  • Page 1 Media Player THD003 User Manual Movie Photo Music...

  • Page 2: Table Of Contents

    Content I. Main Features ....................... 1 1.1.Applications ....................... 1 1.2.Display format ....................1 1.3. Supported Languages .................. 3 II. Remote control ....................4 III.SETUP MENU ...................... 7 IV. Interface port ..................... 9 V. Operation Manual ................... 12 5.1 Boot auto-play ....................12 5.2 Custom control display ...................

  • Page 3: Main Features

    THD003 is a high performance 1080p Full HD media player. I. Main Features 1.1 Applications  Ideal replacement for Blue Ray and DVD video players.  Ideal playback unit for Large LCD and Plasma display.  High Definition Information Display for Resorts, Hotels, Restaurants, Shopping Malls, Airports, etc.
  • Page 4 1.2.4 Supported subtitles format: SRT, SMI, SUB, SSA, IDX+SUB 1.2.5 Supported video code: MPEG1/2/4, H.264, AVC, VC1, WMV, RM/RMVB, DivX3/4/5/6, Xvid3/4/5/6 1.2.6 Supported video files: RM/RMVB, AVI, TS, M2TS, MTS, MKV, MOV, FLV, DVD-ISO, BD-ISO, MPG, DAT, ASF, TP, TRP, WMV, IFO, SWF, 3GP, EVO, DIVX, MP4, OGM 1.2.7 Video Format: A.

  • Page 5: Supported Languages

    The player supports movie files that have been created using Flip Video hand held HD recorder. Files created are mpeg4 HD, xxx.mp4. Digital camera movie file (xxx.mp4,xxx.avi): The THD003 supports movie files xxx.mp4,xxx.avi, xxx.mov that have been created using regular Digital cameras (with movie recording capability). G. DVD and Mpeg2 video: The player supports standard DVD file xxx.vob and also regular Mpeg2 file.

  • Page 6: Remote Control

    II. Remote control All procedures in this manual can be carried out using the remote control buttons. See the following for details on each button and its function: Name Function Power button: Power Press to POWER on or off the device Title button: Title Press to view the title of DVD...
  • Page 7 Press REPEAT 1 / ALL to set repeat option - Chapter, Title or Off. Time seek button; Time seek Press to jump to a specific point on the disc or title. Specify the point using Title, Chapter and Time. TV Mode button; Press to switch between NTSC Interlaced, NTSC Progressive, TV Mode PAL Interlaced, and PAL Progressive.
  • Page 8 Vol + button: Vol+ Press to increase the volume. Audio button: Audio Press to select an audio track on a HDD or USB file. Subtitle button: Press to activate available subtitles when play the DIVX file. Subtitle DivX subtitle supported: SRT,SMI,SUB,SSA format file Resume button;...

  • Page 9: Iii.setup Menu

    III. SETUP MENU...

  • Page 11: Interface Port

    IV.Interface port 4.1 THD003 ports：...
  • Page 13 4.2 THD003 ports：...

  • Page 14: Operation Manual

    V. Operation Manual 5.1 Boot auto-play The media player will auto-play all the files in root directory of USB/SD CARD. But files that stored in the folder can’t be auto-played. The display files can be: video files, picture files, and audio files. Play sequence: video→picture→audio.

  • Page 15: Pictures Sync Playback（Bgm

    5.3 Pictures Sync playback (BGM) For pictures’ playback, you can define a background music folder. Here are two ways. 5.3.1 The first way: Music folder stored in the root directory, it will boot auto-play. In this case, background music will play once playing pictures. First, create a folder named “audio”...

  • Page 16: Custom Function

    Add below programme at the beginning of the configuration file “autoplay.txt”: Transition=9 (Setting the transition model from one picture to another, parameter range 1-9) Slide time=5 (Setting the playing time of each picture) B. Custom volume level Define at the beginning of “autoplay.txt”, as below: Volume=10 (Here “10”...

