimal quantity (in liter or gallon) is written on the surface of canister. When diluting the liquid material, fill water into the canister first and pour the liquid material for dilution.
  • Page 11: Controllers

    7.1 Controllers The product is equipped with the power switch. Canisters operate by each individual switch. You can use both soft (refrigeration) drinks and granita (smoothie, slush). In the refrigeration mode, the temperature of the drink is controlled by the thermostat. In the freezing mode, the viscosity of the mixed material is controlled by the bolt on the rear of the product.
  • Page 12: Operations

    7.2 Operations Adjusting the granita viscosity: The optimal granita viscosity is set by the manufacturer. To change the viscosity, rotate the control bolt on the rear of the product as follows: (See Figure 4.) - To make thicker granita, rotate the control bolt to the right (clockwise). - To make watery granita, rotate the control bolt to the left (counter-clockwise).
  • Page 13: Cleaning And Sterilization Procedure

    Before operating the product again, check whether lumps of ice have been formed. If any lumps of ice are in the canister, remove them before switching on the product. If you operate the product in refrigeration mode during all night, it can prevent accumulation of the condensed ice When the granita is in the canister, do not turn off the slush supply switch.
  • Page 14 Lift the front of the canister to unlock the latch (Figure 5) and pull out the canister to the front. (See Figure 6) Remove the spiral by pulling out (Figure 7) and remove the packing cushion. (See Figure 8) Remove the rubber cushion. (See Figure 9).
  • Page 15: Cleaning The Product

    7.3.2 Cleaning the product Never clean the parts in the dish washer. Warning Prepare the solution mixed with five liters of warm water and kitchen detergent. Do not use a strong detergent. After inserting the mixed solution that does not harm the food, turn on the slush supply switch to extract the solution.
  • Page 16: Sterilizing The Product

    7.3.3 Sterilizing the product Sterilization is performed before operating the product. After sterilization, do not leave the product for a long time. Wash your hands with an anti-bacterial soap. According to the food safety regulations and manufacturer specifications, prepare five liters of warm (45 to 60 ) sterilization solution (dilute a spoon of chloride condense liquefaction or sodium chlorate with two liters of water (100 ppm)).
  • Page 17: Sterilizing The Site

    Push the canister fully into the canister to fix in the packing cushion and fixing latch. (See Figure 14). Use fresh material to remove the remaining sterilization solution on the surface of the canister. Afterwards, do not rinse the product. To reuse the product after a long time, paint the packing cushion with edible grease as in .
  • Page 18: Daily Check

    8. Daily Check If the power cord is damaged, only the qualified person must replace it to prevent electric shock. Warning Daily check: It checks any possible leak through the packing or gasket. If leak happens through the packing or gasket even though properly assembled, check the use of improper grease or parts wear.
  • Page 19: Specifications

    9. Specifications ST12 x 2 ST12x3 MI7.5x2 SIZE (WxDxH) 400×480×895 600×480×895 417×386×705 BODY Case 220V 1020 1350 5.0A 6.4A 3.5A 16W~34W 10 ×2TANK 10 ×3TANK 5 ×2TANK The raw material quantity may vary by the material type and sugar content. If the slush touches the cover, reduce the quantity of the raw material.
  • Page 20: Circuit Diagram 2 ~2

    10. Circuit Diagram MI7.5X2 SSM-52 CIRCUIT DIAGRAM SI12X2 CIRCUIT DIAGRAM...
  • Page 21 SI12X3 CIRCUIT DIAGRAM...
  • Page 22: Before Calling Service

    11. Before Calling Service Failure Cause Action 1. Power is not supplied from 1. Check the outlet connection the outlet. status. 2. The power switch is turned If power is not supplied 2. Turn on the power switch. off. 3. The fuse is disconnected. 3.
  • Page 23 MI7.5X2: OUT CASE ASSEMBLY...
  • Page 24 ST12X2, ST12X3: IN CASE ASSEMBLY SSM-280, 420 IN CASE ASSEMBLY...
  • Page 25 ST12X2, ST12X3: OUT CASE ASSEMBLY SSM-280, 420 OUT CASE ASSEMBLY...
  • Page 26 CANISTER ASSEMBLY ITEM ITEM ITEM Canister Cover Moter cover Packing Redenar One Canister Geared Motor Pin Lever Spiral Micro switch Packing Down Packing back ASS'Y Drum O-ring down Dasher Shaft Base Canister Lever Shaft Tension Bolt Packing Cushion Lever Spring Slush Joint Spring Redenar Lever Label...
  • Page 27 13. When Receiving Service 1. A product failure has occurred while operation. 2. First turn off the power switch and remove the power plug. 3. Contact the service agency. 4. The service engineer visits and performs service upon call. 5. The repair is finished! ! 6.
  • Page 28 5. For repair, provide the product warranty card to the service engineer. 6. This product warranty card is applied in the local area. 7. This card is not reissued so please keep it in a safe place. Contact Details : BLUE ICE MACHINES LIMITED TEL: 0208442 4001 Website: www.blueicecreammachine.co.kr email: info@blueicecreammachine.co.kr...
