Summary of Contents for Apevia ATX-LCD750W
-
Page 3: Product Specifications
The power supply should be operated in an ambient temperature up to 40 2.3 Model name of standard ATX types: ATX-LCD650W ATX-LCD750W 2.4 DC Output: The max. DC output voltage of +5vsb is 2.0A and accord with ATX 2.0 all versions design guide... - Page 4 (Amps) +5VSB (Amps) +3.3V & +5V Combines Load :320W +3.3V , +5V & 12V Combines Load :630W Total Peak output Power:650W DC Output Current Range of ATX-LCD750W Power distribution for configuration DC O/P Load +3.3V (Amps) +5 V (Amps) +12 V1 (Amps)
- Page 5 2.5 Description of Connectors: DC OUTPUT WIRES...
- Page 6 ATX Main Power Connectors 24Pins ( 20+4 Pins ) : PA Color Single +3.3V Orange Orange +3.3V Black +5VDC Black +5VDC Black Black SENSE PWR_OK Gray +5VSB Purple +12V1DC Yellow Yellow +12V1DC Orange +3.3VDC Serial ATA Connectors : PB/PC/PD/PE Color Single Yellow +12V1DC...
- Page 7 ATX Power Supply ( PCI Express ) : PF/PG Color Black Black Black Yellow +12V2DC Yellow +12V2DC Yellow +12V2DC EPS +12V Connectors 8Pins ( 4+4 Pins ) : PH Color Yellow +12V2DC Yellow +12V2DC Yellow +12V2DC Yellow +12V2DC Black Black Black Black Single...
- Page 8 Peripheral Connectors : PJ/PK/PL/PM/PO/PP/PQ/PR Color Single Yellow +12V1DC Black Black +5VDC Floppy Connectors : PN/PS Color Single +5VDC Black Black Yellow +12V1DC Fan Speed Adjustable Knob: User-adjustable fan speed controller optimizing balance between noise reduction and necessary cooling Output Voltage Adjustable Safety Range: 5V : 4.8V~5.15V 12V : 11.8V~12.4V 3.3V : 3.2V~3.4V...
- Page 9 Output voltage can be adjusted within the safety range to meet special applications.Output voltage must be adjusted by a tiny screw driver enclosed in the package. To adjust the output voltage, insert the enclosed screw driver to the selected voltage hole and turn right to increase the voltage and left to decrease the voltage.
