F.Bertazzoni PM36500X Instructions For The Installation, Maintenance And Use

Fixed hobs with gas or mixed supply
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

(GB)
INSTRUCTIONS FOR THE INSTALLATION, MAINTENANCE
pag. 2
AND USE OF FIXED HOBS WITH GAS OR MIXED SUPPLY
(FR)
INSTRUCTIONS POUR L'INSTALLATION, L'ENTRETIEN ET
page. 9
L'UTILISATION DES TABLES DE CUISSON ENCASTRABLES
GAZ ET MIXTES
DIMENSIONS:
Models PM36500X
Models PM365S0X
DIMENSION:
Modeles PM36500X
Modeles PM365S0X
(W) x
(890 mm)
Type 'A'
Type 'B'
(W) x
(890 mm)
(520 mm)
Type 'A'
Type 'B'
(D)
(520 mm)
(D)
310543

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM36500X and is the answer not in the manual?

Questions and answers

Summary of Contents for F.Bertazzoni PM36500X

  • Page 1 INSTRUCTIONS FOR THE INSTALLATION, MAINTENANCE pag. 2 AND USE OF FIXED HOBS WITH GAS OR MIXED SUPPLY DIMENSIONS: (W) x (890 mm) (520 mm) Models PM36500X Type ‘A’ Models PM365S0X Type ‘B’ (FR) INSTRUCTIONS POUR L'INSTALLATION, L'ENTRETIEN ET page. 9...
  • Page 2: What To Do If You Smell Gas

    IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR’S USE. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. OBSERVE ALL GOVERNING CODES AND ORDINANCES. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquid in the vicinity of this or any other appliance.
  • Page 3 Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the top of the highest burner of the cooking appliance and the range hood be less than 650mm. Any other downward facing combustible surface less than 600mm above the top of the highest burner shall be protected for the full width and depth of the cooking surface area.
  • Page 4: Connecting The Appliance To The Gas Supply

    VENTILATION OF THE PREMISES To guarantee that the appliance works correctly it is necessary that the place where the appliance is installed is continuously ventilated. The volume of the premises must not be less than 25 m³ and the quantity of air needed must be based on the regular combustion of gas and on the ventilation of the premises.
  • Page 5 Wiring diagrams Wiring diagram description For hotplate see Fig. 13. 1. Cable terminal L. Black 2. Ignition switch N. White 3. Spark generator T. Green (earth) 4. Ignition spark MAINTENANCE OF THE MACHINE CHANGING THE PARTS Before carrying out any maintenance work, disconnect the appliance from the gas and electric supply.
  • Page 6: Service & Maintenance Instructions

    Regulation of burners Regulation of the "MINIMUM" on the burners To regulate the minimum on the burners carry out the following procedure indicated below: 1) Turn on the burner and put the knob onto position MINIMUM ( small flame ). 2) Remove the knob ( Fig.
  • Page 7: Using Burners

    Using burners A diagram is etched on the control panel above each knob which indicates which burner corresponds to that knob. Manual ignition: Manual ignition is always possible even when the power is cut off or in the event of prolonged power failure. Turn the knob that corresponds to the burner selected counterclockwise to the MAXIMUM position at the etched star (large flame) and place a lit match up to the burner.
  • Page 8 Cleaning the stainless steel parts: Clean the parts with soapy water and dry them with a soft cloth. The shine is maintained by periodically using suitable products which can be found in the supermarket. Never use abrasive powders. Cleaning the burner caps: Lift the burner caps from the burner heads and wash them in soapy water and dry thoroughly.
  • Page 9: Fixation De La Table De Cuisson

    Installation, Service et Instructions pour l’Utilisateur Insertion de la table de cuisson Après avoir enlevé les différentes parties libres à l’intérieur et à l’extérieur de l’emballage, assurez-vous que la table de cuisson ne soit pas endommagée et qu’elle soit appropriée pour l’utilisation du gaz spécifique. L’étiquette du type de gaz se trouve en dessous de la base de la table de cuisson.
  • Page 10 OBSERVACIONES IMPORTANTES PARA LA INSTALACIÓN DEL APARATO Se informa al instalador que este plano de cocción es tipo Y por lo cual puede ser instalado libremente, de manera aislado, o bien inserto entre los muebles de cocina o entre un mueble y las paredes de ladrillos.
  • Page 11: Schémas De Câblage

    Si le branchement se fait directement sur le secteur : - Interposez entre la table et le secteur un interrupteur unipolaire, proportionné à la charge de la table avec une ouverture minimale entre les contacts de 3 mm. - Rappelez-vous que le câble de terre ne doit pas être interrompu par l'interrupteur. - En alternative, le branchement électrique peut aussi être protégé...
  • Page 12 Soulevez les brûleurs et dévissez les becs ( Fig. 9) en employant une clé réglable de 7 mm et changez les becs avec ceux conçus pour la nouvelle alimentation de gaz, selon les informations fournies dans le TABLEAU A ci-dessous. TABLEAU N°2: Adaptation aux différents types de gaz.
  • Page 13: Instructions Pour L'utilisateur

    Avertissement: si les valves doivent être remplacées, désassemblez d’abord les câbles des interrupteurs d’allumage. Il est recommandé de remplacer les joints de la valve chaque fois que la valve est remplacée, assurant, de cette façon, l’étanchéité parfaite entre le corps et le train de gaz. ATTENTION: Débranchez l’alimentation avant l’entretien de l’unité.
  • Page 14: Nettoyage De L'appareil

    - Utilisez toujours des casseroles avec un couvercle. Tableau B Brûleur Diamètres recommandés pour les casseroles (mm) Moyen 140 – 260 Large 180 – 260 Dual (poêle chinoise) 220 – 260 Utilisation correcte des casseroles: - Essuyez le fond de la casserole avant de la positionner sur la plaque de cuisson. - Utilisez les pots avec un fond plat et épais, à...
  • Page 15 Fig 1 Fig 2 Fig.3 Fig. 3A Fig. 3B Fig.4 Fig.5A Fig.5B...
  • Page 16 Fig.6 Fig.7 Fig.8 Fig.9 Fig.10 Fig.11 Fig.12 Fig.13 Fig.14...
