OWNER'S MANUAL
AIR CONDITIONER
Please read this manual carefully before operating
your set and retain it for future reference.
TYPE : WALL MOUNTED
MODELS
Indoor Unit
ASNQ093B1U0 (VA093CL
ASNQ123B1U0 (VA123CL
P/NO : MFL63288105
Outdoor Unit
)
ASUQ093B1U0 (VA093CL
NC0
)
ASUQ123B1U0 (VA123CL
NC0
)
UC0
)
UC0
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG ASNQ093B1U0
Summary of Contents for LG ASNQ093B1U0
- Page 1 OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : WALL MOUNTED MODELS Indoor Unit Outdoor Unit ASNQ093B1U0 (VA093CL ASUQ093B1U0 (VA093CL ASNQ123B1U0 (VA123CL ASUQ123B1U0 (VA123CL www.lg.com P/NO : MFL63288105...
-
Page 2: Table Of Contents
Air Conditioner Ownerʼs Manual TABLE OF CONTENTS FOR YOUR RECORDS A. Safety Precautions ......3 B. Electrical Safety........6 Write the model and serial numbers here: Temporary Use of an Adapter ....6 Model # Temporary Use of an Extension Cord ...6 Serial # Symbols used in this Manual....6 You can find them on a label on the side of each unit. -
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. ■ Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. - Page 4 Safety Precautions Indoor/outdoor wiring connections must Safely dispose off the packing materials. Make sure to check that the power cable be secured tightly and the cable should Like screws, nails, batteries, broken plug is not dirty, loose or broken and be routed properly so that there is no things etc after installation or svc and then only insert the plug completely.
- Page 5 Safety Precautions Do not use the product for special purposes, Do not block the inlet or outlet of air flow. Use a soft cloth to clean. Do not use such as preserving foods, works of art, etc. It harsh detergents, solvents or splashing is a consumer air conditioner, not a precision water etc .
-
Page 6: Electrical Safety
Electrical Safety Electrical Safety • This appliance must be properly grounded. To minimize the risk of electric shock, you must always plug into a grounded oulet. • Do not cut or remove the grounding prong from the power plug. • Attaching the adapter ground terminal to the wall receptacle cover screw does not ground the appliance unless the cover screw is metal and not insulated, and the wall receptacle is grounded through the house wiring. -
Page 7: Product Introduction
Product Introduction Product Introduction Here is a brief introduction of the indoor and outdoor units. Indoor Unit Plasma Filter Allergy Filter Triple Filter Front Panel ON/OFF Button Horizontal Sub Vane Horizontal Main Vane Air Outlet Vertical Louver Signal Receiver Operation Indication Lamps Cooling : Lights up during the system operation, error code indication. -
Page 8: Operating Instructions
Operating Instructions Operating Instructions How to insert the Batteries 1. Remove the battery cover by pulling it according to the arrow direction. 2. Insert new batteries making sure that the (+) and (-) of battery are installed correctly. 3. Reattach the cover by sliding it back into position. NOTE 1. -
Page 9: Wireless Remote Controller
Operating Instructions Wireless Remote Controller The controls will look like the following. Signal transmitter ON/OFF BUTTON Used to turn off/on the unit. OPERATION MODE SELECTION BUTTON Used to select the operation mode. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature. INDOOR FAN SPEED SELECTION BUTTON Used to select fan speed in six steps low, medium-low, medium, medium-high, high and natural wind. - Page 10 Operating Instructions The controls will look like the following. Signal transmitter TIME ADJUSTING BUTTONS Used to adjust the time. TIMER SET/CLEAR BUTTON(after adjusting) Used to set and to cancel the timer operation. RESET BUTTON Used prior to resetting time. LED LUMINOSITY BUTTON Used to adjust LED luminosity.
-
Page 11: Operation Mode
Operating Instructions Operation Mode ON/OFF Press the ON/OFF BUTTON to turn the unit on. The unit will respond with a beep. Open the cover of the remote controller and press the operation mode button. Each time MODE the button is pressed, the operation mode is shifted in the direction of the arrow. Auto Healthy Cooling... -
Page 12: Auto Operation
Operating Instructions Auto Operation <For Cooling Model> MODE The temperature and fan speed are automatically set by the electronic controls based on the actual room temperature. If you feel hot or cold, press TEMPERATURE SETTING buttons for more cooling or heating effect. You cannot switch the indoor fan speed. -
Page 13: Air Circulation Operation
During this operation, 'Cooling' lamp lights up. PLASMA Purification Operation Plasma filter is a technology developed by LG to get rid of microscopic contaminants in the intake air by generating a plasma of high charge electrons. This plasma kills and destroys the contaminants completely to provide clean and hygienic air. -
Page 14: Energy-Saving Cooling Mode
Operating Instructions Energy-Saving Cooling Mode Energy-saving cooling mode can save energy in cooling operation, because it can operate efficiently by setting body-adaptation time according to the change of time and temperature and adjusting desired temperature automatically. 1. Press the ON/OFF BUTTON to start the unit. 2. -
Page 15: Timer Setting
Operating Instructions Timer Setting Button on the Description Indication on the LCD Display Remote Controller Press the Timer button once to set on the Reserved 'On' (Press the Timer button twice to set the Reserved 'Off') Press the Time Setting buttons until the desired time is set. -
Page 16: Horizontal Vane Control
Operating Instructions Horizontal Vane Control The Horizontal Vane can be adjusted by using the remote controller. 1. Press the ON/OFF BUTTON to start the unit. 2. Press the vertical airflow direction button. Each time the button is pressed, the air-flow direction is changed in the direction of the arrow. -
Page 17: Jet Cool Operation
Operating Instructions Jet Cool Operation Jet cool function can be used to cool the room quickly in hot summer. When this function is turned on, the air conditioner runs in cooling operation mode with super high fan speed and 18°C setting temperature for 30 minutes for fast and effective cooling. -
Page 18: Forced Operation
Operating Instructions Forced operation Forced operation is used when the remote controller can't be used. The operation will be started if the ON/OFF button is pressed. If you want to stop the operation, re-press the button. ON/OFF Button Operating mode Cooling Indoor FAN Speed High... -
Page 19: Maintenance And Service
Maintenance and Service Maintenance and Service Before performing any maintenance, turn off the main power to the system, disconnect the circuit breaker and unplug the power cord. Indoor Unit Clean the unit with a soft dry cloth. Do not use bleach or abrasives. Never use any of these •... -
Page 20: Outdoor Unit
Maintenance and Service Outdoor Unit The heat exchanger coils and panel vents of the outdoor unit should be checked regularly. If clogged with dirt or soot, the heat exchanger and panel vents may be professionally steam cleaned. NOTE Dirty or clogged coils will reduce the operating efficiency of the system and cause higher operating costs. Operation Tips! Do not overcool the room. -
Page 21: Troubleshooting Tips! Save Time And Money
Maintenance and Service Troubleshooting Tips! Save time and money! The air conditioner may be operating abnormally when: Problem Possible Causes What To Do n The air conditioner is • Make sure the air conditioner plug is unplugged. pushed completely into the outlet. n The fuse is blown/circuit •... - Page 22 Memo 22 Air Conditioner...
- Page 23 Av. Sor Juana lnés de la Cruz No. 555 Col. San Lorenzo LG ELECTRONICS MEXICO, S.A. DE C.V. Tlalnepantla, Estado de México C.P. 54033 Sor Juana Ines de la Cruz No. 555, San Lorenzo Tel. 5321 1919 Tlalnepantla Estado de Mexico Teléfono sin costo 01 800 347 1919...
