Power Input Connectors; Controls And Settings; Power Output Connectors; Important: Always Use The 'Hibernate' Feature - mini-box M1-ATX Installation Manual

http://mini-box.com, Cool Embedded PCs

Power Input Connectors

J11 Battery + (un-switched battery, positive)
J12 Ignition (switched battery, positive. Can test by connecting it to Battery +)
J13 Battery - (negative)

Controls and Settings

J2 Controls amplifier via remote ON/OFF. Left pin is RMT, Right pin is GND
J6 To motherboard ON/OFF switch
J7 User jumper settings (A,B,C,D)
J8 To external ON/OFF switch (optional, J8 is in parallel with J6)

Power Output Connectors

J3 Optional HDD power (not shown in this picture)
J5 ATX power connector (to motherboard)
J4 To LED (optional)
Jumper attached=ON
A B C D
P
OFF OFF OFF OFF
P0
ON OFF OFF OFF
P1
OFF ON OFF OFF
P2
ON ON OFF OFF
P3
OFF OFF ON OFF
P4
ON OFF ON OFF
P5
OFF ON ON OFF
P6
ON ON ON OFF
P7
OFF OFF OFF ON
P8
ON OFF OFF ON
P9
OFF ON OFF ON
P10
P0: In this mode, the M1-ATX behaves like a regular ATX power supply. If J6 is connected to the motherboard, M1-
ATX will also send a gratuitous "ON pulse" to the motherboard right after power is first applied.
If IGNITION is connected to the battery, the unit will shut down if battery is < 11.2V. This is to protect the battery
from over- discharging. If Ignition is not hooked up, M1-ATX will operate from as low as 6V. For more information,
please consult the "UPS mode" documentation on the product page.
P1 (recommended): Sends ON pulse to motherboard when ignition is ON for more than 5 seconds, sends OFF
pulse to motherboard 5 seconds after ignition is turned off. Waits another 60 seconds and then shuts down 5VSB to
conserve battery. In this mode, the M1-ATX consumes less than 0.5mA. This is our recommended setting.
1.2 Power challenges in a Vehicle PC
The 5V Standby Problem: One of most difficult tasks of operating a PC in a vehicle is power consumption while the
computer is OFF. Even when your computer is OFF or in Suspend, it will still consume about 50-150mA on the 5VSB rail.
No matter how big your battery is, you will eventually drain it if proper actions are not taken.
The M1-ATX is addressing these issues by cutting off the 5VSB rail after a pre-defined amount of time (see jumper chart,
HARDOFF). When 5VSB is always active (HARDOFF=Never), M1-ATX constantly monitors the battery levels. When
battery level drops below 11V for more than one minute, M1-ATX will shut down and re-activate only when the input
voltage is > 12V.
Engine Cranks, under-voltage and over-voltage situations. Another difficult task is maintaining stable 3.3V, 5V, 12V
and -12V power to your PC. While car batteries are rated at 12V, they actually provide voltages in between 7-16V (engine
cranks) or as high as 80 volts (load dump). Most of the times, your battery will stay at 13.5V (while car is running) but
extra precautions need to take place in order to prevent such situations. M1-ATX can operate as low as 6V and as high
as 28V while providing strict regulation on all rails along with input voltage clamping and reverse protection.
Loud amplifier pops when PC starts. If your PC is connected to your car amplifier, you will hear a loud pop when the
computer is first started. The M1-ATX has an 'anti-thump' control that will keep your amp OFF while the PC starts. Simply
connect J6 to your amplifier remote control pins to activate the 'anti-thump' feature.
M1-ATX User Guide
Off-delay Hard-off
(All rails ON) (5VSB)
Standard PSU mode
5s + 1min AutoLatch* 1 min
5s+ 1min AutoLatch* 2 hour
5s+ 1min AutoLatch* NEVER
30s + 1min AutoLatch* 2 hour
30s + 1min AutoLatch* NEVER
30min NEVER
3 hour NEVER
10 min 1 hour
15 min 2 hours
1 hour 75min
Page 2
IMPORTANT: Always use the "Hibernate" feature, never use
"Standby" as it can severely discharge your battery over
extended periods of time.
NEVER use "Hard-off = NEVER" settings unless you
understand the risks of battery depletion. "Hard-off=NEVER
always keeps 5VSB rail ON!
*AutoLatch is active during the fist 60s of PC operation (and
only during the first 60 seconds). For example, If Ignition is
turned ON and then OFF right away, M1-ATX will latch Ignition
in ON position for the next 60 seconds, allowing your operating
system to fully come up. This will prevent disk drive corruption
or systems that remain hung in the ON position. After the first
60 seconds of system operation, the AutoLatch feature will be
removed and system will shut down at as governed by the
"Off-delay" setting.
