- Page 1 Volume OPERATIONAL MANUAL MODEL: SDS200 SECTIONAL DRAIN CLEANING MACHINE by BLUEROCK ® Tools...
- Page 2 S D S 2 0 0 P I P E D R A I N C L E A N E R UNPACKING THE ITEM Caution: This machine is packed together with items that may be sharp, oily and overly heavy objects. Remove the machine from the packaging in a safe manner.
-
Page 3: Table Of Contents
S D S 2 0 0 P I P E D R A I N C L E A N E R Table of Contents SAFETY PRE-OPERATIONAL SAFETY CHECKS OPERATIONAL SAFETY CHECKS SPECIFICATIONS INCLUDED ACCESSORIES ADDITIONAL AVAILABLE ACCESSORIES BLUEROCK ® T DDITIONAL ACCESSORIES FOR THIS MACHINE CAN BE FOUND IN OOLS ONLINE SHOP AT BLUEROCKTOOLS COM OR FROM YOUR LOCAL RETAILER... -
Page 4: Safety
Chapter S D S 2 0 0 P I P E D R A I N C L E A N E R Safety DO NOT USE THIS MACHINE UNLESS YOU HAVE READ THE OPERATING INSTRUCTIONS! Safety glasses must be worn at all times in Long and loose hair must be work areas. - Page 5 S D S 2 0 0 P I P E D R A I N C L E A N E R Ø DO always non-slip rubber soled shoes. Ø DO be extremely careful when cleaning drains where chemical cleaning compounds have been previously used. Ø...
-
Page 6: Specifications
S D S 2 0 0 P I P E D R A I N C L E A N E R Chapter Specifications ELECTRICAL DATA Voltage 110V, 60Hz Induction Motor Current 10 Amps Motor Size 1100W Power Connection US Standard 3 Prong Grounded Plug and inline GFCI MECHANICAL DATA Pipe Capacity 2”... -
Page 7: Operations
THOROUGHLY READ THROUGH THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE! PURPOSE Ø The purpose of the SDS200 is for cleaning the insides of drainpipes from 2” to 8” in diameter. This is a heavy-duty professional use machine allowing a single user to easily clean pipes. Ø... -
Page 8: Preperation For Threading
S D S 2 0 0 P I P E D R A I N C L E A N E R Ø The machine has a main on/off switch with a forward and reverse position. These switches operate the turning mechanism, which turn the machine clutch. - Page 9 S D S 2 0 0 P I P E D R A I N C L E A N E R Ø Rubber Safety Hose Operations The rubber safety hose is attached to the back of the clutch channel. See figure below. CAUTION: The rubber safety hose must be installed.
- Page 10 S D S 2 0 0 P I P E D R A I N C L E A N E R § When deciding which cutter to use, the user should choose a cutter size that is at least 1”...
-
Page 11: Running The Machine
S D S 2 0 0 P I P E D R A I N C L E A N E R RUNNING THE MACHINE Ø Do all pre-operational and operational safety checks from Chapter 1. Ø Consider your security and stability as well as the orientation of the machine in the work area. Consider the work surface material, condition, strength, density and rigidity. - Page 12 S D S 2 0 0 P I P E D R A I N C L E A N E R Ø Turn the main machine switch to the “on” position (“R” for general cutting forward clockwise). NOTE: The machine will turn on, but the cable will not spin yet (until the clutch handle is depressed.
- Page 13 S D S 2 0 0 P I P E D R A I N C L E A N E R With gloved hand, pull the cable out or hold cable against the edge of the sewer inlet pipe until a half circle is formed in the cable.
-
Page 14: Troubleshooting
S D S 2 0 0 P I P E D R A I N C L E A N E R Chapter Troubleshooting Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! PROBLEM CAUSE CORRECTION... -
Page 15: General Maintenance
S D S 2 0 0 P I P E D R A I N C L E A N E R Chapter General Maintenance Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! Ø... -
Page 16: Parts List
S D S 2 0 0 P I P E D R A I N C L E A N E R Chapter Parts List Part Description Specification Description Specification Hull Strain relies M12 Plastic Inner hexagon screw M5*35 Protective shield Φ74*74*69 PA6 74*74*1.5mm Gland... -
Page 17: Breakdown View
S D S 2 0 0 P I P E D R A I N C L E A N E R Breakdown View...
