- Page 1 HAL-HPC301 Handheld Particle Counter Operational Manual 7970 Cherry Ave., Suite 303 Rancho Cucamonga, CA 91730 USA Phone: (866) 438-4258 Fax: (855) 402-9190 Info@haltechnologies.com http://haltechnologies.com Page 1 of 33 V1.1...
- Page 2 This page intentionally left blank Page 2 of 33 V1.1...
-
Page 3: Table Of Contents
Table of Contents Version Table ................. 4 Disclaimer ..................5 1. Introduction ................8 1.1 Features ......................10 1.2 Specifications ....................10 2. Basic Operation ............... 12 2.1 Handheld Unit Overview ................12 2.2 Key Functions ....................12 2.3 Graphical User Interface (GUI) ..............13 2.3.1 Main Screen .................... -
Page 4: Version Table
Version Table Date Version Comment February 10, 2017 Added Data Downloader instructions December 20, 2016 1.0 Formal Release April 15, 2015 Pre-release updating April 7, 2015 Pre-release Version Page 4 of 33 V1.1... -
Page 5: Disclaimer
Disclaimer The information in this manual is believed to be accurate, however, Hal Technology assumes no responsibility for any inaccuracies that may be contained in this manual. Under no circumstances will Hal Technology be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 6 Noting items of interest or instrument features and/or requirements. Unpacking and Inspection • Inspect the receiving package and notify the shipper immediately if there appears to be susceptible damage during shipping. • Please verify that the enclosed items coincide with the shipping package list. This Instrument is designed to be the class-1 laser equipment.
- Page 7 Please contact Hal Technology to schedule your calibration or any services needed. The HAL-HPC301 can only be serviced at Hal Technology or by a Hal Technology authorized professional. Page 7 of 33 V1.1...
-
Page 8: Introduction
A sampling flow is directed through a proprietary chamber designed to collect scattered light and generate electrical pulses proportional to the size of the incident particles. The HAL-HPC301 is a completely self-contained particle counter, that is, no other parts are required to start monitoring or making particle count measurements. A plethora of optional accessories are available to increase measurement confidence and accuracy. - Page 9 The HAL-HPC301 has three adjustable particle size channels starting at 0.3 microns at a flow of .1 CFM (2.83 LPM). Particle count data is displayed as Cumulative, Differential or Concentration mode (Counts/Liter or Counts/Cubic foot, Counts/Cubic Meter). Options are available to include Mass Concentration and Particulate Matter measurements.
-
Page 10: Features
1.1 Features • User settable channel sizes (0.3 μm, 0.5 μm, 0.7 μm, 1.0 μm, 2.0 μm, 2.5 μm, 5 μm, 10 μm, and 15 μm) • User adjustable start delay, sampling time, and sampling interval • USB interface for data downloading (Software included) •... - Page 11 • Count Limit Warning: FED STD 209E (Class 1 to 100,000), ISO 14644-1 (Class 3 to 9), and user defined (custom). • Measurement Mode: Cumulative, Differential, Number Concentration, Mass Concentration and PM values • Save Option: Single, Multiple or Average •...
-
Page 12: Basic Operation
2. Basic Operation 2.1 Handheld Unit Overview Figure 2: Overview of the HPC301 2.2 Key Functions The units interface is composed of a six key interface: ENTER BACK Each button controls the following features: • Power button : While the unit is off, press and hold the power button for approximately 2 seconds to turn on the instrument. -
Page 13: Graphical User Interface (Gui)
the instrument is not actively sampling it will automatically power off after 5 minutes of inactivity. • : Start or stop measuring/sampling. • : Move the cursor to select desired screen or item. • ENTER: Confirm the current selection or edit a parameter. •... -
Page 14: Measure Screen
Figure 3: HPC301 Main Screen 2.3.2 Measure Screen The Measure screen, shown in Figure 4, will show the channel values and the optional temperature, relative humidity, and pressure values if the PHT probe is attached to the unit. From this screen one can navigate to the Settings Screen by pressing the UP key, the Browse Screen by pressing the DOWN key, or start taking data by pressing the RUN/STOP key The Measure Screen also shows the status of the Sound, Alarm, Bluetooth, and Printing settings as well as the battery charge state. - Page 15 Figure 4: Measure Screen of the HPC301 • Push the RUN/STOP key to begin a measurement. During the sampling process, you may cancel the measurement by hitting the RUN/STOP key again. • The Start Delay will count down to zero, at which point the unit will begin sampling. The unit will collect the number of samples requested at the appropriate Sample Duration and Sample Interval.
