30-900-00015 Issued 2002-11-28

Multimedia Service Manual

for the Control Module used on the Renault Rear

Seat Entertainment System

Control Module

Part Number 4035241

About this Document

Document no.

Produced by:

Download from:

Issue

2002-11-28

Printed Copies are Uncontrolled.

CONFIDENTIAL

http:/euro.evisteon.com

30-900-00015

Visteon Technical Service

Operations

http://euro.evisteon.com

Remarks

First Issue

Table of Contents

Need help?

Do you have a question about the 4035241 and is the answer not in the manual?

Questions and answers

Summary of Contents for VISTEON 4035241

Page 1 Control Module used on the Renault Rear Seat Entertainment System Control Module Control Module Control Module Control Module Part Number 4035241 Part Number 4035241 Part Number 4035241 Part Number 4035241 About this Document About this Document About this Document About this Document Document no.
Page 2 Turn off the ignition switch After 5 min the power switches off. Auto-off feature Unplug the control module. 4. If the unit is faulty proceed to the next step. 30-900-00015 Issued 2002-11-28 Page 2 of 19 © Copyright Visteon 2002...
Page 3 2. Remove screws 5 to 8. and separate the PCB from the control box base. 3. Visually inspect the components for obvious signs of mechanical or electrical damage. 4. Proceed to section C. 30-900-00015 Issued 2002-11-28 Page 3 of 19 © Copyright Visteon 2002...
Page 4: Diagnosis And Repair
Check 5 V IC 16 Pin If OK go to next line TR6 defect, IC16. Replace defective components. Check for PCB damaged pins . Replace defective components. 30-900-00015 Issued 2002-11-28 Page 4 of 19 © Copyright Visteon 2002...
Page 5 44, 53 O/C. Replace defective components. Check Waveform If OK go to next line Recheck Fault symptoms IC10 7, 8 Check test looms Check Reg supplies 5/9/12/Gnd. Replace defective components. 30-900-00015 Issued 2002-11-28 Page 5 of 19 © Copyright Visteon 2002...
Page 6 RV15 partial short No video picture, on C80 s/c to gnd. No IIC clock signal to either screen, DVD IC9 pin 7 failed, open LCD screens controls working R31 open, dry-jointed 30-900-00015 Issued 2002-11-28 Page 6 of 19 © Copyright Visteon 2002...
Page 7 Failure of any right-side or dry joint audio input circuit IC19 failed or not receiving 9 V supply associated with CN3 IC1 partially defective Dry joint on IC1 pin 43 or 52 30-900-00015 Issued 2002-11-28 Page 7 of 19 © Copyright Visteon 2002...
Page 8 4. Complete repairs to the control module. Ensure that the repaired items are clean. 5. Reassemble the control module by performing the dismantling procedure described above in reverse. 6. Retest the module as described in section A-3 30-900-00015 Issued 2002-11-28 Page 8 of 19 © Copyright Visteon 2002...
Page 11: Functional Diagram
C controlled AV Switch matrix). Audio signals are routed through this device to the relevant audio processors IC2/5 and then on to the Headphone amplifiers IC3/4 Video signals from IC1 are buffered by IC10 and supplied to the relevant LCD module. 30-900-00015 Issued 2002-11-28 Page 11 of 19 © Copyright Visteon 2002...
Page 12 Audio Amp Processor R2 HP L2 HP IC4-Screen 2 IC5-Audio Audio Amp Processor Router Signal Block Diagram Router Signal Block Diagram Router Signal Block Diagram Router Signal Block Diagram 30-900-00015 Issued 2002-11-28 Page 12 of 19 © Copyright Visteon 2002...
Page 13 Service Manual – Renault System Control Module pcb Top Control Module pcb Top Control Module pcb Top Control Module pcb Top 30-900-00015 Issued 2002-11-28 Page 13 of 19 © Copyright Visteon 2002...
Page 14 Top View of the Control Module pcb Detailing Circuit Reference Nos. Top View of the Control Module pcb Detailing Circuit Reference Nos. Top View of the Control Module pcb Detailing Circuit Reference Nos. 30-900-00015 Issued 2002-11-28 Page 14 of 19 © Copyright Visteon 2002...
Page 15 Service Manual – Renault System Control Module pcb Bottom Control Module pcb Bottom Control Module pcb Bottom Control Module pcb Bottom 30-900-00015 Issued 2002-11-28 Page 15 of 19 © Copyright Visteon 2002...
Page 16 Bottom View of the Control Module PCB Detailing Circuit Reference Nos. Bottom View of the Control Module PCB Detailing Circuit Reference Nos. Bottom View of the Control Module PCB Detailing Circuit Reference Nos. 30-900-00015 Issued 2002-11-28 Page 16 of 19 © Copyright Visteon 2002...
Page 17: Connector Details
Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Power ground 30-900-00015 Issued 2002-11-28 Page 17 of 19 © Copyright Visteon 2002...
Page 18 5 V IR supply out CN 15-5 Section LCD Power +12 V CN 15-6 Video Out CN 15-7 LCD Video gnd CN 15-8 Backlight Ground CN 15-9 Backlight +12 V CN 15-10 30-900-00015 Issued 2002-11-28 Page 18 of 19 © Copyright Visteon 2002...
Page 19 TO JVC VCR OR NECVOX DVD TO (TBE) DVD TO AUXILLIARY PANEL VOLVO_AUDIO_SEL_DRIVE VFILTER INPUTS INPUTS INPUTS +9VA OUTPUTS +5V_ACC OUTPUTS OUTPUTS INPUTS +9VA TO LEFT LCD INTERFACE BOARD TO RIGHT LCD INTERFACE BOARD POWERVIEW...
Page 20 POWERVIEW...
Page 21 POWERVIEW...
Page 22 2A max POWERVIEW...
Page 23 POWERVIEW...
Page 24 POWERVIEW...
Page 25 POWERVIEW...