  • Page 17: Other Functions' Operation Manual

    5.5 Other functions’ operation manual ( only specific models have these functions) 5.5.1 RS232 control display A. The THD003 provides a DB9 female port for communication with control PC and program download. The pins are defined as below: Interface RS232(9 pins)
  • Page 18 C. Instruction of RS232 commands a. Examples of command format: @00:VOL+$ Represents: Volume up @00:NEXT$ Represents: Next file @01:PREV$ Represents: Previous file (this command can only be accepted by media player that set the address as “01”, all other media players will not act on this command).
  • Page 19 player can act on this command. There is only one broadcast address “00”, and addresses range from 01 to 99 is user address. User address can be defined in the “autoplay.txt”. For example, add “address=5” into “autoplay.txt”, then the address of media player is “5”.
  • Page 20 E. Commands List (take broadcast address “00” as example ) Command Description @00:OK$ Enter @00:UP$ Direction key, up @00:REV$ Playback @00:FWD$ Fast forward @00:REP$ Repeat play @00:MUTE$ No sound @00:VOL+$ Volume up @00:VOL-$ Volume down @00:STOP$ Stop and restart playback @00:PREV$ Previous file @00:NEXT$...
  • Page 21 F. Software Download a. Download link: https://docklight.de/downloads/ b. Choose “Docklight V2.2” to download the RS232 controlling software: c. Click “Docklight” on PC , the window shows:...
  • Page 22 Button : Clear Button : Send Button : Edit RS232 commands Take care of these settings:...
  • Page 23 d. Edit RS232 commands G. RS232 Return Message...
  • Page 24 a. Auto read the definitions in "autoplay.txt" when power on： volume=15 irmode=1 00[av:off][spdif:off][hdmi:off]=/ 01[hdmi:off][av:off][n]=01/ 02[av:off][spdif:off]=02/ 03[hdmi:off][spdif:off]=03/ 04=04/ 05[av:off]=05/ 06[n][vol:10]=06/ ( Here button 1 and folder 01 is defined "NO INTERRUPT" in configuration file“autoplay.txt”: “01[hdmi:off][av:off][n]=01/”)
  • Page 25 b. RS232 Return Message Format ① RS232 command format ② Remote control format ③ Push button control format c. Description Here take “RS232 command format” as an example: ① Send RS232 command “@00:01$”, start to play folder 01, the RS232 Return Message is as below: When folder 01 is displaying, send RS232 command “@00:01$”...

  • Page 26: Button Control Display

    H. Note “@0:WHO?”: This is a signal that stand-alone media player ask the synchronization console to confirm if this player is host machine or slave machine. If the player is host machine, it will synchronize other machine. And if it is slave machine, it will wait for the sync signal. You can turn off this finding by sending the string “@00:SLAVE$”.
  • Page 27 Description: (Define the default volume) volume=20 irmode=1（Button function definition）; 01=01/（“01” before “=” represents button number. “01” behind “=” represents the folder or file path (“/” must be added after folder name) vol_plus=03（Button 3:VOL+）; vol_minus=04（Button 4:VOL-）; NEXT=05 Button 5: play next file PREV=06 Button 6: play previous file C.
  • Page 28 volume=15 irmode=1 00[av:off][spdif:off][hdmi:off]=/ 01[hdmi:off][av:off][n]=01/ 02[av:off][spdif:off]=02/ 03[hdmi:off][spdif:off]=03/ 04=04/ 05[av:off]=05/ 06[n][vol:10]=06/ Instruction: Here "av" represents "audio output", "spdif" represents "optical and coaxial output","hdmi" represents "HDMI output" , "off" represents no sound output. 1. volume=15(Define the default volume) 2. irmode=1（Button function definition） 3. 06[n][vol:10]=06/ The "[n]"...

  • Page 29: Motion Sensor Display

    A. DISPLAY NEXT FILE---The player auto loop play root directory files when power on, it switches to the next file（files in folder 01） when the IR body sensor detects passer-by. When the file is finished, it switches to root directory files. B. Define configuration file in “autoplay.txt”: a. THD003 Sensor_mode=Nextfile 01=01/...
  • Page 30 THD003 Sensor_mode=Nextfile Sensor_file=01/ C. Store the displaying files in root directory as follows: a. Files stored in root will be displayed as homepage; b. Files in folder “01” will be displayed as next files when IR body sensor detects passer-by.

  • Page 31: Pin Definition Of Button Interface

    VI. Pin definition of button interface Pin definition of LED button interface: THD003...

  • Page 32: Setting Of Picture Playback

    VII. Setting of picture playback When picture is displaying on the screen, you can set picture playback by pressing button “MENU” on remote control, and then use direction key and button “OK” to carry on.
  • Page 33 Description: Picture Playback Slide Slide Repeat off Repeat all Shuffle Background Video Timing Transition Loop Music Setting Transition Off Brightness 2 Seconds All Effect Shuffle Default Contrast 5 Seconds Fliping Select Music Saturation 10 Seconds Quartet 30 Seconds Sliding Center Extend 2D/3D Expand Dissolve Fade In/Out...