-
Page 16: Browse Screen
data for the Sample Duration and then counts through the Sample Interval. The Sample Duration and Sample Interval times will be repeated for the requested number of samples. Figure 5 specifically shows the sampling process when the unit is set to a non-zero Start Delay and 4 samples are taken. -
Page 17: Settings Screen
Figure 6: Browse Screen 2.3.4 Settings Screen Figure 7 shows the Settings Screen of the HPC301. From this screen one can navigate to the Browse Screen by pressing the UP key, the Measure Screen by pressing the DOWN key, or enter the settings screen by pressing the ENTER key. All the unit’s parameters are set using this screen. - Page 18 Figure 8 shows the parameters that can be set via the Setting Screen. Particle Sizes – Modify particle sizes on Channels 1 - 6 Sample Parameters – Modify Start Delay, Interval, Duration, Number of Samples, Material Density (MC and PM only), Count Mode, and Location SETTINGS Date &...
-
Page 19: Modifying Parameters (Settings)
2.3.5 Modifying Parameters (Settings) Particle Sizes Sample Parameters Date & Time Preferences Alarm/Sound Levels Print/Save Options Bluetooth Settings Factory Settings Particle Sizes: This three-channel particle counter allows the user to select three predefined channel sizes from 0.3 μm, 0.5 μm, 1.0 μm, 2.0 μm, 2.5 μm, 5.0 μm, 10.0 μm, and 15.0 μm. - Page 20 delay can be set between 00:00 and 59:59. Sample Interval The sample interval is defined as the time between measurements. No data is collected during the interval. The sample interval can be set between 00:00 and 59:59. Sample Duration The sample duration is defined as the time between measurements. No data is collected during the interval.
- Page 21 • Particulate Matter and Mass Concentration measurement capabilities are optional accessories for the HPC301. If your unit does not have this capability require contact Technology info@haltechnologies.com sales@haltechnologies.com for a quote. Count Mode All channels are counted as cumulative counts, and processed according to the Count Mode setting.
- Page 22 Preferences: The preferences page allows users to select the color theme of the HPC301. The available colors are Gray, Red, Green, and Blue. The preferences page also allows the user to select the displayed unit of temperature. The choices are °C (Celsius) and °F (Fahrenheit). Alarm/Sound Levels: The user has two options for preset alarm levels: FS209E and ISO standards.
- Page 23 Be sure that the printer is turned on before attempting the Connect test. Factory Settings: The firmware update option is reserved for future use by Hal Technology, and the Page 23 of 33 V1.1...
- Page 24 calibration option is password protected for safety reasons. If a calibration is required, contact services@haltechnologies.com. The Clear Last Record option is available in case the unit were to lose power while saving data. If this were to occur, it is possible the last record could be corrupted.
-
Page 25: Data Downloader Instructions
3. Data Downloader Instructions The HPC301 Data Downloader software installs on most recent Windows operating systems. To install the HPC301 Data Downloader software, please follow the instructions in the file named Readme.txt that is usually provided on the compact disc. After successful installation, it is preferable to have the HPC301 powered off when using the software to download data from the HPC301. -
Page 26: Troubleshooting
4. Troubleshooting If none of the suggested remedies work for your particular problem, contact services@haltechnologies.com for further assistance. Symptom Possible Remedy The unit will not turn on. 1. Hold the Power Button down until the unit turns on. 2. Plug the unit in using the supplied power adapter or charger, wait a few minutes, and try turning it on. - Page 27 Printer does not print. 1. Ensure the printer is in working order (turned on and has thermal paper). 2. Ensure Bluetooth is enabled on the HPC301. 3. Run a connection test from the Bluetooth Settings Page. Page 27 of 33 V1.1...
-
Page 28: Warranty
Abnormal operation due to required instrument calibration. Limitation of Warranty A. Hal Technology warrants that all equipment shall be free from defects in material and workmanship under normal use for a period of one year from the date of shipment to Buyer except that Hal Technology does not warrant that operation of the software will be completely uninterrupted or error free or that all program errors will be corrected. - Page 29 If the Instrument is modified or in any way altered without the explicit written consent of Hal Technology, then the warranty is null and void. This warranty is limited to a period of one year, except as noted below, without regard to whether any claimed defects were discoverable or latent on the date of shipment.
-
Page 30: Contact Information
Hal Technology authorized employee. Buyer pays shipping costs to factory; seller will pay standard return shipping costs during the warranty period. Buyers may select a faster method of shipment at their own expense. - Page 31 Please fill out the Registration form below and send to: HAL TECHNOLOGY, LLC 7970 Cherry Avenue, Suite 303 Rancho Cucamonga, CA 92336 USA Fax: (855) 402-9190 (toll-free) Or send relevant registration information to the email address below: services@haltechnologies.com User Registration Form...
-
Page 32: Glossary
6. Glossary Counts per Cubic Foot – The number of counts in a sample volume (cubic feet). This is calculated using the parameters of the unit and the flow conditions. Counts per Cubic Meter - The number of counts in a sample volume (cubic meter). This is calculated using the parameters of the unit and the flow conditions. - Page 33 Wait Sample Wait Sample Wait Sample Wait Sample Time Passing Page 33 of 33 V1.1...
